10C Evo
10C Evo Manual
Motorcycle Bluetooth Communication & Camera System

1. Turning On/Off the Headset

To power on the headset, press the Jog Dial and the Phone Button at the same time until the blue LED
appears. To power off the headset, press the Jog Dial and the Phone Button at the same time until the
red LED appears briefly.

2. Adjusting Volume

You can easily adjust the volume by rotating the Jog Dial.

3. Checking the Battery Level

When the headset is powering on, the red LED flashes rapidly indicating the battery level.
4 flashes = High, 70~100%
3 flashes = Medium, 30~70%
2 flashes = Low, 0~30%
When you power on the headset, keep pressing the Jog Dial and the Phone Button simultaneously for
about 3 seconds until you hear high tone triple beeps. Then you will hear a voice prompt indicating the
battery level is high, medium, or low.

4. Charging the Battery

You can charge the headset by connecting the supplied USB power & data cable into a computer's USB
port or USB wall charger. The LED turns red while the headset is charging and turns blue when it is fully
charged. It takes about 3.5 hours to be completely charged.

5. Pairing with Mobile Devices - Phone, Music

1. Press and hold the Phone Button for 5 seconds until the LED flashes red and blue alternately and you
hear multiple beeps.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10C Evo and is the answer not in the manual?

Questions and answers

Summary of Contents for Sena 10C Evo

  • Page 1 10C Evo 10C Evo Manual Motorcycle Bluetooth Communication & Camera System 1. Turning On/Off the Headset To power on the headset, press the Jog Dial and the Phone Button at the same time until the blue LED appears. To power off the headset, press the Jog Dial and the Phone Button at the same time until the red LED appears briefly.
  • Page 2 2. Search for Bluetooth devices on your mobile phone. Select the Sena 10C Evo in the list of the devices detected on the mobile phone. 6. Using Phone Features Answering Calls: Tap the Phone Button or the Jog Dial to answer the call.
  • Page 3 “Camera setup”. 18. Factory Reset If you want to restore the 10C EVO to factory default settings, press and hold the Phone Button for 10 seconds. Tap the Jog Dial. The headset automatically restores the default settings and turns off.
  • Page 4 padding and external shell of the left side of the helmet. 3. Tighten the two screws until the clamp unit is fastened firmly to the helmet. 4. Insert a microSD card into the card slot to use camera. 5. Attach the main unit to the clamp unit until you hear a click. Note: This device can be weared on the head of human with separation distance of 5mm...
  • Page 5 FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 6 IC Caution: - English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
