  • Page 1 MOBILITY SCOOTER Boomerbuggy – Super Transporter OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY GUIDELINES ……..………………………………………..…..…... 2 SAFETY NOTICE…………………………………………………………...….. 3 PARTS INTRODUCTION……………………………………………..………. 9 OPERATION…………………………………………………………………..10 BATTERY CHARGING AND CARE………………………………………..18 INSPECTION AND MAINTENANCE……………………………………..… 22 TROUBLE SHOOTING AND SPECIFICATION…………….……………… 24 INTENDED USE Maximum safe slope: 10° The product is not intended for visually impaired people. The drivers need to be mentally and physically suitable to drive the scooter.

  • Page 3: Safety Guidelines

    I . S A F E T Y G U I D E L I N E S Please carefully read this owner’s manual before using the scooter. Improper use of the scooter could result in harm, injury or traffic accidents. Therefore for maximum pleasure while using the scooter please read this owner’s manual.

  • Page 4: Safety Notice

    2 . S A F E T Y N O T I C E GENERAL MANDATORY! Do not operate your new Scooter for the first time without ompletely reading and understanding this owner’s manual and the Consumer Safety Guide. Your Scooter is a state-of-the-art life-enhancement device designed to increase mobility. We provide an extensive variety of products to best fit the individual needs of the Scooter user.
  • Page 5 2 . S A F E T Y N O T I C E WHILE DRIVING ■ Please carry out daily inspections. Refer to the section entitled “DAILY CHECKING” ■ Do not move your body out of the scooter while moving ...
  • Page 6 2 . S A F E T Y N O T I C E ■ Starting and Driving 1. Make sure the seat is installed properly. 2. Make sure the tiller has been secured properly. 3. Fold down the armrests so you can rest your arms on them. 4.
  • Page 7 ▓ Motor Vehicle Transport Daymak recommends that you do not remain seated in your scooter while traveling in a motor vehicle. The scooter should be stowed in the trunk of a car or in the back of a truck or van with the batteries removed and properly secured.
  • Page 8 1. WARNING EMI LABEL………………………………………… 2. FREEWHEEL LABEL…………………………………….……….. 3.SEAT PINCH WARNING LABEL......2 . S A F E T Y N O T I C E This portion of the content will provide the user with basic information that describes the problems with EMI, known sources of EMI, protective measures either to lessen the possibility or exposure or to minimize the degree of exposure, and suggested action should unexpected or erratic movement occur.
  • Page 9 Caution: It is very important that you read this information regarding the possible effects of electromagnetic interference on your electric scooter. ■ ELECTROMAGNETIC INTERFERENCE (EMI) FROM RADIO WAVE SOURCES Powered scooter may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones.

  • Page 10: Parts Introduction

    3 . PA R T S I N T R O D U C T I O N PARTS DESCRIPTION 1. Power switch 2. Charger Socket Cover 3. Tiller Extend Lever 4. Tiller Angle Adjust Lever 5. Separate Frame safety Lever 6.

  • Page 11: Operation

    4 . O P E R AT I O N 4.1 CONTROL PANEL 1. Battery Level Indicator 2. Forward / Reverse Selector PROHIBITED! Do not expose the tiller console to moisture. In the event that the tiller console does become exposed to moisture, do not attempt to operate your Scooter until the tiller console has dried thoroughly.
  • Page 12 4 . O P E R AT I O N ■ Braking  Release the speed control lever freely while either going forward or reverse, and the electromagnetic brake in the motor will be activated, and the scooter will stop. YELLOW GREEN ■...
  • Page 13 4 . O P E R AT I O N ▓ How To Set Freewheel Mode Whenever you need or want to push your Scooter for short distances, you can put it in freewheel mode. 1. Locate the manual freewheel lever at the top right of the rear section. 2.
  • Page 14 4 . O P E R AT I O N ■ Tiller Adjustment The tiller can be adjusted in to many different positions to suit each driver. 1. Loosen the lever to adjust the tiller to positions you want. 2. Once decide the position, tighten the lever to secure the tiller. WARNING! Remove the key from the key switch before adjusting the tiller or the seat.

  • Page 15: Battery Pack

    4 . O P E R AT I O N ■ Main Circuit Breaker (Reset Button) When the voltage in your Scooter’s batteries becomes low or the Scooter is heavily strained because of excessive loads or steep inclines, the main circuit breaker may trip to protect the motor and electronics from damage.
  • Page 16 4 . O P E R AT I O N ■ Disassembling The Scooter WARNING! To avoid personal injury, ask for assistance, if necessary, while disassembling or assembling your scooter. Please follow the steps. 1. Turn key switch to “OFF”. 2.
  • Page 17 4 . O P E R AT I O N 4. pick up the frame separatly with handle bar and fold the rear frame. 5. push the tiller adjustment knob and fold tiller. Push 6. Loosen the tiller adjustment lever and fold down the tiller and retighten lever.
  • Page 18 4 . O P E R AT I O N ■ Assembling The Scooter No tools are required to disassemble or assemble your scooter. 1. Push the tiller adjustment knob Set the tiller angle. 2. Pull the Separate Frame safety Lever to unfolded. Pull 3.

  • Page 19: Battery Charging And Care

    5 . B AT T E RY C H A R G I N G A N D C A R E ■ CHARGING THE BATTERY Follow the procedure below step by step: 1. Turn the power switch to (OFF) 2.
  • Page 20 5 . B AT T E RY C H A R G I N G A N D C A R E ■ BATTERY  Do not expose the battery to temperatures below 10°C or above 50°C when charging or storing the scooter.
  • Page 21 5 . B AT T E RY C H A R G I N G A N D C A R E PROHIBITED! Removal of grounding prong can create electrical hazard. If necessary, properly install an approved 3-pronged adapter to an electrical outlet having 2-pronged plug access.
  • Page 22 ■ Cleaning the battery If the batteries are contaminated by water, battery acid, dust or other substances, they will discharge quickly. The batteries supplied with the Daymak scooter are sealed and as such are maintenance free with no risk of battery leakage.

  • Page 23: Inspection And Maintenance

    6 . I N S P E C T I O N A N D M A I N T E N A N C E ■ INSPECTION  Clean the scooter with a damp cloth and dust down approximately once a week to preserve the appearance of the scooter.
  • Page 24 6 . I N S P E C T I O N A N D M A I N T E N A N C E ■ Tires The condition of the tires depends on how you drive and use your scooter. ...

  • Page 25: Trouble Shooting And Specification

     Tighten the height adjustment handle to secure the The handlebar appears loose handlebar  Ensure that the wigwag paddle is released. Involuntarily horn sounds  Switch the scooter off and on.  Recharge the batteries.  If problem persists contact your Daymak dealer.
  • Page 26 7. T R O U B L E S H O O T I N G A N D S P E C I F I C AT I O N ▓ SPECIFICATION Boomerbuggy – Super Transporter Model Reference Expand Dimension (L x W x H mm) 47.2"...
