Checks before Installation

Accessories

Wi-Fi Kit
User & installation manual
• The Wi-Fi Kit must be installed by a certified technician.
CAUTION
• Before installation, be sure to cut off power.
• Follow applicable rules for electrical wiring. Make sure that the cables of the Wi-Fi Kit are installed
inside a wall or covered to avoid being touched by the occupant.

External Dimensions

SOL OCF Wi-Fi KIT 구통신 유럽향 IBIM_EN_DB68-08417A-00_.indd 5
Cable ties (2)
U-type terminals (6)
185
Cable clamps (3)
M4×16 screws (5)
29
Unit: mm
5
2019-06-21 오후 4:11:42
