Summary of Contents for Amantii SYM-B Series

  • Page 1 Fix your Fireplace SYM-B Series...
  • Page 2 Content • How to replace LED light • How to replace flicker motor • How to replace heating element • How to replace the PCB board • How to replace the signal receiver...
  • Page 3: Safety First

    SAFETY FIRST TO AVOID ANY ELECTRICAL SHOCK OR POTENTIAL DAMAGE TO THE UNIT REMEMBER TO TURN THE POWER OFF TO THE UNIT BEFORE ATTEMPTING TO REMOVE OR INSTALL ANY PARTS.
  • Page 4 Replace LED light Replace ember bed LED light Step 1 Unscrew the screws circled in red to remove the trim.
  • Page 5 Magnetic stone Trim Please note The bottom of the trim is secured to the face by a magnetic stone.
  • Page 6 Step 2 After the trim’s been removed, take off the front glass panel. Front glass panel...
  • Page 7 Step 3 The side steel panels need to be removed. To remove the side panels, unscrew screws circled in red. The steel panels...
  • Page 8 Step 4 After the steel panels have been removed, the ember bed glass panel can carefully be removed by rising one end up first and then out. The ember bed LED strips are located below it. Remember this is a piece of glass and can break if not handled with care.
  • Page 9 Step 5 The LED strips are held in place with screws and are connected to the other strips or to the end using a molex connector. Unscrew the screws of the failed LED strip and unplug the molex connector to replace it with a new one. Unscrew Unplug...
  • Page 10 Replace Flame LED light Follow STEP 1 to 4 in Replace Ember Bed LED light Step 1 Remove the back glass to expose location of the flame LED. Unscrew the screws circled in red to remove the steel bar that secures the back glass.
  • Page 11 Step 2 Remove flame effect steel panel. To remove the panel, remove the 2 screws shown circled in red on each side of the unit. Remove the panel and set aside. Zoomed View Zoomed View...
  • Page 12 Once the panel has been removed you have exposed the location of the Flame LED strip. They are set back from the Ember bed LED as seen below Horizontal view Bird’s eye view LED strips for flame effect lie here...
  • Page 13 HOOK BUCKLE Step 3 The Flame LED strip is connected using a molex connector and secured in place with plastic hooks. Disconnect the strip from the molex connector and carefully unsecure the hooks holding the strip in place. A new strip can now be installed by reconnecting to the molex connector and secured to the unit using the hooks.
  • Page 14 Replace flicker motor Follow STEP 1 to 4 in Replace Ember Bed LED light Step 1 Remove the back glass to expose location of the Flicker motor. Unscrew the screws circled in red to remove the steel bar that secures the back glass. Remove steal bar and set aside. The back glass can now be removed and set aside.
  • Page 15 Step 2 Remove flame effect steel panel. To remove the panel, remove the 2 screws shown circled in red on each side of the unit. Remove the panel and set aside. Zoomed View Zoomed View...
  • Page 16 Once the flame effect steel panel’s been removed, you can locate the flame motor on the left side of the unit.
  • Page 17 Steps to remove Flicker Motor Step 1 Step 2 Step 3 The motor is Unscrew the clamp Unscrew the 2 connected using that secures the screws circled in red spade connectors. flicker rod onto the to remove the motor Carefully disconnect motor.
  • Page 18 Replace the heating element Follow STEP 1 to 4 in Replace Ember Bed LED light. Step 1 Remove the back glass to expose the flame effect steel panel. Unscrew the screws circled in red to remove the steel bar that secures the back glass.
  • Page 19 Step 2 Remove flame effect steel panel. To remove the panel, remove the 2 screws shown circled in red on each side of the unit. Remove the panel and set aside. Zoomed View Zoomed View...
  • Page 20 Step 3 Remove the screws circled in red located at the top rear of the inner firebox...
  • Page 21 Step 4 Remove inner top panel. Remove the screws circled in red to take off the inner top panel. The heating element, PCB board, Canopy light and Signal receiver are all fixed on it.
  • Page 22: Heating Element

    HEATING ELEMENT INNER TOP PANEL...
  • Page 23 Step 5 To replace the element, remove the screws circled in red that secures the heating element assembly from to the inner top panel and carefully remove the heater.
  • Page 24 Step 6 Remove heater brackets from the heater by removing the screws circled in red. Unplug the heater and replace it with a new heater. NOTE: When removing the heater, take note of how it was removed. The rubber spacers need reinstalled the same way that they were removed...
  • Page 25 Replace the PCB board Follow STEP 1 to 4 in Replace the heating element. PCB board INNER TOP PANEL...
  • Page 26 Step 1 Remove the 4 screws circled in red and replace the failed PCB board with a new one. Secure the new board to the inner top using the same 4 screws used to remove the board...
  • Page 27 Replace the signal receiver Follow STEP 1 to 4 in Replace the heating element to take off the inner top panel. The signal receiver lies here Step 1 Remove the 2 screws circled in red to take the signal receiver off the inner top panel.
  • Page 28 Step 2 The receiver is connected to the PCB board using a molex connector. Follow the lead from the receiver back to the board and disconnect it from the PCB board. A new receiver can be connected to the PCB board then secured to the inner top of unit.
