Quick Start Guide for the Integrated CNC System of Shoe
1
System Overview ............................................................................................................................ 1
1.1
NK300CX Host ..................................................................................................................... 1
1.1.1 Layout ........................................................................................................................ 1
1.1.2 Mounting Dimension (Unit: mm) .................................................................... 4
1.2
WH108C Operation Panel ............................................................................................... 5
1.2.1 Layout ........................................................................................................................ 5
1.2.2 Mounting Dimension (Unit: mm) .................................................................... 8
1.3
Main Software Interface .................................................................................................. 9
2
Basic Commissioning ................................................................................................................. 10
2.1
Set Commissioning Parameters ................................................................................. 10
2.1.1 Set Bus Control System .................................................................................... 10
2.1.2 Set Non-bus Control System ........................................................................... 11
2.2
Adjust the Axis Direction ............................................................................................. 11
2.3
Return to the Machine Origin ..................................................................................... 12
2.3.2 Set the Datum with an Absolute Encoder ................................................. 14
2.4
Define the Workpiece Origin ...................................................................................... 15
3
Quick Start ...................................................................................................................................... 16
3.1
Load a Program File ....................................................................................................... 16
3.1.1 Load a Program File from the Internet ...................................................... 17
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD.
Molding Machines
Author: Product Supporting Department
Weihong Corporation, All Rights Reserved
上海维宏电子科技股份有限公司
Version: 2020.1 1st Version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NK300CX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WEIHONG NK300CX

Summary of Contents for WEIHONG NK300CX

  • Page 1: Table Of Contents

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Quick Start Guide for the Integrated CNC System of Shoe Molding Machines Version: 2020.1 1st Version Author: Product Supporting Department Weihong Corporation, All Rights Reserved System Overview ..........................1 NK300CX Host ........................1 1.1.1 Layout ........................
  • Page 2 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3.1.2 Set a Machining Task ..................21 Adjust the WCS ......................... 23 3.2.1 Select a WCS ......................23 3.2.2 Set the Offsets ...................... 24 Execute Tool Calibration ....................25 FAQs ..............................26 Axis Servo Alarm ......................26 Failed to Register the System ..................

  • Page 3: System Overview

    NcStudio JS software for shoe molding machines Main Software Interface for details. 1.1 NK300CX Host This part introduces the layout and mounting dimension of NK300CX host. 1.1.1 Layout It introduces the layout of both front view and rear view. 1 /33...
  • Page 4 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.1.1.1 Front View The front view of NK300CX host is as follows: USB interface Used to connect with USB flash disks. And it is protected by a cover. Display area Human-machine interface, or user’s interface. It is user-friendly and easy to use.
  • Page 5 1.1.1.2 Rear View The rear view of NK300CX host is as follows: DB9M/F cable interface – For NK300CX-H, it is used to connect with the keypad panel. – For NK300CX-V, it is used to connect with the operation panel. Terminal board interface Used to connect with Lambda terminal board.

  • Page 6: Mounting Dimension (Unit: Mm)

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Power interface Used to connect with 220V power supply. 1.1.2 Mounting Dimension (Unit: mm) NK300CX Dimension NK300CX Cut-out 4 /33...

  • Page 7: Wh108C Operation Panel

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.2 WH108C Operation Panel This part introduces the layout and mounting dimension of WH108C operation panel used by NK300CX-V. 1.2.1 Layout The front view of the operation panel is as follows: Alpha-numeric keys Used to input characters and numbers.
  • Page 8 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Keys for common ports Used to turn on / off frequently used ports, including Air, Light, Coolant, Oil keys, and control rapid movement, including Rapid key. Keys for mode selection Used to select a machining mode among REF.Point, JOG, Auto, Handle and Step.
  • Page 9 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 11. Spindle override knob Used to adjust spindle override from 50% to 150%. When parameter N72003 G00 F Fixed is set to No, the knob is used as G00 override knob and used to adjust G00 override from 0 to 100%.

  • Page 10: Mounting Dimension (Unit: Mm)

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.2.2 Mounting Dimension (Unit: mm) WH108C Dimension WH108C Cut-out 8 /33...

  • Page 11: Main Software Interface

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 1.3 Main Software Interface The interactive user interface for NcStudio Software for Shoe Molding Machines in Auto mode is as follows: Status bar It shows the following information: – Current mode, such as Auto, JOG, etc.

  • Page 12: Basic Commissioning

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2 Basic Commissioning Through this section, you can quickly know the following basic commissioning processes for Integrated CNC System for Shoe Molding Machines: Set commissioning parameters. Adjust the axis direction. Return to the machine origin.

  • Page 13: Set Non-Bus Control System

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2.1.2 Set the Non-bus Control System This operation is used to set commissioning parameters for the non-bus control system. Before setting commissioning parameters for the non-bus control system, ensure the following: • Parameter N50000 Control System Type is set to 0.

  • Page 14: Return To The Machine Origin

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. In JOG / Handle / Step mode, press X+ to move X-axis, and observe its moving direction. Optional: If the actual moving direction is opposite to the judged direction, modify the value of parameter Axis Direction(X) to the opposite value.
  • Page 15 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. To return to the machine origin with an incremental encoder, do the following: In REF mode, to enter Coor interface, press → 1: Press one of the following: – F1: return X-axis to the machine origin.

  • Page 16: Set The Datum With An Absolute Encoder

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 2.3.2 Set the Datum with an Absolute Encoder This operation is used to return to the machine origin with an absolute encoder by directly setting the datum at the first time to use the system.

  • Page 17: Define The Workpiece Origin

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. After setting the datum with an absolute encoder, you can export the set datum by pressing F1 in the next page to save it to the root directory of a USB flash disk. When a new software is installed, you can import the previously saved datum by pressing F2 in the next page, so as to save the trouble of repeated setting.

  • Page 18: Quick Start

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Exchange positions of X1-axis and X2-axis and press F2. The system automatically calculates the midpoint coordinate of X1-axis and X2- axis separately based on the coordinates of X1-axis and X2-axis recorded in step 5 and step 6, and separately sets the midpoints of X1-axis and X2-axis as their workpiece origins.

  • Page 19: Load A Program File From The Internet

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3.1.1 Load a Program File from the Internet This operation is used to establish network connection between the integrated CNC system for shoe molding machine and PC, to realize two-way transmission between them.
  • Page 20 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Press ↑ or ↓ to select the target input box, and set the following addresses: – IP address E.g. 192.168.1.188 (the first three digits should be the same with that of PC, and the last digit should be different from that of PC) –...
  • Page 21 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Press Enter, and check the result: Connection succeeds, and network connection between the integrated CNC system and PC is established. If the connection fails, troubleshoot the following: Check the corresponding cable interface of the router.
  • Page 22 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. To access a shared program file, do the following: To enter Network interface, press → 3: Press H. Browse for Folder dialog box pops up: 20 /33...

  • Page 23: Set A Machining Task

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Select Network → the target PC, find the desired shared folder, and click OK. File list in the shared folder shows in Network interface. To select the target program file, press ↑ or ↓.
  • Page 24 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. According to the actual situation, modify names of program files in the target folder: – If it is your first time to match the program files with technics, modify the names according to the default matching principle.

  • Page 25: Adjust The Wcs

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. • To modify the workpiece coordinate system, press F3. The supported workpiece coordinate system includes coordinate systems G54 ~ G59 and extended coordinate systems G54P0 ~ G54P119. Before using extended coordinate systems, ensure parameter N80010 Support Extended Part Offsets is set to Yes.

  • Page 26: Set The Offsets

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. To select a WCS , do the following: In Auto mode, to enter Coor interface, press → 1. Press N or click WCS input box and select a workpiece coordinate system. – To select G54 (default setting), press F1.

  • Page 27: Execute Tool Calibration

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 3.3 Execute Tool Calibration This operation is used to measure the selected tool, so as to ensure it works normally during machining. The types of tool calibration include the following: • Mobile calibration •...

  • Page 28: Faqs

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. Do one of the following in double-axis mode according to the actual situation: – If it is the first time to execute tool calibration, press F7. – After tool change or tool break, press F2.

  • Page 29: Failed To Register The System

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 4.2 Failed to Register the System Cause You exited System interface during registering the system. Solution Press → 1 to enter System interface, take a picture of the interface, send the photo to your developer, and stay at the interface until the end of registration.

  • Page 30: Parameter List

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5 Parameter List This part introduces the parameters for manufacturers. 5.1 Technic Parameters N63000 Look Ahead Distance for Interpolation The system looks ahead certain distance to analyze and calculate path interpolation. The smaller the value, the slower the speed.
  • Page 31 上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. N64102 Z Axis Acceleration The maximum acceleration of Z-axis. Its value should match with the value of parameter N64100 Axial Acceleration. N64120 Acceleration for Corners The maximum acceleration of feed motion on adjacent axes.

  • Page 32: Parameters For Approaching The Workpiece Surface

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. N64248 Enable Smooth Optimization Whether to optimize the tool path in path smoothing or after Acc/Dec to improve efficiency. N64300 Deceleration Time To Pause The time from running to pause or stop state.

  • Page 33: Parameters For Z-Axis Motion At Pause

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. N20011 Spindle Off Delay Time The delay time before turning off the spindle so that it can stop completely. If the value is too small, the inverter alarm will occur. 5.6 Parameters for Z-axis Motion on Pause N73000 F When Cycle Resume after Pause The downward feedrate of Z axis at the previous cutting point after a pause.

  • Page 34: Parameters For Action After Cycle

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. 5.9 Parameters for Action after Cycle N79100 Stop Mode when Cycle Completed The tool motion after the cycle is completed. 0: stay where it is. 1: tool moves to fixed point. 2: tool moves to zero in WCS.

  • Page 35: Other Parameters

    上海维宏电子科技股份有限公司 SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD. N74080 Back Off Distance The additional moving distance after the end of fine positioning in returning to machine origin. The positive value means the positive direction and the negative one means the negative direction.
