2.3 Installing the Microphone

2.3.1 Using the Attachable Boom Microphone
1. Attach the hook and loop fastener for attachable boom microphone
on the inside surface of the left external shell.
2. Attach the attachable boom microphone's mounting plate to the
hook and loop fastener.
3. Adjust the head of the microphone so that the tab is facing away
from your mouth.
4. Align the arrows on the microphone and speaker cables and
insert the microphone cable into the speaker cable.
5. Insert the speaker connector into the speaker port to connect it
to the main unit.
6. Close the cover of the speaker cable to lock the cable to the port.
Note:
You can use the boom microphone holder after attaching the hook and loop
fastener for boom microphone holder on it to ensure secure installation.
8
1
2
4
6
3
Tab
5
Note
2
