- Page 1 Drawing : TPC465 Issue Date : 05/01/2017 DD3000 460V / 3PH / 60HZ INDUSTRIAL DEHUMIDIFIER OWNER’S MANUAL www.eipl.co.uk...
- Page 2 The DD3000 is of the desiccant wheel type designed to dry air by passing a large volume of air, the “process” air through a slowly rotating Silica gel rotor.
-
Page 3: Specifications
Drawing : TPC465 Issue Date : 05/01/2017 SPECIFICATIONS : DD3000 ODEL : 1400mm (55.1“) EIGHT : 2000mm (78.7“) IDTH : 1000mm (39.4“) EPTH : 505Kg (1113 lbs) EIGHT : 460V, 3 ph, 60Hz OWER UPPLY 28 kW (max) OWER : 3500m³/hr (2060 cfm) -
Page 4: Unit Capacity
Drawing : TPC465 Issue Date : 05/01/2017 UNIT CAPACITY The ambient conditions of the area to be dehumidified will determine the amount of water extraction the unit is cable of. Measure the ambient conditions of the area to be determined and then use that information with the following capacity diagram to determine the unit capacity. -
Page 5: Installation
Date : 05/01/2017 INSTALLATION The DD3000 is designed for indoor use. The unit should be placed on a level surface and a space of 1 meter free around all faces to allow access for any duct work and servicing. Connecting duct work: The regeneration outlet must be ducted to outside the area being dehumidified. - Page 6 Drawing : TPC465 Issue Date : 05/01/2017 Control Settings Once the unit is positioned correctly, required duct work attached and the power supply connected, the process fan speed and temperature control need to be set correctly. The fan speed control is located within the main electrical control. The controls are numbered 1 to 10, with 10 being the maximum speed.
- Page 7 Drawing : TPC465 Issue Date : 05/01/2017 FAN PERFORMANCE CURVES For example: If the total system resistance is 600pa then the process fan selector would have to be set to No 5 to achieve the required airflow of 3000m³/h (1766 cfm) For example:...
-
Page 8: Operation
Drawing : TPC465 Issue Date : 05/01/2017 If the total system resistance is 800pa then the regen airflow will be 750m³/h (441 cfm). Adjustment of the damper may be required to achieve the required regeneration airflow. OPERATION The electrical controls are located on the front of the unit. They are: ISOLATOR •... - Page 9 Drawing : TPC465 Issue Date : 05/01/2017 High Temperature Cut-Out: The DD 3000 dehumidifier has been designed to work in ambient conditions of -20ºC to +40ºC. Should the temperature in the room become excessive a manual overheat protector will operate, switching off the heaters. The fans and drive motor will continue to operate but the HIGH TEMPERATURE fault lamp will illuminate.
- Page 10 Drawing : TPC465 Issue Date : 05/01/2017 SAFETY -WARNING- ♦ DO NOT ALLOW CHILDREN TO PLAY WITH OR AROUND THE UNIT. ENSURE THE UNIT IS INACCESIBLE TO CHILDREN WHEN NOT ATTENDED. ♦ DO NOT USE THIS UNIT IN AN ENVIRONMENT CONTAINING FLAMMABLE FUMES ♦...
- Page 11 Drawing : TPC465 Issue Date : 05/01/2017 ROUTINE SERVICE & REPAIR WARNING: ENSURE THAT THE POWER CORD TO THE MACHINE HAS BEEN DISCONNECTED BEFORE CARRYING OUT ROUTINE SERVICE. THE SERVICING AND REPAIR OF THIS UNIT SHOULD ONLY BE CARRIED OUT BY A SUITABLY QUALIFIED PERSON.
-
Page 12: Troubleshooting
Drawing : TPC465 Issue Date : 05/01/2017 Should an electrical component fail, consult the Factory Service Center • to obtain the proper replacement part. F ANY OF THE PRECEDING PROBLEMS OCCUR CONTACT THE NDUSTRIAL RODUCTS ERVICE ENTER PRIOR TO CONTINUED OPERATION OF THE UNIT TO PREVENT PERMANENT DAMAGE TROUBLESHOOTING YMPTOM... - Page 13 Drawing : TPC465 Issue Date : 05/01/2017...
- Page 14 Drawing : TPC465 Issue Date : 05/01/2017 WARNINGS This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved.
- Page 17 Virginia, 23606-2575 D-13599, Berlin DL14 9AD Germany Tel: +44 (0) 1388 664400 Tel: +01 757 873 6800 Tel: +49 3043 557241 Fax: +44 (0) 1388 662590 Fax: +01 757 873 3632 Fax: +49 3043 557240 www.eipl.co.uk www.ebacusa.com www.eip-ltd.de sales@eipl.co.uk sales@ebacusa.com sales@eip-ltd.de...
