- Page 1 Boomerbeast Deluxe and Ultimate User Manual...
- Page 2 Daymak warranties, services, and stocks parts for everything it sells. We support our prod- ucts. Please feel free to visit our website. You’ll find the latest in cool transportation solutions,...
- Page 3 Safety When operating the Boomerbeast please make sure you adhere to the following: Always check your mirrors and blind spots when operating through trails. Turn on headlights when in need of additional visibility. Make sure that your battery power is sufficient before you go out to ride Do not ride with more than 1 passenger Do not over charge the battery by leaving the charger in the charging port.
-
Page 4: Scooter Part Diagrams
Scooter Part Diagrams Diagram 1: The Boomerbeast Electric Scooter 1. Controller Rack 15. Shocks 2. Throttle Tires 16. Turn Signals 3. Tablet Charging Port 10. Ball Hitch 17. Headlights 4. Tablet / Mount 11. Motor (rear) 18. Brakes 5. Ignition 12. - Page 5 Boomer Beast Operation Mounting your tablet The Boomerbeast comes wiht a tablet mount that allows you to attach a tablet that gives you speed, distance travelled and allows you to configure the performance infront of you. The Mounting brackets come with 4 pieces. Piece A Piece B Piece C...
- Page 6 Take the two pieces from Piece C and screw each one on the screws tightly to lock the tablet holder in place. Take the Piece D, and align the four holes to match the four pegs from Piece B. Once they are in, push either up or down (depending on where you mounted it) until it clicks into place.
- Page 7 Connecting your Tablet to your Unit Connecting via Bluetooth Turn on your tablet with the signle button on the right hand side and hold it for 3 seconds. Once it has turned on click on the Daymak Drive Bluetooth App.
- Page 8 Turning on your unit) Once you have done that, a speedometer will show up and you are ready to go! For more information on the Daymak Drive App, please refer to the quick guide seen here: http://daymak.com/manuals/Daymak%20Drive%20Manual.pdf Please note the Boomerbeast Beast Ultimate has two con- trollers, so any changes to effect one motor, will not effect the other.
- Page 9 Boomer Beast Operation (cont’d) Driving your unit Once you have your Boomerbeast set up and connected. It’s time to ride! Right Handlebar 1) Throttle - Turn this toward you to engage the motor and to propell the unit forward. Do this very slowly at first until you get the feel of how quickly it goes.
- Page 10 Brakes On both sides of the handlebar there are brake levers as seen on the right. To engage the brakes, pull the brake lever towards you. The right brake lever activates the front brakes The left brake lever activates the rear brakes Brake lock To engage the brake lock, first pull the brake lever towards you as you would nor-...
- Page 11 The Battery The Boomerbeast Deluxe / Ultimate come with a solar powered lithium ion battery case. This allows the unit to trickle charge the bike while it is out in the sun for addi- tional range and battery longevity. To take it out of the battery, on the right hand side there is a lock in which you can put your key into.
- Page 12 The Battery (cont’d) The Boomerbeast battey can function completly on its own whether you want to use it as a power bank or charge it in or outside of your home. 1) External Charging Port - This is the charging port if you want to charge the battery outside of this unit.
- Page 13 The Battery Charging Your Unit If you are charging the Boomerbeast directly in the frame there is a chargeport to the left near the front of the unit that is covered by a plastic flap. To begin charging, take the charger and plug it into a 110V wall outlet.
- Page 14 The Controller Daymak Drive Bluetooth Controller The Daymak Drive controller is what makes the unit do what it does when a function is press or a switch is switched. This controller is located underneath the seat covered by a black panel. This should not be tampered with by con- sumers.
-
Page 15: Rear Rack
Mirrors The Boomerbeast comes with a set of mirrors that screw on each handlebar. Screw each mirror into the appropriate side (left mirror on left side etc). Until it is loosely in the position you want. Then take a wrench and tighten the bolt at the bottom of the mirrors to make it stick in that position. - Page 16 The Seat King Seat The Boomerbeast comes with an adjustable King seat with arm rests. 1) Arm Rests - Raise these up or down as you see fit. Set it however makes you the most comfortable. 2) Back Rest Angle - Pull this lever up and push the back rest of your chair to set it to the angle that is most comfort- able for you.
- Page 17 Otherwise if possible bring the battery inside. Bring in your unit to your local Daymak dealer for a yearly check up if possible. Do not over charge the battery, once the battery is fully charged unplug it as soon as possible.
- Page 18 Thank you for choosing Daymak...
