Sun Microsystems StorEdge D2 Array Best Practices Manual page 56

64...67 0x40
68...71 0x44
72 0x48
73 0x49
74 0x4A
75 0x4B
76...77 0x4C
78...79 0x4E
80...83 0x50
84 0x54
85...86 0x55
87 0x57
88...131 0x58
SCSI ID Mapping This field determines the configuration used to assign SCSI IDs to
the drive slots. The D2 default is set to 0x02 and is the only supported value. This
value indicates a 12-drive configuration. If a value other than 0x02 is downloaded to
this field, a CHECK CONDITION is generated with sense information indicating
ILLEGAL REQUEST- INVALID SEP COMMAND IN WRITE BUFFER DATA
PACKET. (Sense key = 05h, ASC = 26, ASCQ = 02).
ENCSER (Enclosure Service) (D2 default bit is clear) This bit defines the value of
the Enclosure Service bit (ENCSER) in the standard INQUIRY command response
data (byte 6, bit 6). If set to 1, it indicates that the target returns Enclosure Services
Information (ESI) as a result of a RECEIVE DIAGNOSTIC COMMAND. If set to 0x00
and a RECEIVE DIAGNOSTIC RESULTS is issued requesting a supported SES
Diagnostic page, the requested page is returned without any error condition.
BKD (Backpanel VPD) - (D2 default bit is set) If it is set to 1, VPD page 1
(Midplane VPD data) is supported.
7-2 Sun StorEdge D2 Array Best Practices Guide • January 2002
4 Voltage 3: Threshold Data (Not Supported)
4 Voltage 4: Threshold Data (Not Supported)
1 Over-Temperature Failure Level
1 Over-Temperature Warning Level
1 Under-Temperature Warning (Not Supported)
1 Under-Temperature Failure
2 Fan Parameter – Low Trip Point (RPM)
2 Fan Parameter – Reporting
4 Diagnostic Parameters – RQST FAIL
Reporting (Not Supported)
1 SCSI ID Mapping
2 Configuration Parameters
1 0
44 Reserved
(Not Supported)
(Not Supported)
0xFF
0xFF
0x4C
0x44
0x00
0x00
0x384
0x01F4
0xFF
0x02
0xFF
0
0xFF
