- Page 1 BCB580 Weight Bench with Butterfly and Leg Lift Curl Developer Extension This product is intended for indoor, home use only and is not to be used in a commercial setting. OWNER’S MANUAL...
- Page 2 This page is left blank intentionally...
- Page 3 Please ensure any user of the unit familiarizes themselves with these Safety and Warning guidelines before use. 250 lbs. User Weight; 110 lbs. Weight Set; 50 lbs. Leg Developer; 30 lbs. Each Butterfly x 2= 60 lbs. Total. BCB580 Page 1...
-
Page 4: General Information
50 lbs. Leg Developer 21717 Ferrero Parkway 30 lbs. Each Butterfly x 2 = 60 lbs. Total Walnut, CA 91789 Total: 470 lbs. Telephone: 1 (888) 266 - 6789 Fax: 1 (909) 598 - 6707 Email: info@bodyflexsports.com BCB580 Page 2... -
Page 5: Before Assembly
Ruler (with both Metric and English measurements) Use to measure the length or size of hardware including QTY: 1 bolts to ensure you are using the correct part. Adjustable or flat wrenches Use to securely install parts including nuts and bolts. QTY: 2 BCB580 Page 3... -
Page 6: Hardware And Tool List
(44) Washer (M8) 17 pcs (45) Washer (M10) 20 pcs Nuts (46) Nylon Nut (M8) 3 pcs (47) Nylon Nut (M10) 8 pcs Others #32 Knob Bolt (M10x50 mm) 1 pc #33 Knob (M10) 2 pcs Tools 2 pcs BCB580 Page 4... -
Page 7: Part Listing
Foam Roller Washer (M8) Round End Cap (Φ19 mm) Washer (M10) Round End Cap (Φ25 mm) Nylon Nut (M8) Square End Cap ( 50 mm) Nylon Nut (M10) Square End Cap ( 45 mm) Screw (M4x10 mm) BCB580 Page 5... -
Page 8: Exploded View
Exploded View The following diagram is provided to help you familiarize yourself with the parts and hardware that will be used during the assembly process. BCB580 Page 6... -
Page 9: Assembly Step
Repeat this process on the right side with right Rear Uprights (#05). Insert the Backrest Adjustment Tube (#07) into the Rear Uprights (#05) . Insert the Left Weight Rest (#15) and Right Weight Rest (#16) into the Rear Uprights (#05). BCB580 Page 7... - Page 10 (38) Hex Bolt (M10 x 20mm) 2 pcs two Nylon Nuts (#46). (40) Hex Bolt (M8 x 55mm) 2 pcs (44) Washer (M8) 4 pcs (45) Washer (M10) 4 pcs (46) Nylon Nut (M8) 2 pcs (47) Nylon Nut (M10) 2 pcs BCB580 Page 8...
- Page 11 Circle Tube on the Main Frame (#03). Secure it with a Washer (#45) and a Nylon Nut (#47). (43) Hex Bolt (47) Nylon Nut (M10) 1 pc (M8 x 15mm) 2 pcs (44) Washer (M8) 2 pcs (45) Washer (M10) 2 pcs BCB580 Page 9...
- Page 12 (39) Carriage Bolt (M8 x 45mm) 1 pc Developer (#02). Attach Quick Clip (#34) to the Weight Plate Bar (#11). (44) Washer (M8) 1 pc (45) Washer (M10) 2 pcs (46) Nylon Nut (M8) 1 pc (47) Nylon Nut (M10) 1 pc BCB580 Page 10...
- Page 13 Attach Seat Cushion (#18) to the Main Frame (#03), secure them together with four Hex Bolts (#42) and four Washers (41) Hex Bolt (M8 x 40mm) 4 pcs (#44). (42) Hex Bolt (M8 x 35mm) 4 pcs (44) Washer (M8) 8 pcs BCB580 Page 11...
- Page 14 Attach Arm Cushion (#17) to the Arm Curl Frame (#10), secure them together with two Hex Bolts (#43) and two Washers (#44). (44) Washer (M8) 2 pcs (43) Hex Bolt (M8 x 15mm) 2 pcs #32 Knob Bolt (M10x50 mm) 1 pc BCB580 Page 12...
- Page 15 However, for your own safety, please make sure to read this entire Owner’s Manual which includes safety instructions and warnings, as well as any safety/warning labels affixed to the product before use. For your safety , please visually and functionally inspect and test the unit after assembly is complete. BCB580 Page 13...
-
Page 16: Safety And Maintenance
1 (888) 266-6789 or 1 (909) 598-9876, or mail in a written request to: Body Flex Sports, Inc. 21717 Ferrero Parkway Walnut, CA 91789 More detailed information about how to reach our CUSTOMER SUPPORT may be found on the General Information page of this manual. BCB580 Page 14... - Page 17 Keep your left leg straight. 2. Return to the starting position slowly. 2. Gently pull your right leg toward your trunk without raising your upper body. Switch leg positions and repeat. BCB580 Page 15...
- Page 18 Repeat on the other leg. muscles in your left calf stretch. other. Switch leg positions and repeat. Reverse arm positions and BCB580 Page 16...
- Page 19 This page is left blank intentionally...
- Page 20 THANK YOU FOR YOUR PURCHASE MODEL NO.: BCB580 Please fill in the information below and keep this manual along with your sales receipt as proof of purchase. Serial Number : Date of Purchase : Retailer : Body Flex Sports, Inc.
