- Page 1 boomerBeast 2.0 standard / deluxe / d User Manual...
-
Page 2: About Daymak
Daymak warranties, services, and stocks parts for everything it sells. We support our prod- ucts. Please feel free to visit our website. You’ll nd the latest in cool transportation solutions,... - Page 3 Safety When operating the Boomerbeast please make sure you adhere to the following: Always check your mirrors and blind spots when operating through trails. Turn on headlights when in need of additional visibility. Make sure that your battery power is suffi cient before you go out to ride Do not ride with more than 1 passenger Do not over charge the battery by leaving the charger in the charging port.
-
Page 4: Scooter Part Diagrams
Scooter Part Diagrams Diagram 1: The Boomerbeast Electric Scooter 1. Mirrors Charging Port 15. Ignition 2. Brake Handle Motor 3. Turn Signals 10. Seat Adjust 4. Headlight 11. Trunk 5. Shocks 12. Charging Port 6. Tires 13. Seat 7. Foot Rests 14. - Page 5 Boomerbeast Operation Turning the Unit On Below the front display you will nd a key hole where you put the keys that have come with your Boomerbeast. 1) Turn the key to this position to turn the unit on. The Key cannot be removed while it is in the on position.
- Page 6 Driving the Boomerbeast Engaging the motor On the right handlebar is a throttle that must be rotated towards you (bring the back of your hand towards your body) The throttle is very sensitive so be sure to turn it slowly. Make sure that you are on the unit and can easily turn on the brakes (see below).
- Page 7 Engaging the Brake Lock The Boomerbeast has a brake lock that will prevent it from rolling even when parking the unit on a hill. To engage the brake lock do the following: 1) Pull the brake lever on the left hand side towards you as much as you can.
- Page 8 Boomerbeast Operation (cont’d) Turning on your unit Handlebars, on each unit you will nd a few buttons and switches. Here is what everything does. Left Handle Bar 1) High Beam / Low Beam - Toggle this switch to choose between a low or high angle of the headlights. (The headlight must be on for this to have an e ect) 2) Turn Signals - Push this to the left to indicate turning to the left and into the middle once your done.
- Page 9 Turning on your unit) Once you have done that, a speedometer will show up and you are ready to go! For more information on the Daymak Drive App, please refer to the quick guide seen here: http://daymak.com/manuals/Daymak%20Drive%20Manual.pdf Please note the Boomerbeast D has two controllers, so any changes to e ect one motor, will not e ect the other.
- Page 10 Boomerbeast Operation (cont’d) You will nd above the ignition a display that will show you your metrics and performance for your Boomer- beast. Display 1) Speed - This display shows you how fast you are going in km/h 2) Motor Power - This meter shows how much power is being drawn from the motor.
-
Page 11: Charging The Unit
Charging the unit After using your Boomerbeast, you will need to charge the unit. The Boomerbeast comes with a charger that you can use to plug into a regular outlet. (The deluxe unit charger looks di erent slightly but functions the same way). - Page 12 Remote / Alarm The Boomerbeast comes with a remote as well that has multiple functions. Here is what they do. 1) Panic Button - Press this button to set o the alarm. Use this in case of emergencies or to locate your vehicle. 2) Unlock Button - Press this button to disable the alarm.
- Page 13 Foot rests The Boomerbeast comes with extendable foot rests so you can choose your riding style. Using your feet push the foot rests towards the Boomerbeast and it will pop out. Reverse this process stick them to the sides of the Boomerbeast.
- Page 14 The Controller Daymak Drive Bluetooth Controller The Daymak Drive controller is what makes the unit do what it does when a function is press or a switch is switched. This controller is located underneath the seat. This should not be tampered with by consumers.
-
Page 15: Circuit Breaker
Accessing the controller / circuit breaker Behind the seat you will nd two bolts that lock the seat rest to the machine. Using an Allen Key, unscrew the two bolts seen below and lift the bar up to access the under seat compart- ment. - Page 16 Seat The Boomerbeast comes with a seat that has movable arm rests that can be moved up and down to get on and o the unit easier The seat can be slid either forward or backward slightly by holding the lever as shown above and pushing the seat either direction.
- Page 17 Rear Rack On the back of the Boomerbeast is the carrying rack. Use this to mount a case or store goods however you see t.
-
Page 18: Maintenance
Otherwise if possible bring the battery inside. Bring in your unit to your local Daymak dealer for a yearly check up if possible. Do not over charge the battery, once the battery is fully charged unplug it as soon as possible. - Page 19 Thank you for choosing Daymak...
