Technical Data; Installation - Scheppach DECO-XL Translation From The Original Instruction Manual

6. Technical data

Extent of delivery
Technical data
Dimensions
L x W x H mm
Bench size mm
Saw blade
length mm
Cutting height
max. mm
Working depth mm
Lifting
movement mm
Lifting speed 1/min
(electronical)
Bench diagonal
adjustment left
degrees
Weight kg
Suction connection
piece ø mm
Motor
Electrical motor
70 (S1); 90 (S2 30min);
Power W
* Duty type S2 – Short-time duty.
Operation at constant load for 30minutes or less, fol-
lowed by a time de-energized and at rest of sufficient
duration to re-establish machine temperatures within 2
K of the ambient temperature.
Noise and vibration
Total vibration values determined in accordance with
EN 61029.
sound pressure level L
pA
uncertainty K
pA
sound power level L
WA
uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing. Total
vibration values (vector sum - three directions) deter-
mined in accordance with EN 61029.

7. Installation

Setting the saw bench, Fig. 2
Setting the angle scale
• Release the star button (A and bring the saw bench
(B) to a right angle (C) in relation to the saw blade.
• Use a 90° angle tc measure the right angle between
the blade and the bench. The saw blade be 90° to
the angle.
• Close the star button again when the distance
between the blade and the 90° angle is at a minimum.
The bench should then be at 90° to the saw blade.
12 / 20
Scroll saw
Flexible Wave
Accessories kit
Operating instructions
630 x 320 x 380
ø 255 x 415
127
50
405
20
550 – 1600
0 – 45
11,8
35
230-240 V~/50 Hz
125 (S2 5min)
load no load
dB(A) 77,3 67,2
dB 3 3
dB(A) 87,4 78,4
dB 3 3
• Release the lock screw (D) and bring the indicator
to the zero position. Fasten the screw. Please note:
the angle scale is a useful piece of supplementary
equip ment, but should not be used for precision
work. Use scrap wood for saw tests, adjust the
bench if neces sary.
Note: The bench should not be on the motor
block, this can cause undesireable noise.
Horizontal saw bench and diagonal cuts, Fig. 2+3
• The saw bench can be positioned into a 450
diagonal position or be left in the horizontal
position.
• You can read off the approximate slope angle
by using the angle scale located under the work
bench. For more exact adjustment, use scrap wood
for some saw tests; adjust the bench if necessary.
Blade guard assembly, Fig. 4
Install the blade guard to the holder as shown in the
diagram. Secure the screws with a nut and washer.
• Lift the saw onto the frame and base and push it
onto the workbench.
• Familiarize yourself with the saw operating
elements and features.
Mounting the saw on a work bench, Fig. 5
• A workbench made from solid wood is betier than
one made of plywood, as interfering vibrations and
noise are more noticeable with plywood.
• The necessary tools and small parts for assembling
the saw on a workbench are not supplied with
the saw. However, use equipment of at least the
following size:
E Saw body
F Foam rubber base
GWork bench
H Flat seal
I Washer
J Hexagonal nut
K Lock nut
L Hexagonal bolt
Ouantity Description
4 Hexagonal bolts (6mm) 1/4-20 x length
4 Flat seal (7mm) 9/321.0
4 Washers (7mm) 9/321.0.
8 Hexagonal nuts (6 mm) 1/4-20
First of all, drill holes into the seating surface and
then insert the screws.
• A foam rubber base for reduction of noise is
not supplied with the saw either. However, we
expressly recommend that you use such a base to
keep vibration and noise to a minimum. Ideal size
400 x 240 mm.
CHANGING THE SAW BLADES
Warning: Switch off the saw and remove the
mains supply plug before installing saw b!ades
in order to avoid injuries caused by unintentiona!
activation of the saw.
