Module Rf Receive Sensitivity; Module Operating Frequencies - SIM Tech SIMCom SIM800H Hardware Design

Table 48: DCS1800 and PCS1900 conducted RF output power
PCL Nominal output power (dBm)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

6.10.2. Module RF Receive Sensitivity

The following table shows the module's conducted receiving sensitivity, it is tested under static condition.
Table 49: Conducted RF receive sensitivity
Frequency
GSM850,EGSM900
DCS1800,PCS1900

6.10.3. Module Operating Frequencies

The following table shows the module's operating frequency range; it is followed by the 3GPP TS 05.05
technical specification requirement.
Table 50: Operating frequencies
Frequency
GSM850
EGSM900
DCS1800
PCS1900
SIM800H _Hardware Design_V2.03
DCS1800,PCS1900
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
0
Receive sensitivity（Typical）
< -108dBm
< -108dBm
Receive
869 ～ 894MHz
925 ～ 960MHz
1805 ～ 1880MHz
1930 ～ 1990MHz
Smart Machine Smart Decision
Tolerance (dB) for conditions
Normal
±2
±3
±3
±3
±3
±3
±3
±3
±3
±4
±4
±4
±4
±4
±5
±5
Receive sensitivity(Max)
< -106dBm
< -106dBm
Transmit
824 ～ 849MHz
880 ～ 915MHz
1710 ～ 1785MHz
1850 ～ 1910MHz
59
Extreme
±2.5
±4
±4
±4
±4
±4
±4
±4
±4
±5
±5
±5
±5
±5
±6
±6
