INSTALLATION AND OPERATION INSTRUCTIONS FOR
INSTALLATION AND OPERATION INSTRUCTIONS FOR
INSTALLATION AND OPERATION INSTRUCTIONS FOR
SYM-34
SYM-42
SYM-50
SYM-60
SYM-74
SYM-88
SYM-100
SAFETY INFORMATION
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
34
42
50
60
74
88
100
WARNING
appliance.
1
Advertisement
Table of Contents
Related Manuals for Amantii SYM-34
Summary of Contents for Amantii SYM-34
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR INSTALLATION AND OPERATION INSTRUCTIONS FOR INSTALLATION AND OPERATION INSTRUCTIONS FOR SYM-34 SYM-42 SYM-50 SYM-60 SYM-74 SYM-88 SYM-100 SAFETY INFORMATION WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS ............................ -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS 1. Read all instructions before installing or using this heater. 2. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front, sides and rear of the heater. 3. Always unplug heater when not in use. 4. - Page 4 knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
- Page 5 Cautions Always install the heater in accordance with this guide. If in doubt obtain expert advice. Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. Always disconnect the heater from the electrical supply before moving it, or Do’s carrying out cleaning, maintenance.
-
Page 6: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a 120 Volt grounded outlet. -
Page 7: Sym-34
SYM-34 Description This appliance has been tested in accordance Built-in Appliance Voltage 120V AC 60Hz with the UL Standard 2021 for fixed and location dedicated electric room appliances in the United Watts 1000W Max States and Canada. If you need assistance... -
Page 8: Sym-42
SYM-42 Description This appliance has been tested in accordance Built-in Appliance Voltage 120V AC 60Hz with the UL Standard 2021 for fixed and location dedicated electric room appliances in the United Watts 1000W Max States and Canada. If you need assistance NO HEATER 38W Max during installation, please contact your local... -
Page 9: Sym-50
SYM-50 Description This appliance has been tested in accordance Built-in Appliance Voltage 120V AC 60Hz with the UL Standard 2021 for fixed and location dedicated electric room appliances in the United Watts 1000W Max States and Canada. If you need assistance NO HEATER 42W Max during installation, please contact your local... -
Page 10: Sym-60
SYM-60 Description This appliance has been tested in accordance Built-in Appliance Voltage 120V AC 60Hz with the UL Standard 2021 for fixed and location dedicated electric room appliances in the United Watts 1000W Max States and Canada. If you need assistance NO HEATER 46W Max during installation, please contact your local... -
Page 11: Sym-74
SYM-74 Description This appliance has been tested in accordance Built-in Appliance Voltage 120V AC 60Hz with the UL Standard 2021 for fixed and location dedicated electric room appliances in the United Watts 1000W Max States and Canada. If you need assistance NO HEATER 50W Max during installation, please contact your local... -
Page 12: Sym-88
SYM-88 Description Built-in Appliance Voltage 120V AC 60Hz This appliance has been tested in accordance with the UL Standard 2021 for fixed and location Watts 1000W Max dedicated electric room appliances in the United NO HEATER 56W Max States and Canada. If you need assistance MOTOR HEATER during installation, please contact your local Appliance Width... -
Page 13: Sym-100
SYM-100 Description This appliance has been tested in accordance Built-in Appliance with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances in Watts 1000W Max the United States and Canada. If you need NO HEATER 60W Max assistance during installation, please contact... -
Page 14: Installation-Wall Mount
INSTALLATION-WALL MOUNT WALL MOUNT NOTE: Due to the many different materials used to build walls, it is highly rec NOTE: Due to the many different materials used to build walls, it is highly rec NOTE: Due to the many different materials used to build walls, it is highly recommended that you consult your local builder before you install this appliance on a wall. -
Page 15: Installation- Built-In
120 Volt grounded outlet. wer supply cord into a 120 Volt grounded outlet. The rough wall opening size of the fireplace: The rough wall opening size of the fireplace: W(“) D(“) H(“) SYM-34 33 3/8 SYM-42 43 1/4 SYM-50 51 1/4 SYM-60... - Page 16 3. Unscrew the 2 screws located on each side and take off the inner side steel panels. crews located on each side and take off the inner side steel panels. crews located on each side and take off the inner side steel panels.
- Page 17 4. Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make sure that the fireplace fits the wall opening well and there is no gap between sure that the fireplace fits the wall opening well and there is no gap between sure that the fireplace fits the wall opening well and there is no gap between the trim and...
- Page 18 6. Remove the trim following STEP 1. Screw back the inner side steel panels. Remove the trim following STEP 1. Screw back the inner side steel panels. Remove the trim following STEP 1. Screw back the inner side steel panels. 7.
-
Page 19: Hard-Wire Installation
HARD- WIRE INSTALLATION WIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. -
Page 20: Media Options
MEDIA OPTIONS The fireplace shipped with an ember log set that is pre fireplace shipped with an ember log set that is pre-installed and clear and clear. Consumers may purchase optional decorative media if they choose. See dealer for more details. ve media if they choose. -
Page 21: Operation
OPERATION The fireplace can be operated either by the The fireplace can be operated either by the touch panel located on the left located on the left front top side of the fireplace or by supplied remote control. y supplied remote control. Plug the fireplace into a 15 Amp wall socket. -
Page 22: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and the main power switch located on the bottom left hand side is at position I. Important: When operating the remote make sure you point the remote to the center of the fireplace each time you press the button. -
Page 23: Installing Wall Thermostat
INSTALLING WALL THERMOSTAT INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS WALL THERMOSTAT WIRING DIAGRAMS NOTE: The wall thermostat will be functioning when the heater is on the TEMP. setting. NOTE: The wall thermostat will be functioning when the heater is on the TEMP. setting. NOTE: The wall thermostat will be functioning when the heater is on the TEMP. -
Page 24: Replacement Parts
REPLACEMENT PARTS PART NUMBER DESCRIPTION SYM-34 SYM-42 SYM-50 SYM-60 10701358 10701359 10701346 10701347 FRONT GLASS 3200503 3201503 3202503 3203503 TRIM 10702224 10702225 10702210 10702211 EMBER BED GLASS FLAME EFFECT 10702217 10702218 10702219 10702220 GLASS 601141B 601141B 601141B 601141B LED STRIP FOR... - Page 25 REPLACEMENT PARTS PART NUMBER DESCRIPTION SYM-74 SYM-88 SYM-100 10701348 10701363 10701364 FRONT GLASS 3204503 3205503 3206503 TRIM 10702212 10702226 10702227 EMBER BED GLASS FLAME EFFECT 10702221 10702222 10702223 GLASS 601141B 601141B 601141B LED STRIP FOR FLAME 601142B 601142B 601142B 601136B 601136B 601136B LED STRIP FOR...
-
Page 26: Exploded View
EXPLODED VIEW... -
Page 27: Truble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary Back black cloth is falling off Change a new flicker and back and roll the flicker black cloth Ember bed is not Ember LED’s are burnt out Inspect the ember bed LED’s and... -
Page 28: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service Service Special Concerns Name Technician Name Performed NOTES:... -
Page 29: Warranty
Amantii warrants such products to be free from defects in material and workmanship for a period of two (2) years from the date of the first purchase of such products. The limited two (2) year warranty period for products also applies to any implied warranties that may exist under applicable law. Some...
