Advantech B+B SmartWorx 232USB9M Quick Start Manual page 2

Troubleshooting
One USB port is required for each installed
device. The USB port can be native to the PC or it
can be a USB port on a USB hub that is
connected to a PC.
The device works with USB 1.1 or 2.0 ports. But it
has a maximum USB data rate of 12 Mbps.
To verify the installation you may open the
Windows Device Manager Scroll down to Ports.
Expand the flyout window. You should see the
new ports. If there are no exclamation points or
other trouble indicators ports are installed
correctly and ready for use.
Are My Devices Wired As DTE or DCE?
(How to Check)
1. Use Rule of Thumb
If the device plugs into the computer serial
port and works normally, the device is wired
as DCE (or the connection cable is a crossover
type that makes it work as a DCE). If the device
connects to the computer port using a "null
modem" crossover cable, it is wired as DTE.
2. Use RS-232 Line Tester
A quick and easy way to determine the DTE/DCE port
type is to use a RS-232 line tester
such as the 9PMTT. The tester can show the signal state
of any active RS-232 data lines using LEDs lighting Red
or Green. Active data lines are
output from a device. They may be either
High or Low.
Document number – 710-10879-00_232USB9M-xx_3216qsg
Recommended Accessories
9PAMF6
6ft DB9 to DB9 Cable
Male to Female
USBAMBM-6F
6ft USB Cable
1-888-948-2248 | Europe: +353 91 792444
www.advantech-bb.com
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.advantech-bb.com | E-mail: support@advantech-bb.com
QUICK START
GUIDE
232USB9M/232USB9M-LS
USB to RS-232
Mini Converter
Before you begin, be sure you have
the following:
+
232USB9M/232USB9M-LS
+
USB Cable
+
CD-ROM with Drivers
www.advantech-bb.com
Fast and easy on the web:
