- Page 1 BRM2720X BRM2780 Cardio Dual Trainer This product is intended for indoor, home use only and is not to be used in a commercial setting. OWNER’S MANUAL...
- Page 2 This page is left blank intentionally...
- Page 3 The diagram below highlights and reviews many of the important Safety and Warning labels also found on the unit. Please ensure any user of the unit familiarizes themselves with these Safety and Warning guidelines before use. Page 1 BRM2720X / 2780...
-
Page 4: General Information
- 1 x Philips (”Crosshead”) Screw Driver Telephone: 1 (888) 266A - 6789 Fax: 1 (909) 598 - 6707 Weight Limit Email: info@bodyflexsports.com Your product is suitable for users weighing : 250 pounds or less Page 2 BRM2720X / 2780... -
Page 5: Before Assembly
Use to measure the length or size of hardware including QTY: 1 bolts to ensure you are using the correct part. Adjustable or flat wrenches Use to securely install parts including nuts and bolts. QTY: 2 Page 3 BRM2720X / 2780... -
Page 6: Part Listing
33 Cap Nut (M8) 70 Tool 1 34 Nylon Nut (M10) 71 Tool 2 35 Nylon Nut (M8) 72 Bolt (M8x30 mm) 37 Special Washer (16 mm) 73 Rectangular Inner Plug (25x40 mm) 38 Special Washer (19 mm) Page 4 BRM2720X / 2780... -
Page 7: Exploded View
: : Not all of the parts and hardware you see here will be used while you are assembling the machine because some of these items are already pre-installed. Please use this page only as a reference guide for parts and hardware. Page 5 BRM2720X / 2780... -
Page 8: Hardware And Tool List
[11 Pieces] [2 Pieces] [4 Pieces] [8 Pieces] pre-assembled [2 Pieces] [3 Pieces] pre-assembled Others (#57) Round Cap (#55) Plastic Bushing (#70) Tool 1 (#71) Tool 2 [2 Pieces] [1 Piece] [2 Pieces] [1 Piece] Page 6 BRM2720X / 2780... -
Page 9: Assembly Step
Please Note that the Front Stabilizer (#08) has end caps that spin for ease of relocating the unit and the Rear Stabilizer (#09) has height adjustable end caps for leveling of the unit. Front Roller Page 7 BRM2720X / 2780... - Page 10 "8" is the highest level of tension (most difficult level for workout). TENSION WIRE ASSEMBLY Insert the tip of the Tension Controller (#17) wire into the Tension Wire (#18) head at an angle. Tilt the Tension Controller (#17) wire into the crevice and then pull upward. Page 8 BRM2720X / 2780...
- Page 11 Cap (#57), Washer (#42) and a Bolt (#27). #57 Round Cap #55 Plastic Bushing #42 Washer (M8) [2 Pieces] [2 Pieces] [2 Pieces] #45 D Shape Washer #38 Special Washer [2 Pieces] [2 Pieces] #27 Bolt (M8 x 20mm) [2 Pieces] Page 9 BRM2720X / 2780...
- Page 12 #28A Hex Bolt (M8x40 mm) [6 Pieces] Repeat this process on the other side. #41 Washer (M10) #34 Nylon Nut (M10) [2 Pieces] [2 Pieces] #35 Nylon Nut (M8) [6 Pieces] #42 Washer (M8) [6 Pieces] Page 10 BRM2720X / 2780...
- Page 13 You will need to connect this wire to the Monitor (#61) later. #69 Arc Washer (M6) #67 Cap Nut (M6) [4 Pieces] [4 Pieces] Page 11 BRM2720X / 2780...
- Page 14 #30 Screw (M5x12mm) [4 Pieces] connect the Pulse Sensor Wire (#60) to the Monitor (#61). Secure the Monitor (#61) to the bracket of the Center Post (#02A) with four Screws (#30) that were previously removed. Page 12 BRM2720X / 2780...
- Page 15 However, for your own safety, please make sure to read this entire Owner’s Manual which includes safety instructions and warnings, as well as any safety/warning labels affixed to the product before use. For your safety , please visually and functionally inspect and test the unit after assembly is complete. Page 13 BRM2720X / 2780...
-
Page 16: Computer Operation
Press ENTER button until the TIME function is selected and press the UP or DOWN button to enter the value you wish to choose. Count up: If you do not set a time value with the UP or DOWN button, the monitor will count up the time from 00:00~99:59. Page 14 BRM2720X / 2780... - Page 17 If you set a value between the allowed limits (60 to 220), the monitor will measure your pulse. Once you have reached the set value, the monitor will flash until your pulse reading is below your set value. Page 15 BRM2720X / 2780...
- Page 18 - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Page 16 BRM2720X / 2780...
-
Page 19: Safety And Maintenance
Body Flex Sports Inc. 21717 Ferrero Parkway Walnut, CA 91789 More detailed information about how to reach our CUSTOMER SUPPORT may be found on Page 2 of the Owner’s Manual under the “CUSTOMER SUPPORT” section. Page 17 BRM2720X / 2780... -
Page 20: Troubleshooting
2. Check to ensure the AC Adapter* or Batteries* are properly plugged in or fully charged. 3. Check your product manual to determine if your model uses either AC Adapter or batteries to power your unit. Page 18 BRM2720X / 2780... - Page 21 Keep your left leg straight. 2. Return to the starting position slowly. 2. Gently pull your right leg toward your trunk without raising your upper body. Switch leg positions and repeat. Page 19 BRM2720X / 2780...
- Page 22 Repeat on the other leg. muscles in your left calf stretch. other. Switch leg positions and repeat. Reverse arm positions and Page 20 BRM2720X / 2780...
- Page 23 This page is left blank intentionally...
- Page 24 THANK YOU FOR YOUR PURCHASE MODEL NO.: BRM2720X/BRM2780 along with your sales receipt as proof of purchase. Serial Number : Date of Purchase : Retailer : Body Flex Sports Inc. 21717 Ferrero Parkway Walnut, CA 91789 : 1 (888) 266A-6789...
