  • Page 1 SIM5320JE-TE_Hardware Design_V1.01...
  • Page 2 Smart Machine Smart Decision SIM5320JE-TE Hardware Design Document Title 1.01 Version 2012-07-10 Date Release Status SIM5320JE-TE_Hardware Design_V1.01 Document Control ID General Notes SIMCom offers this information as a service to its customers, to support application and engineering efforts that use the products designed by SIMCom. The information provided is based upon requirements specifically provided to SIMCom by the customers.

  • Page 3: Table Of Contents

    Smart Machine Smart Decision Contents Revision History .............................. 9 Introduction ............................10 Product Outline ..........................10 Hardware Interface Overview......................11 Hardware Diagram..........................11 Functional Overview......................... 12 Package Information ..........................13 Pin Configuration..........................13 Pin description........................... 15 Package Dimensions ......................... 18 Board-to-board connector .........................
  • Page 4 Smart Machine Smart Decision 3.9.1 Pin Description........................... 39 3.10 GPIO Interface..........................40 3.10.1 Pin Description ........................40 3.10.2 Application Guide........................41 3.11 PCM Interface..........................43 3.11.1 Pin Description ........................43 3.11.2 Signal Description ........................43 3.12 Global Positioning System ......................47 3.12.1 Technical specification ......................
  • Page 5 Smart Machine Smart Decision Table Index Table 1: SIM5320JE-TE series frequency bands ......................10 Table 2: General Feature ..............................12 Table 3: Board-to-Board Connector pin description ....................... 14 Table 4: Pin description..............................15 Table 5: Pin description..............................21 Table 6: Power on timing ..............................26 Table 7: Power off timing ...............................
  • Page 6 Smart Machine Smart Decision Table 43: Operating Modes Overview ..........................55 Table 44: Current consumption ............................57 Table 45: The ESD performance measurement table (Temperature: 25℃, Humidity: 45%) .......... 59 Table 46: SIM5320JE-TE GPIOs list..........................60 Table 47: Digital I/O characteristics..........................60 Table 48: Related documents ............................
  • Page 7 Smart Machine Smart Decision Figure Index Figure 1: SIM5320JE-TE functional architecture ......................11 Figure 2: Pin view................................13 Figure 3: Top dimensions (Unit: mm) ..........................18 Figure 4: Side dimensions (Unit: mm) ..........................18 Figure 5: Panasonic AXK580147YG board-to-board connector pin side ............... 19 Figure 6: Panasonic AXK680347YG board-to-board connector pin side ...............
  • Page 8 Smart Machine Smart Decision SIM5320JE-TE_Hardware Design_V1.01 2012-07-10...

  • Page 9: Revision History

    Smart Machine Smart Decision Revision History Data Version Description of change Author 2012-07-10 1.01 Original Libing SIM5320JE-TE_Hardware Design_V1.01 2012-07-10...

  • Page 10: Introduction

    Introduction This document describes electronic specifications, RF specifications, function interface, mechanical characteristic and testing conclusions of the SIMCom SIM5320JE-TE module. With the help of this document and other SIM5320JE-TE software application notes, user guides, users can quickly understand and use SIM5320JE-TE module to design and develop applications quickly.

  • Page 11: Hardware Interface Overview

    Smart Machine Smart Decision Hardware Interface Overview The physical interface to the mobile application is made through a 80 pins board-to-board connector, which provides all hardware interfaces between the module and customers’ boards except the RF antenna interface. Sub-interfaces are described in detail in the next chapter, which includes: ●...

  • Page 12: Functional Overview

    Smart Machine Smart Decision Functional Overview Table 2: General Feature Feature Implementation Power supply Single supply voltage 3.3～4.2V Dual-mode UMTS/HSDPA/EDGE/GPRS operation ● GPRS Class B, multislot class 12 operation, Supports coding scheme: ● CS1-4 EDGE multislot class 12 operation, Supports coding schemes ●...

  • Page 13: Package Information

    Smart Machine Smart Decision Package Information Pin Configuration All hardware interfaces which connect SIM5320JE-TE to customers’ application platform are through 80 pins . Figure 2 is SIM5320JE-TE outline diagram. Board-to-Board Connector Figure 2: Pin view SIM5320JE-TE_Hardware Design_V1.01 2012-07-10...
  • Page 14 Smart Machine Smart Decision Table 3: Board-to-Board Connector pin description Pin No. Define Pin No. Define VBAT VBAT VBAT VBAT VBAT VBAT VBAT VBAT VRTC GPIO44 VREG_AUX GPIO40 CURRENT_SINK GPIO43 ADC2 GPIO41 ADC1 GPIO1 KEYSENSE_N4 GPIO42 KEYPAD_3 GPIO4 KEYPAD_4 I2C_SCL KEYPAD_1 I2C_SDA KEYSENSE_N3...

  • Page 15: Pin Description

    Smart Machine Smart Decision EAR1N RESET MIC1N SPI_CS_N MIC1P SPI_MOSI_DATA SPK_P SPI_MISO_DATA SPK_M SPI_CLK Pin description Table 4: Pin description Pin name Description Comment Power Supply VBAT Power supply voltage VRTC Power supply for RTC If it is unused, keep open. VREG_AUX LDO power output Ground...
  • Page 16 Smart Machine Smart Decision SPI (master only) master out/slave in SPI_MOSI_DATA data SPI (master only) master in/slave out SPI_MISO_DATA data USB_VBUS USB power supply input Plus (+) line of the differential, They are compliant with bi-directional USB signal to/from the USB_DP the USB 2.0 specification.
  • Page 17 Smart Machine Smart Decision General Input PIN. It also can be PCM_SYNC/GPIO2 multiplexed as the PCM_SYNC pin. General Output PIN. It also can be PCM_CLK/GPIO3 multiplexed as the PCM_CLK pin. General Output PIN. It also can be PCM_DOUT/GPIO5 multiplexed as the PCM_DOUT pin. GPIOs Output PIN as LED control for GPIO1...

  • Page 18: Package Dimensions

    Smart Machine Smart Decision Package Dimensions The following figure shows mechanical dimensions of SIM5320JE-TE. Figure 3: Top dimensions (Unit: mm) Figure 4: Side dimensions (Unit: mm) 2.4 Board-to-board connector We recommend users to adopt Panasonic AXK770247G as the board to board connector in their own PCB SIM5320JE-TE_Hardware Design_V1.01 2012-07-10...

  • Page 19: Rf Connector And Adapter Cable

    Smart Machine Smart Decision to connect with SIM5320JE-TE. These high density SMT connectors are designed for parallel PCB-to-PCB applications. They are ideal for using in VCRs, notebook PCs, cordless telephones, mobile phones, audio/visual and other telecommunications equipment where reduced size and weight are important.
  • Page 20 Smart Machine Smart Decision 删除的内容: 7 Figure 7: RF connector MM9329-2700 删除的内容: 8 Figure 8: RF adapter cable MXTK88TK2000 For more information about the connector, please visit http://www.murata.com/ SIM5320JE-TE_Hardware Design_V1.01 2012-07-10...

  • Page 21: Application Interface Specification

    Smart Machine Smart Decision Application Interface Specification Power Supply The power supply range of SIM5320JE-TE is from 3.3V to 4.2V. For the VBAT, the ripple due to GSM/GPRS emission burst (every 4.615ms）may cause voltage drop, and the current consumption rises typically to peak of 2A.
  • Page 22 Smart Machine Smart Decision tantalum capacitor (above 100uF) will be the best way to reduce the voltage drops. If the power current cannot support up to 2A, users must introduce larger capacitor (typical 1000uF) to storage electric power, especially GPRS multiple time slots emission. For the consideration of RF performance and system stability, another large capacitor (above 100uF) should be located at the VBAT pin and some multi-layer ceramic chip (MLCC) capacitors (0.1uF) need to be used for EMC because of their low ESR in high frequencies.

  • Page 23: Rtc Backup

    Smart Machine Smart Decision 删除的内容: 11 Figure 11: Reference circuit of the DCDC power supply Voltage monitor To monitor the power supply voltage, user can use the AT command “AT+CBC”, this command has two parameters: the battery status and the voltage value (mV). It will return the capacity percentage and actual value of battery (at the VBAT pin).
  • Page 24 Smart Machine Smart Decision 删除的内容: 13 Figure 13: RTC supply from non-chargeable battery Rechargeable battery backup 删除的内容: 14 Figure 14: RTC supply from rechargeable battery Note: The VRTC can be disabled, jus disconnect it in application circuit. Coin-type rechargeable battery is recommended, such as XH414H-IV01E form Seiko can be used. Typical charge-discharge curves for this battery are shown in the following figure.

  • Page 25: Power On/Off Time Sequence

    Smart Machine Smart Decision Power on/off Time Sequence 3.2.1 Power on Sequence SIM5320JE-TE can be powered on by POWER_ON pin, which starts normal operating mode. POWER_ON pin is pulled up with a 200kR resistor to 1.8V in module. User can power on the SIM5320JE-TE by pulling the POWER_ON pin down for a short time.

  • Page 26: Power Off Sequence

    Smart Machine Smart Decision 删除的内容: 6 Table 6: Power on timing Parameter Description Time value Unit The time to pull POWER_ON down to power on 64< Ton<180 TpD+ The time to indicate connecting with the network >5.5 The time to indicate the module is powered on Tpw+ >4.5 completely...
  • Page 27 Smart Machine Smart Decision completely powering the module off. Method 1: Power off SIM5320JE-TE by pulling the POWER_ON pin down ● Method 2: Power off SIM5320JE-TE by AT command ● User can power off the SIM5320JE-TE by pulling POWER_ON down for a specific time. The power off scenario is illustrated in the following figure.

  • Page 28: Uart Interface

    Smart Machine Smart Decision UART Interface SIM5320JE-TE provides a UART (universal asynchronous serial transmission) port. It consists of a flexible 7-wire serial interface. The module is as the DCE (Data Communication Equipment) and the client PC is as the DTE (Data Terminal Equipment). AT commands are entered and serial communication is performed through UART interface.

  • Page 29: Pin Description

    Smart Machine Smart Decision 3.3.1 Pin Description 删除的内容: 8 Table 8: Pin description Pin type Pin name Pin No. Active voltage Default Status UART_RXD High/Low Pull-Down High/Low UART_TXD Pull-Up High/Low UART_RTS High/Low UART UART_CTS Pull-Up High/Low UART_DTR Pull-Up High/Low UART_DCD High/Low UART_RI More pin information refers to chapter 2.2.

  • Page 30: Audio Interfaces

    Smart Machine Smart Decision If Full Modem is used to establish communication between devices, the pin “RI” is another operation status. Initially it keeps high, when a voice call or CSD call comes, the pin “RI” will change to low for about 5900ms, then it will return to high level for 100ms.

  • Page 31: Design Guide

    Smart Machine Smart Decision Table 11: MIC input characteristics Parameter Unit Working Voltage Working Current 0.07 External Microphone Load Resistance k Ohms Table 12: Audio output characteristics Parameter Unit Normal Load resistance Differential (EAR_P,EAR_N) Output power Table 13: Speaker output characteristics Parameter Unit Quiescent Current...

  • Page 32: Audio Parameter Characteristic

    Smart Machine Smart Decision 删除的内容: 24 Figure 24: Receiver interface configuration 删除的内容: 25 Figure 25: Microphone interface configuration Note: SIM5320JE-TE has integrated MIC bias circuit. There is no need to pull the MIC1P and MIC1N up to the external power, just connect it to microphone. MIC1P and MIC1N must be differential lines. 3.4.3 Audio Parameter Characteristic Main audio parameters can be changed to satisfy users’...

  • Page 33: Usim Interface

    Smart Machine Smart Decision MICP/MICN analogue amplifier 0…1 0…24dB 2 steps AT+CMICAMP1 micAmp1 gain before ADC Digital gain of input Mute, (txVol/ AT+CTXVOL txVol signal after ADC 1...65535 -84...+12dB 16384) Digital gain of input signal after Mute, (txGain/ AT+CTXGAIN txGain summation 1...65535 -84...+12dB...

  • Page 34: Application Guide

    Smart Machine Smart Decision V_USIM 3.00 1.65 USIM_RESET 0.8* V_USIM 3.00 V_USIM 0.8* V_USIM V_USIM USIM_CLK 0.7* V_USIM 3.00 V_USIM 0.8* V_USIM V_USIM USIM_DATA 0.7* V_USIM 3.00 V_USIM 0.8* V_USIM V_USIM Table 16: Pin description Pin name Description USIM_CLK USIM Card Clock USIM_RESET USIM Card Reset USIM Card data I/O, which has been pulled up with a 22kR resistor to...

  • Page 35: Recommend Components

    Smart Machine Smart Decision 3.5.3 Recommend Components For 6 pins USIM socket, SIMCom recommend to use Amphenol C707 10M006 512 2. User can visit http://www.amphenol.com for more information about the holder. 删除的内容: 27 Figure 27: Amphenol SIM card socket Table 17: Amphenol USIM socket pin description Signal Description SIM Card Power supply, it can identify automatically the...

  • Page 36: Pin Description

    Smart Machine Smart Decision receiver, depending on the device function. Use AT Commands “AT+CRIIC and AT+CWIIC” to read/write register values of related peripheral equipments connected with I2C interface. 3.6.1 Pin Description Table 18: Pin description Pin name Pin No. Function I2C_SDA Serial interface data input and output I2C_SCL...

  • Page 37: Application Guide

    Smart Machine Smart Decision Table 19: Pin description Pin name Pin No. Function KEYSENSE_N0 KEYSENSE_N1 KEYSENSE_N2 Sensing keys KEYSENSE_N3 KEYSENSE_N4 KEYPAD_0 KEYPAD_1 Driving pads KEYPAD_2 KEYPAD_3 KEYPAD_4 3.7.2 Application Guide All keypad pins can be configured for GPIOs. These GPIOs also support interruption operation if used as input pins.

  • Page 38: Usb Interface

    Smart Machine Smart Decision Table 20: GPIO configuration Keypad interface GPIO No. KEYPAD_4 GPIO6 KEYPAD_3 GPIO7 KEYPAD_2 GPIO8 KEYPAD_1 GPIO9 KEYPAD_0 GPIO10 KEYSENSE_N4 GPIO11 KEYSENSE_N 3 GPIO12 KEYSENSE_N 2 GPIO13 KEYSENSE_N 1 GPIO14 KEYSENSE_N 0 GPIO15 Note: Refer to document [23] for detailed information of Keypad Application Note. USB Interface SIM5320JE-TE module contains a USB interface.

  • Page 39: Spi Interface

    Smart Machine Smart Decision 删除的内容: 29 Figure 29: USB interface Because of high bit rate on USB bus, pay attention to influence of junction capacitance of ESD component on USB data lines. Typically, the capacitance should be less than 4pF @1MHz. ：...

  • Page 40: Gpio Interface

    Smart Machine Smart Decision Table 23: Pin description Pin name Pin No. Function SPI_CS SPI chip-select; not mandatory in a point-to-point connection SPI_MISO_DATA SPI master in/slave out data SPI_CLK SPI clock SPI_MOSI_DATA SPI master out/slave in data 3.10 GPIO Interface SIM5320JE-TE provides a limited number of GPIO pins.

  • Page 41: Application Guide

    Smart Machine Smart Decision Table 25: Pin description Pin name Pin No. Function Output PIN as LED control for network status. If it is GPIO1 unused, left open. Input PIN as RF operating control. H: Normal Mode L:Flight Mode GPIO4 If it is unused, left open.
  • Page 42 Smart Machine Smart Decision Table 26: LED status LED Status Module Status Always On Searching Network/Call Connect 200ms ON, 200ms OFF Data Transmit 800ms ON, 800ms OFF Registered network Power off / Sleep Flight mode control GPIO4 controls SIM5320JE-TE module to enter or exit the Flight mode. In Flight mode, SIM5320JE-TE closes RF function to prevent interference with other equipments or minimize current consumption.

  • Page 43: Pcm Interface

    Smart Machine Smart Decision 3.11 PCM Interface SIM5320JE-TE provides hardware PCM interface for external codec. The PCM interface enables communication with an external codec to support hands-free applications. SIM5320JE-TE PCM interface can be used in two modes: the default mode is auxiliary PCM (8 KHz long sync mode at 128 KHz PCM CLK);...
  • Page 44 Smart Machine Smart Decision PCM mode after powering on or resetting the module every time if user wants to use Primary PCM.SIM5320JE-TE PCM Interface can be operated in Master or Slave mode if it is configured to primary PCM. In Master Mode, the Module drives the clock and sync signals that are sent to the external codec.
  • Page 45 Smart Machine Smart Decision 删除的内容: 34 Figure 34: MODULE to EXT CODEC timing Table 30: Timing parameters Parameter Description Unit T(auxsync) AUX_PCM_SYNC cycle time – μs T(auxsynch) AUX_PCM_SYNC high time 62.4 62.5 μs T(auxsyncl) AUX_PCM_SYNC low time 62.4 62.5 μs T(auxclk)* AUX_PCM_CLK cycle time –...
  • Page 46 Smart Machine Smart Decision 删除的内容: 36 Figure 36: EXT CODEC to MODULE timing 删除的内容: 37 Figure 37: MODULE to EXT CODEC timing Table 31: Timing parameters Parameter Description Max Unit T(sync) PCM_SYNC cycle time – – μs T(synch) PCM_SYNC high time –...

  • Page 47: Global Positioning System

    Smart Machine Smart Decision Delay from PCM_CLK falling to PCM_DOUT T(zdout) – – HIGH-Z Note: SIM5320JE-TE can transmit PCM data by USB except for PCM interface. Please refer to document [22] for more information of PCM Application Note. 3.12 Global Positioning System SIM5320JE-TE merges GPS satellite and network information to provide a high-availability solution that offers industry-leading accuracy and performance.

  • Page 48: Application Guide

    Smart Machine Smart Decision required to calculate the handset’s position. Therefore, rather than provide the GPS measurements and available network data back to the location server, the mobile calculates the location on the handset and passes the result to the requesting entity. In standalone (autonomous) mode, the handset demodulates the data directly from the GPS satellites.

  • Page 49: Reset Function

    Smart Machine Smart Decision Table 32: Electronic characteristic Symbol Description Unit CURRENT_SINK Input voltage Input current Since the driver is ground-referenced current sink, the operating device it drives must form a current path between the VDD pin and the CURRENT_SINK pin. The following figure is for users reference. VBAT Passive Pin 45 is +5V tolerant-...

  • Page 50: Adc

    Smart Machine Smart Decision 删除的内容: 39 Figure 39: Reset circuit ： Note 50ms<t<200ms. ESD components are suggested to be used on Reset pin. 3.13.3 ADC SIM5320JE-TE has a dedicated ADC that is available for digitizing analog signals such as battery voltage and so on;...

  • Page 51: Ldo

    Smart Machine Smart Decision Note: The input signal voltage value in ADC must not be higher than 2.2V. 3.13.4 LDO SIM5320JE-TE has a LDO power output, namely VREG_AUX. The LDO is available and output voltage is 2.6V by default, rated for 250mA. User can switch the LDO on or off by the AT command “AT+CVAUXS”...

  • Page 52: Operating Specification

    Smart Machine Smart Decision Table 36: Operating frequencies Frequency Receiving Transmission GSM850 869 ～894 824 ～849 E-GSM900 925 ～960 880 ～915 DCS1800 1805～1880 MHz 1710～1785 MHz PCS1900 1930～1990 MHz 1850～1910 MHz WCDMA 2100 2110～2170 MHz 1920～1980 MHz WCDMA 900 925 ～960 880 ～915 Table 37: Conducted receive sensitivity Frequency...

  • Page 53: Antenna Design Guide

    Smart Machine Smart Decision Table 39: HSDPA throughout Max supported Theoretical max Category Supported Modulation HS-DSCH codes peak rate(Mbps) Category1 16QAM,QPSK Category2 16QAM,QPSK Category3 16QAM,QPSK Category4 16QAM,QPSK Category5 16QAM,QPSK Category6 16QAM,QPSK Category7 16QAM,QPSK Category8 16QAM,QPSK Category9 10.0 16QAM,QPSK Category10 14.0 16QAM,QPSK Category11 QPSK...

  • Page 54: Reliability And Operating Characteristics

    Smart Machine Smart Decision Reliability and Operating Characteristics Electronic Characteristics Absolute maximum rating for digital and analog pins of SIM5320JE-TE are listed in the following table: Table 40: Absolute maximum ratings Parameter Unit Voltage at digital pins (1.8v digital I/O) -0.3 Voltage at digital pins (2.6v digital I/O) -0.3...

  • Page 55: Operating Modes Overview

    Smart Machine Smart Decision 5.2.1 Operating Modes Overview Table 43: Operating Modes Overview Mode Function Module will automatically enter SLEEP mode if DTR is set to high level and there is no on air or hardware interrupt (such as GPIO interrupt or data on serial port).

  • Page 56: Minimize Power Consumption

    Smart Machine Smart Decision 5.2.2 Minimize Power Consumption There are two modes that SIM5320JE-TE achieves low power consumption. Sleep mode If peripheral equipments stops working, and there is no on air or hardware interrupts (such as GPIO interrupts or data on UART), SIM5320JE-TE will enter sleep mode automatically. In this mode, SIM5320JE-TE can still receive paging ，...
  • Page 57 Smart Machine Smart Decision Table 44: Current consumption GSM Sleep mode (without USB connection) Sleep @DRX=2 4.5mA GSM850 Sleep @DRX=5 2.7mA Sleep @DRX=9 2.3mA Sleep @DRX=2 4.5mA GSM900 Sleep @DRX=5 2.7mA Sleep @DRX=9 2.3mA Sleep @DRX=2 4.5mA DCS1800 Sleep @DRX=5 2.7mA Sleep @DRX=9 2.3mA Sleep @DRX=2 4.5mA PCS1900...

  • Page 58: Emc And Esd Notes

    Smart Machine Smart Decision DCS1800 @power level #0 <400mA,Typical 260mA PCS1900 @power level #0 <300mA,Typical 263mA EDGE Data DATA mode, EDGE( 1 Rx,4 Tx ) CLASS 12 GSM 850 @power level #8 <500mA,Typical 335mA GSM 900 @power level #8 <500mA,Typical 332mA DCS1800 @power level #2 <450mA,Typical 291mA PCS1900...
  • Page 59 Smart Machine Smart Decision the application to the RF receiver in the receiver band. RF emissions interfere with audio input/output. It is recommended to shield the sensitive components and trace with common ground and user can add beads where necessary. Normally SIM5320JE-TE is mounted on customer host board.

  • Page 60: Appendix

    Smart Machine Smart Decision Appendix A. SIM5320JE-TE GPIOs List Table 46: SIM5320JE-TE GPIOs list Name GPIO Index Default Function Alternate Function PCM_DIN GPIO Interrupt [LEVEL/LOW] PCM_DIN STATUS_LED Status led GPIO PCM_SYNC GPIO [IN] PCM_SYNC PCM_CLK GPIO [OUT/LOW] PCM_CLK RF_SWITCH RF Switch Enable/Disable RF subsystem PCM_OUT GPIO [OUT/LOW]...

  • Page 61: Related Documents

    Smart Machine Smart Decision High-level 2.15 1.35 output voltage Low-level 0.45 0.45 output voltage High-level output current Low-level output current Input high leakage current Input leakage current Input capacitance Note: These parameters are for digital interface pins, such as keypad, GPIO, I C, UART, SPI.
  • Page 62 Smart Machine Smart Decision Equipment (SIM – ME) interface Digital cellular telecommunications system (Phase 2+); Alphabets GSM 03.38 and language-specific information Digital cellular telecommunications system (Phase 2)； Mobile GSM 11.10 Station (MS) conformance specification； Part 1: Conformance specification Digital cellular telecommunications system (Release 5); Mobile [10] 3GPP TS 51.010-1 Station (MS) conformance specification...

  • Page 63: Terms And Abbreviations

    Smart Machine Smart Decision D. Terms and Abbreviations Table 49: Terms and Abbreviations Abbreviation Description Analog-to-Digital Converter Antenna Reference Point Bit Error Rate Base Transceiver Station Coding Scheme Circuit Switched Data Clear to Send Digital-to-Analog Converter Discontinuous Reception Digital Signal Processor Data Terminal Equipment (typically computer, terminal, printer) Data Terminal Ready Discontinuous Transmission...
  • Page 64 Smart Machine Smart Decision Receive Direction Subscriber Identification Module Short Message Service serial peripheral interface TDMA Time Division Multiple Access Terminal Equipment, also referred to as DTE Transmit Direction UART Universal Asynchronous Receiver & Transmitter VSWR Voltage Standing Wave Ratio Vmax Maximum Voltage Value Vnorm...

  • Page 65: Safety Caution

    Smart Machine Smart Decision E. Safety Caution Table 50: Safety caution Marks Requirements When in a hospital or other health care facility, observe the restrictions about the use of mobiles. Switch the cellular terminal or mobile off, medical equipment may be sensitive to not operate normally for RF energy interference.
  • Page 66 Smart Machine Smart Decision Contact us: Shanghai SIMCom Wireless Solutions Ltd. Add: SIM Technology Building, No.633, Jinzhong Road, Changning District, Shanghai P.R. China 200335 Tel: +86 21 3235 3300 Fax: +86 21 3235 3301 URL: www.sim.com/wm SIM5320JE-TE_Hardware Design_V1.01 2012-07-10...
