WEIHONG NcEditor V12 Manufacturer's Manual

Laser cutting cnc system
Hide thumbs Also See for NcEditor V12:
Table of Contents

Advertisement

Quick Links

NcEditor V12 Laser Cutting CNC System
1
CNC System Installation ............................................................................................................... 2
1.1
Install Hardware ............................................................................................................ 2
1.2
Install Software ............................................................................................................... 6
1.3
Install Driver .................................................................................................................... 9
1.4
Install a Camera ........................................................................................................... 12
2
Interface Overview ...................................................................................................................... 14
2.1
Toolbar ............................................................................................................................ 16
2.2
Drawing Window ........................................................................................................ 17
2.3
Running Information Bar ......................................................................................... 18
2.4
Window Display Buttons ......................................................................................... 19
2.5
Machine Control Area ................................................................................................ 19
2.6
Status Bar ....................................................................................................................... 25
2.7
Drawing Toolbar ......................................................................................................... 26
2.8
3D View Area ................................................................................................................ 26
3
Machine Tool Commissioning ................................................................................................. 28
3.1
Modify Port Polarity................................................................................................... 28
3.2
Set Drive Parameters ................................................................................................. 28
3.3
Adjust Pulse Equivalent and Electronic Gear Ratio ....................................... 50
3.4
Set Speed Parameters ................................................................................................ 52
3.5
Adjust the Axis Direction ......................................................................................... 52
3.6
Set the Workbench Stroke ....................................................................................... 53
Manufacturer Manual
上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD.
Version: 2019.3 1st Version
Author: Document Department
Weihong Corporation, All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NcEditor V12 and is the answer not in the manual?

Questions and answers

Related Manuals for WEIHONG NcEditor V12

Summary of Contents for WEIHONG NcEditor V12

  • Page 1: Table Of Contents

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. NcEditor V12 Laser Cutting CNC System Manufacturer Manual Version: 2019.3 1st Version Author: Document Department Weihong Corporation, All Rights Reserved CNC System Installation ....................... 2 Install Hardware ......................2 Install Software ....................... 6 Install Driver ........................
  • Page 2 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Compensate Lead Screw Errors ................53 Set Parameters of Air Pressure and Laser Device .......... 56 Check Machine Tool Setting ..................58 Follow-up ............................61 Interface Overview ..................... 61 Commissioning Steps ....................69 List of Parameters .......................
  • Page 3 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. NcEditor V12 Laser Cutting CNC System is independently developed by Weihong Electronic Technology Co., Ltd., with copyright reserved. This manual is intended for manufacturers of machine tools. It mainly includes the following: •...

  • Page 4: Cnc System Installation

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1 CNC System Installation This section introduces how to install NcEditor V12 Laser Cutting CNC System, including the following: • Install hardware • Install software • Install driver • Optional: Install a camera 1.1 Install Hardware...
  • Page 5 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.1.2 Connect Hardware To connect hardware, see the following wiring diagrams: • In position loop control mode 3 / 144...
  • Page 6 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • In velocity loop control mode W-axis refers to the focus axis and B-axis refers to the rotation axis. To avoid being confused with Y-axis in plane cutting configuration, Y-axis in tube cutting configuration is U-axis.
  • Page 7 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.1.3 Install Motion Control Card NcEditor V12 Laser Cutting CNC System uses PM95A motion control card to mate with NcEditor software, so as to control laser cutting rapidly and accurately. Before installing motion control card, check whether the computer meets the requirement according to the following list: •...

  • Page 8: Install Software

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.2 Install Software This section introduces how to install software of NcEditor V12 Laser Cutting CNC System, hereinafter referred to as NcEditor software. Before installing the software, note the following: • There must be a D disk in your computer, otherwise the installation will fail.
  • Page 9 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. According to the prompt, click OK to delete files of the old version software and avoid interfering the installation of the new version software. Select one of the following parameter migration method and click Next: –...
  • Page 10 According to the prompt, click Yes to reboot the computer at once. If you need to uninstall the software, do the following: Delete NcEditor folder under directory C:\Program Files\Weihong. Delete NcEditor shortcut on the desktop. 8 / 144...

  • Page 11: Install Driver

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.3 Install Driver This section introduces how to install driver to match the software with the hardware. To install driver, do the following: • Automatically install driver. • Manually install driver. During installing NcEditor software, the system automatically installs driver. If the system failed to automatically install driver, you can manually install it.
  • Page 12 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.3.2 Manually Install Driver After installing NcEditor software and motion control card, if the software cannot be opened and one of the following dialog boxes pops up, it indicates that the system may fail to automatically install driver. After eliminating problems such as the motion control card loosens, you can manually install driver to solve the problem.
  • Page 13 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. – If it is not your first time to update the driver: Find an INF configuration file as follows: The folder is under directory C:\ProgramFiles\Weihong\NcEditor\Addins. 11 / 144...

  • Page 14: Install A Camera

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Click Install this driver software anyway in Windows Security dialog box: 1.4 Install a Camera This section introduces how to install a camera and enable camera function, so as to monitor the machining condition and control machining.
  • Page 15 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. To link the camera and the computer, set the computer address according to the information of the camera: The first three parts of IP address, subnet mask and default gateway should be the same with those of the camera, and the last part of IP address should be different from that of the camera.

  • Page 16: Interface Overview

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2 Interface Overview NcEditor V12 Laser Cutting CNC System includes the following interfaces: • Interface of sheet cutting configuration Used to cut sheets. It is shown as follows: 14 / 144...
  • Page 17 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • Interface of tube cutting configuration Used to cut tubes. It is shown as follows: Menu bar Toolbar Drawing window Running information bar Window display buttons Machine control area Status bar Drawing toolbar...

  • Page 18: Toolbar

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2.1 Toolbar It is used to show frequently used instructions. It differs in the number of selected objects: • If no object is selected, it shows the following: – : New Used to create a new file.

  • Page 19: Drawing Window

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. – : Catch Used to enable/disable catching function. – : Catch option Used to catch option. • If one or more objects are selected, it shows related information of the objects and the following buttons: –...

  • Page 20: Running Information Bar

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2.3 Running Information Bar It is used to show running status and alarms of the machine tool. It includes the following: • Report bar • Alarm bar 2.3.1 Report Bar It is shown as follows: You can check the following: •...

  • Page 21: Window Display Buttons

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • To check causes and solutions of alarms, click Warnings. • To check alarm type, click 2.4 Window Display Buttons It is used to show/hide the following windows: • Sheet cutting configuration: machine control area.
  • Page 22 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2.5.1 Axis Coordinate Display Area It is used to show the following: • Workpiece coordinates • Machine coordinates Compared with sheet cutting configuration, W-axis is added in tube cutting configuration. This part takes sheet cutting configuration as an example:...
  • Page 23 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2.5.3 Manual Control Area It is used to move the machine tool manually. Compared with sheet cutting configuration, B-axis is added in tube cutting configuration. This part takes sheet cutting configuration as an example: •...
  • Page 24 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. – Step mode Click an axis direction button. The machine tool moves the customized step size. The default customized step size is 5mm. To customize the step size, double click the feed mode button. The value should not be too large to avoid damage due to misoperation.
  • Page 25 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • : Breakpoint resume Used to resume machining from the exact interrupted position when the power interruption or e-stop occurs and the workpiece origin is secured. • : Simulation Used to execute simulation to check the toolpath in real-time.
  • Page 26 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • : Go forward Used to control the machine tool to move along the toolpath towards positive direction. • : Go backward Used to control the machine tool to move backward along the toolpath towards negative direction.

  • Page 27: Status Bar

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • : Lead light Used to turn on red light manually, which is a kind of guide light. Red light is used to point out the position of laser on the sheet. •...

  • Page 28: Drawing Toolbar

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2.7 Drawing Toolbar It is used to do the following: • Draw objects • Execute auxiliary editing operations • Execute basic editing operations • Set technics • Set layers • Nest toolpaths •...
  • Page 29 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • : Zoom in Used to mnake the view appear larger. • : Zoom out Used to make the view appear smaller. • : Best view Used to adjust 3D view area to the best size, so as to check the toolpath effect.

  • Page 30: Machine Tool Commissioning

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3 Machine Tool Commissioning This section mainly introduces how to do commissioning for the machine tool. Before commissioning, click System → Configs and select the proper configuration. The machine tool commissioning includes the following: •...
  • Page 31 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. When setting drive parameters of brands which are not mentioned in this section, do the following: • Confirm the SON signal type of selected drive and ensure it is active low, i.e., servo is ON when SON and GND of 24V power is conducted.
  • Page 32 Pr528 LED Initial Status Used to monitor if the number of sent and received pulses is correct. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine whether there is electrical interference.
  • Page 33 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Pr102 1st Velocity Loop Integrated Time Constant Unit: 0.1ms Set according to the actual machining situation. Default value: 210 Relationship among parameters Pr008, Pr009 and Pr010 Pr008 Pr009 Pr010 Description Invalid Invalid As shown above, the process is undergone in terms of the set value of Pr008, and no affected by the settings of Pr009 and Pr010.
  • Page 34 Monitor if the number of sent and received pulse is correct by setting this parameter. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine whether there is electrical interference.
  • Page 35 Example: when pulse equivalent is 0.001, pitch 10mm, without reducer, sets the parameter to 2500; when pitch 5mm, set it to 1250. Range: [16, 214] Set value: Set according to PG divider ratio (Weihong system). Pn202 Electronic Gear Ratio (Numerator), Electronic Gear Ratio (Denominator)
  • Page 36 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. YASKAWA Σ-Ⅴ/Σ-7 Servo Drive Fn010 Parameter Input Prohibition Setting If it is set to “0000”, modification to user parameters “PnXXX” and part of auxiliary function parameters “FnXXX” is permitted. If it is set to “0001”, modification to user parameters “PnXXX” and part of auxiliary function parameters “FnXXX”...
  • Page 37 Monitor if the number of sent and received pulse is correct by setting this parameter. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine whether there is electrical interference.
  • Page 38 Monitor if the number of sent and received pulse is correct by setting this parameter. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine whether there is electrical interference.
  • Page 39 Example: when pulse equivalent is 0.001, pitch 10mm, without reducer, set this parameter to 2500; when pitch 5mm, set it to 1250. Set value: set it according to PG divider ratio (Weihong system). Relationship among parameters Pr0.08, Pr0.09 and Pr0.10 Pr0.08...
  • Page 40 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Fuji FALDIC-β Servo Drive 01 Command Pulse Numerator α, 02 Command Pulse Denominator β Equal to numerator/denominator of electronic gear ratio. Calculation formula: **α/β = (Encoder resolution * Pulse equivalent * Mechanical reducer ratio)/ Screw pitch Example: encoder resolution 65536, pitch 5mm, pulse equivalent 0.001, mechanical...
  • Page 41 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 27 Parameter Write-protection Whether drive parameters can be modified. 0: write-enable 1: write-protected 74 CONT Always ON 1 When it is set as “1”, servo is activated (RUN). Set value: 1 Fuji ALPHA 5 Servo Drive...
  • Page 42 Monitor if the number of sent and received pulse is correct by setting this parameter. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine if there is electrical interference.
  • Page 43 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. P1-01 Control Mode Setup Format: ZYX1X0 Z=0: during control mode switching, DIO is maintaining the set value. Since switching control mode is not used, Z=0. Y=0: forward rotation (CCW) (in terms of load).
  • Page 44 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. P2-15 Digital Input Pin DI6, P2-16 Digital Input Pin DI7 Default factory setting of DI6 and DI7 are NC (normally closed) limit signal input pins. Drive cannot run without being connected to pin 32 and pin 31 of CN1.
  • Page 45 Monitor if the number of sent and received pulse is correct by setting this parameter. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine whether there is electrical interference.
  • Page 46 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Set value: set it according to PG divider ratio (Weihong system). P2-10 Digital Input Pin 1 (DI1) Format: X2X1X0 X1X0=01: digital input (DI1 = SON) corresponds to 9th pin of CN1. X2=1: set DI1 input as NO (normally open) a-contact point.
  • Page 47 Monitor if the number of sent and received pulse is correct by setting this parameter. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine whether there is electrical interference.
  • Page 48 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Set value: 00 P1-44 Electronic Gear Ratio (Numerator)(N1), P1-45 Electronic Gear Ratio (Denominator)(M) Range: [1, 32767] Calculation formula: P1-44/P1-45 = (Encoder resolution * Pulse equivalent * Mechanical reducer ratio) / Pitch screw Example: encoder pulses=2500, pitch =5mm, pulse equivalent=0.001, reducer ratio = 1: N1 / M = 2500×4×0.001/5 = 2/1.
  • Page 49 Monitor if the number of sent and received pulse is correct by setting this parameter. In Weihong control system, the correct quantity of pulse sent by control card is detected by pulse inspection to determine whether there is electrical interference.
  • Page 50 Range: [20, 40000] Example: pulse equivalent = 0.001mm/p, pitch=10mm, without reducer, set this parameter to 10000; when pitch=5mm, set it to 5000. Set value: set it according to PG divider ratio (Weihong system). P2-10 Digital Input Pin DI1 Format: X2X1X0 X1X0=01: digital input (DI1 = SON) corresponds to 9th pin of CN1.
  • Page 51 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. P2-17 Function Setting for Digital Input Pin DI8 Format: X2X1X0 X2X1X0=000: external EMG stop input is not used. Set value: 000 P2-18 Function Setting for Digital Output Pin DO1 DO1 corresponds to pin 6 & pin 7, used as clamping-position brake signal of Z-axis.

  • Page 52: Adjust Pulse Equivalent And Electronic Gear Ratio

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3.2.2 Set Drive Parameters (in Velocity Loop Control Mode) This operation is used to set parameters of the following servo drives in velocity loop control mode: • WISE servo drive • YASKAWA Σ-7 servo drive •...
  • Page 53 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Electronic gear ratio The ratio represents servo scales up or down the pulse frequency sent by CNC system. If the value is greater than 1, it means scaling up and vice versa. Pitch The moving distance per revolution of the motor.

  • Page 54: Set Speed Parameters

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • Rotary axis – Stepper motor: Pulse equivalent = 360 / (360/Step angle * Subdivision * Mech anical reducer ratio) – Servo motor: Electronic gear ratio = (Encoder resolution * Pulse equivalen t) / 360 * Mechanical reducer ratio 3.4 Set Speed Parameters...

  • Page 55: Set The Workbench Stroke

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3.6 Set the Workbench Stroke This operation is used to set the upper limit and lower limit of the workbench, so as to ensure the machine tool moves within a safe range. If it is your first time to set the workbench stroke, confirm the actual size of the machine tool before setting.
  • Page 56 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3.7.2 Compensate Comprehensive Errors To compensate comprehensive errors, do the following: Click System → Screw Error Compensation. Screw Error Compensation dialog box pops up: To get the actual measurement data of the machine tool via laser...
  • Page 57 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Click Load Tools. AxesErrorEditor dialog box pops up: To import the RTL or LIN file, click File → Import File. The results include the following: – Values of parameters Position, Measured Value(Positive) and Measured Value (Negative) show in the dialog box.

  • Page 58: Set Parameters Of Air Pressure And Laser Device

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Click . The system automatically does the following: – Save the information into screw error compensation file as a DAT file with filename axeserr under directory C:\Program Files\Weihong\NcEditor\config. – Compensate comprehensive errors according to the data in the file.
  • Page 59 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Parameters of air pressure and laser device are as follows: Default Blow Type The default gas for blowing. If the selected gas is oxygen, port Proportioning Valve Enabled will be opened. Default Blow P.

  • Page 60: Check Machine Tool Setting

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Min Pulse Width The minimum allowable pulse width when the laser power is controlled by duty ratio. When pulse width is less than this value, this value takes effect. When pulse width is greater than this value, pulse width in duty ratio takes effect.
  • Page 61 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Check Pulse through Two Points To check pulse through two points, do the following: Make a dot on the surface of a workpiece with laser and set this dot as the workpiece origin.
  • Page 62 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3.9.3 Check Laser Technics This operation is used to check whether the technic control of piercing is normal. It includes the following: • Whether the state of ports like laser, blow, follow-up and burst is the same with the actual situation.

  • Page 63: Follow-Up

    SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 4 Follow-up This section introduces follow-up in NcEditor V12 Laser Cutting CNC System, which is used to move Z-axis up and down in real time through the corresponding relationship between capacitance and distance and ensure the relative distance between the cutting head and the workpiece is unchanged.
  • Page 64 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • Param interface Axis coordinate display area Manual control area Follow-up control buttons Alarm display bar Waveform display area Main parameters area Parameters setting area 4.1.1 Axis Coordinate Display Area It is used to show the following: •...
  • Page 65 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 4.1.2 Manual Control Area It is used to move the machine tool manually. It includes the following: • Axis direction buttons Used to move each axis towards positive or nagative direction. • Feed mode button Used to select one of the following feed mode by clicking the circular button: –...
  • Page 66 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. You can set step size by doing one of the following: • To customize step size, click the first button, and enter the value in Customize Step Size dialog box. • To set fixed step size, click one of the last three buttons.
  • Page 67 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • : Stop After the button is clicked, the system stops machining and enters idle status. It is used to normally stop machining task during follow-up control. • : Servo Calibration It is exclusive for velocity loop control mode.
  • Page 68 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • Real-time Capacitance page Used to show real-time change of capacitance in certain time. X-axis coordinate shows time while Y-axis coordinate shows the capacitance. Max Differ on the upper left shows the difference between the maximum capacitance and the minimum one when the cutting head and the workpiece are still.
  • Page 69 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. In this page, you can do the following: – Pause the waveform change: If you double click within the coordinate, at the top of Y-axis coordinate will turn into – Set scale parameters:...
  • Page 70 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. – Z Speed Used to show current running speed of Z-axis. – Z Position Used to show current machine coordinate of Z-axis. – Capacitance Used to show current capacitance. The smaller the distance between the cutting head and the workpiece is, the smaller the value is.

  • Page 71: Commissioning Steps

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 4.2 Commissioning Steps This section introduces the procedure of follow-up commissioning. Before commissioning, do the following: • To get familiar with layout and application of follow-up interface, see Interface Overview for details. •...
  • Page 72 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Observe the corresponding step length change of Z-axis coordinate and make a distinct between the increase and decrease of the changing value. • If Z-axis coordinate change is different from the specified step length, it indicates that the parameter is wrong and you should modify it.
  • Page 73 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Electric Interference is Serious for details. 4.2.3 Calibrate Servo This operation is used to eliminate the zero drift of servo motor caused by velocity loop control. To judge zero drift, do the following: Turn on the servo motor and enable servo in the software.
  • Page 74 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Move upward the specified calibration distance after it touches the workpiece. The system collects the calibration data and generates the calibration data: • Stability The difference of the collected data between the segment of the cutting head down 5mm before touching the workpiece and that of the cutting head up 5mm after touching the workpiece.

  • Page 75: List Of Parameters

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 4.2.5 Check Follow-up This operation is used to check if follow-up commissioning succeeds. Before checking follow-up, ensure the calibration is successful. To check follow-up, do the following: Turn on and off the follow-up and observe whether the cutting head shakes and whether the follow-up distance is correct.
  • Page 76 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 4.3.1 Follow-up Parameters Sensitivity A larger value means a more sensitive following. A too large value may cause overshoot. Range: [0, 20] Default value: 10 Used as down Kp and to control down speed of following.
  • Page 77 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. In Position Tolerance When the detected height is equal to “Follow height ± In position tolerance”, follow- up is in position. If the follow-up in position signal is not detected in 3s, the values will be doubled and the signal needs to be detected again.
  • Page 78 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Pulse Count Per Revolution Exclusive for velocity loop control mode. Number of pulses for per revolution of motor. Pitch = Number of pulses per revolution * Pulse equivalent Range: [0, 0.1] Default value: 10000 4.3.2 Calibration Setting Parameters...
  • Page 79 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Calibrate Curve Smoothing Point No. Used to set the number of calibrated points for the calibration curve. Range: [0, 500] Default value: 0 4.3.3 Follow Setting Parameters Z Up Position After returning to the machine origin, the machine coordinate of Z-axis up position after following is turned off or cutting finishes.
  • Page 80 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Out Margin Sensitivity The larger the value is, the higher the tendency is to judge whether the cutting head is beyond the workpiece margin. The larger the value is, the higher the tendency for judging out margin is.
  • Page 81 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Default value: 100 Max Plugging Depth Maximum allowable plugging depth of the cutting head relative to the workpiece surface. If the actual plugging depth exceeds the set value of the parameter, the cutting head will be outside the workpiece and it will be lifted.

  • Page 82: Faqs

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Default value: 50 4.4 FAQs This section mainly answers the following common questions that you may encounter during follow-up commissioning: • PG frequency dividing ratio is set incorrectly • Electric interference is serious •...
  • Page 83 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 4.4.2 Electric Interference is Serious Cause • Physical hardware The drive, Lambda 5E terminal board and EX33A terminal board are not well grounded. The cable shielding layer is not well treated, that is, the shielding layer is broken and the shielding nest is not wired to the outer metal frame.
  • Page 84 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • Software setting Slightly reduce the value of parameter Sensitivity. Slightly increase the values of parameters In Position Tolerance and Zero Limit Speed Range. Note: Please be careful. Because these operations may lead to lower precision of follow-up and cutting separately.
  • Page 85 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Solution Change the ceramic ring. 4.4.6 The Cutting Head Shakes Substantially during Cutting a Thin Sheet Cause The air pressure is high. Solution Set parameter Sensitivity as 2 (default value: 5) and parameter In Position Tolerance as 0.2 (default value: 0.1).

  • Page 86: List Of System Parameters

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5 List of System Parameters This section introduces all parameters under System → System Parameters menu in NcEditor V12 Laser Cutting CNC System, including: • Basic parameters • Speed and accuracy parameters •...
  • Page 87 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Axis Direction Moving direction of X-axis. If the moving direction of X-axis is opposite to the direction judged by Right Hand Rule when the machine tool is moved manually, modify the value of the this parameter.
  • Page 88 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Soft Limit Upper Limit Upper limit of soft limit. Range: (soft limit lower limit, 999999]mm Default value: 1500 5.1.2 Y-axis Enable Single Y Configuration Whether to enable single Y configuration. Yes: single Y configuration...
  • Page 89 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. PG Frequency Dividing Ratio of Y Ratio of sending pulse to feedback pulse in Y-axis. Positive value: positive direction of axis encoder Negative value: negative direction of axis encoder 0: not enable encoder feedback...
  • Page 90 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.1.3 Z-axis Pulse Equivalent Displacement or angle caused by per pulse in Z-axis. Range: [1E-08, 1000]mm/p Default value: 0.001 Axis Direction Moving direction of Z-axis. If the moving direction of Z-axis is opposite to the direction judged by Right Hand Rule when the machine tool is moved manually, modify the value of the this parameter.
  • Page 91 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Enable Soft Limit Protection Used to prevent the machine tool from colliding with hard limit switch. Yes: enable No: not enable Default value: Yes Soft Limit Lower Limit Lower limit of soft limit.
  • Page 92 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Enable Soft Limit Protection Used to prevent the machine tool from colliding with hard limit switch. Yes: enable No: not enable Default value: Yes Soft Limit Lower Limit Lower limit of soft limit.
  • Page 93 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.1.6 Origin Setting (X) X Direction in Coarse Positioning Moving direction of X-axis in coarse positioning stage during returning to the machine origin. 1: Positive -1: Negative Default value: -1 X Speed in Coarse Positioning Feedrate of X-axis in coarse positioning stage during returning to the machine origin.
  • Page 94 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Y Direction in Coarse Positioning Moving direction of Y-axis in coarse positioning stage during returning to the machine origin. 1: Positive -1: Negative Default value: -1 Y Speed in Coarse Positioning Feedrate of Y-axis in coarse positioning stage during returning to the machine origin.
  • Page 95 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Z Speed in Coarse Positioning Feedrate of Z-axis in coarse positioning stage during returning to the machine origin. Range: [0.06, 9000]mm/min Default value: 1800 Z Speed in Precision Positioning Feedrate of Z-axis in fine positioning stage during returning to the machine origin.
  • Page 96 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. W Speed in Precision Positioning Feedrate of W-axis in fine positioning stage during returning to the machine origin. Range: [0.06, 6000]mm/min Default value: 60 Back Distance of W W-axis adjusting displacement after fine positioning stage during returning to the machine origin.
  • Page 97 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. W-axis Lead Screw Compensation Mode Mode used to compensate lead screw error. 0: no compensation 1: backlash compensation 2: screw error compensation Screw Error Compensation Positioning Speed Positioning speed of laser interferometer in screw error compensation wizard.

  • Page 98: Speed And Accuracy Parameters

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Y1Y2 Dynamic Tolerance When Y1-axis and Y2-axis are moving, if the difference between the feedback value and output value is greater than the value, alarm will occur. Range: [10, 1000]ms Default value: 3 Double Y Error Detect Cycle Cycle for detecting double Y error.
  • Page 99 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. XY-axis Stepping Speed Step speed in step mode. Range: [0.06, Maximum value of maximum speeds between XY-axes]mm/min Default value: 6000 Z-axis Rapid Jogging Speed Speed in rapid jog mode. Range: Default value: 1800 Z-axis Jogging Speed Default speed in jog mode.
  • Page 100 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Y-axis Manual Feed Acceleration Acceleration in jog mode. Used to control the acceleration in jog mode. Range: [16, 100000]mm/ s Default value: 2000 Z-axis Manual Feed Acceleration Acceleration in jog mode. Used to control the acceleration in jog mode.
  • Page 101 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Z-axis Manual Feed Jerk Jerk in jog mode. Used to control the jerk in jog mode. Range: [16, 100000]mm/ s Default value: 10000 W-axis Manual Feed Jerk Jerk in jog mode. Used to control the jerk in jog mode.
  • Page 102 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Gxx Acc Single axis acceleration is used to describe the acceleration/deceleration capability of single feed axis. Decided by the physical feature of the machine tool, such as quality of motion part, torque and resistance of the feed motor.
  • Page 103 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. W-axis G00 Jerk Change rate of single axis acceleration during rapid traverse. Range: [0.001, 9999999]mm/ s Default value: 100000 Pause Deceleration Time Required time from running status to pause status or stop status.
  • Page 104 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.2.5 Machining Accuracy Max. Look-ahead Paths Maximum number of path to calculate distance. Range: [1, 1000] Default value: 300 Enable B-spline Interpolation Used to enable B-spline interpolation to segment that matches B-spline curve characteristic, so as to improve machining efficiency.
  • Page 105 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Max. Angle of High-speed Connection If the angle of two adjacent segments are larger than the value during machining, the speed of machining joint is startup speed. If smaller than the value, an appropriate connection speed will be calculated according to the connection angle.

  • Page 106: External Device Parameters

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.3 External Device Parameters This section introduces parameters of external device under External Device category, including the following: • 3.0 Monitoring • 3.1 Lube • 3.2 Gas Control • 3.3 Exhaust • 3.4 Exchange Workbench •...
  • Page 107 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.3.3 Gas Control Default Blow Type Gas type when the button Blow is clicked. 0: Air 1: Nitrogen 2: Oxygen Default value: 0 Default Blow P. Default value of air pressure in idle status.
  • Page 108 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Analog AVO1/2/3 Voltage of analog AVO1/2/3 when the analog rate is 100%. Range: [Pressure in idle status, 10]V Default value: 10 5.3.4 Exhaust Enable Auto Exhaust Whether to enable automatic exhaust. Default value: No Disable Exhaust Delay Delay time before disabling exhaust port when leaving out of the area.
  • Page 109 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.3.5 Exchange Workbench Enable Exchange Workbench Whether to exchange workbench. Default value: No 5.3.6 Focus Control Enable Focus Control Whether to enable focus control function. Default value: No 5.3.7 Follow-up Empty Move Collide Sensitivity Used to control the sensitivity of touching workpiece signal during rapid traverse process.
  • Page 110 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Min Pulse Width Minimum allowable pulse width when laser power is controlled by duty ratio. When pulse width is smaller than this value, this value is used. When pulse width is larger than this value, pulse width in duty ratio is used.

  • Page 111: Advanced Function Parameters

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.4 Advanced Function Parameters This section introduces parameters of advanced function under Advanced Function category, including the following: • 4.0 Habitual Setting • 4.1 Simulation • 4.2 Fixed Point • 4.3 Resume •...
  • Page 112 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Screen Switch Used to switch between landscape mode and portait mode. 0: Landscape mode 1: Portrait mode Default value: 0 5.4.2 Simulation Simulation Speed Speed during executing simulation. Range: [0, 100000]mm/min Default value: 1000 5.4.3 Fixed Point...
  • Page 113 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Forward/Retract Speed Speed during moving forward/backward. Range: [10, Maximum value of maximum speed between X-axis and Y-axis]mm/min Default value: 3000 5.4.5 Leap Frog Enable Frog Leaping Whether to enable leapfrog. It is modified synchronously with frogleap function in Layer Setting dialog box. See Layer Function for details.
  • Page 114 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Laser off Lag Time for Scan Cutting It can be set larger when some workpiece is left uncut in trace end. Range: [0, 10] Default value: 1 The Buffer Count for Scan Cutting Modify this parameter when cutting trace is dislocated.

  • Page 115: Electrical Wiring Diagram

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6 Electrical Wiring Diagram This section introduces the following information about hardware installation in NcEditor V12 Laser Cutting CNC System: • Mounting dimension • Wiring diagram of terminal board • Wiring diagram of laser device •...
  • Page 116 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Mounting dimension of EX33A terminal board is as follows: Mounting dimension of EX31A terminal board is as follows: 114 / 144...
  • Page 117 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Mounting dimension of follow-up amplifier is as follows: Mounting dimension of PM95A motion control card is as follows: 115 / 144...

  • Page 118: Wiring Diagram Of Terminal Board

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6.2 Wiring Diagram of Terminal Board In this section, you can quickly know about how to connect I/O ports of each terminal board. According to the configuration, wiring diagram of terminal board can be divided into the following: •...
  • Page 119 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of Lambda 5E Terminal Board In double Y configuration, wiring diagram of Lambda 5E terminal board in position loop control mode is as follows: Wiring diagram in velocity loop control mode differs from that in position loop control mode in that: •...
  • Page 120 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring diagram in single Y configuration differs from that in double Y configuration in that: • X-axis, Y-axis and Z-axis servo interfaces should be connected to axis servo interfaces 1, 2 and 4.
  • Page 121 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of EX33A Terminal Board Wiring diagram of EX33A terminal board is as follows: Among the ports: • Outputs Y00~Y05 should be conneted to relays. • In configuration with follow-up, Y02 is set as Blow (Air).
  • Page 122 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of EX31A Terminal Board Wiring diagram of EX31A terminal board is as follows: Among the ports: • C00~C05 are common ports. • Y04~Y09 are reserved output ports. • S00~S03 are active high/low ports.
  • Page 123 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of Lambda 5E Terminal Board Wiring diagram of Lambda 5E terminal board in position loop control mode is as follows: Wiring diagram in velocity loop control mode differs from that in position loop control mode in that: •...
  • Page 124 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of EX30A Terminal Board Wiring diagram of EX30A terminal board is as follows: 122 / 144...
  • Page 125 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of EX33A Terminal Board Wiring diagram of EX33A terminal board is as follows: 123 / 144...

  • Page 126: Wiring Diagram Of Laser Device

    Before connecting laser devices, do the following: • Select and connect proper pulse modulation signals for different laser devices. The relationship between pulse modulation signals provided by NcEditor V12 Laser Cutting CNC System and corresponding interfaces on EX30A/EX33A termninal board is as follows: –...
  • Page 127 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • If the laser device supports RS232 communication, connect RS232 interface on the laser device to RS232 on EX30A/EX33A terminal board via a DB9 cable, so as to realize communication between the laser device and the software.
  • Page 128 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6.3.1 Wiring Diagram of IPG-YLR Series Laser Device Wiring diagram is as follows: 6.3.2 Wiring Diagram of FEIBO MARS-500W Laser Device Wiring diagram is as follows: 126 / 144...
  • Page 129 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6.3.3 Wiring Diagram of Raycus Laser Device Wiring diagram is as follows: 6.3.4 Wiring Diagram of JK/GSI-500W-FL Laser Device Wiring diagram is as follows: 127 / 144...
  • Page 130 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6.3.5 Wiring Diagram of Maxphotonics Laser Device Wiring diagram is as follows: 6.3.6 Wiring Diagram of SPI-500W-R4 Laser Device Wiring diagram is as follows: 128 / 144...
  • Page 131 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6.3.7 Wiring Diagram of HFB 1000-1500W Laser Device Wiring diagram is as follows: 129 / 144...
  • Page 132 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6.3.8 Wiring Diagram of GW SMATLas 3S Laser Device Wiring diagram is as follows: 130 / 144...

  • Page 133: Wiring Diagram Of Drive

    SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 6.4 Wiring Diagram of Drive In this section, you can quickly know how to connect WEIHONG DB15 drive interface to different servo motors. Before connecting, you need to know the definition of drive interface. See...
  • Page 134 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Remark of drive interface is as follows: Signal Definition Input/Output Remark It is used to receive the Input, differential differential output of Feedback signal of A+, A- signal transmission encoder phase A signal...
  • Page 135 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Signal Definition Input/Output Remark Analog speed V-REF Output command +24V, GND DC 24V power Output It is connected to drive. 6.4.2 Wiring Diagram of Drive (in Position Loop Control Mode) This section introduces wiring diagrams of the following drives: •...
  • Page 136 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • With brake lines 134 / 144...
  • Page 137 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of YASKAWA Σ-Ⅱ/Σ-Ⅴ/Σ-7 Servo Drive Wiring diagram is as follows: • Connect to one connector 135 / 144...
  • Page 138 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • Connect to two connectors 136 / 144...
  • Page 139 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of Panasonic AC Servo Drive Wiring diagram is as follows: 137 / 144...
  • Page 140 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of Fuji Servo Drive Wiring diagram is as follows: 138 / 144...
  • Page 141 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of DELTA Servo Drive Wiring diagram of DELTA ASDA-A servo drive is as follows: DELTA ASDA-A, ASDA-A2 and ASDA-AB share the same wire. Among them, ASDA-A2 and ASDA-AB have the same wiring pin while ASDA-A has the contrary pulse pin, with PULSE 43, /PULSE 41.
  • Page 142 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring diagram of DELTA ASDA-B servo drive is as follows (connecting to one connector): Wiring diagram of DELTA ASDA-B2 servo drive is as follows: 140 / 144...
  • Page 143 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring diagram of DELTA ASDA-B servo drive is as follows (connecting to two connectors): 6.4.3 Wiring Diagram of Drive (in Velocity Loop Control Mode) This section introduces wiring diagrams of the following drives: •...
  • Page 144 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of WISE Servo Drive Wiring diagram is as follows: 142 / 144...
  • Page 145 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of YASKAWA Σ-7 Servo Drive Wiring diagram is as follows: 143 / 144...
  • Page 146 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Wiring Diagram of Fuji Servo Drive Wiring diagram is as follows: 144 / 144...
  • Page 147 S P E C I A L I Z E D / C O N C E N T R A T E D / F O C U S E D Shanghai Weihong Electronic Technology Co., Ltd. Address: No. 1590, Huhang Rd., Fengxian, Shanghai, China, 201401 Hot-line: 400 882 9188 Website: www.weihong.com.cn/en...
