Installation Instructions
Classic Hands-Free Device Retrofit Kit
BMW Z4 (E 85 )
Retrofit kit part number:
Installation time:
The installation time is 4.0 hours, but this may vary depending on the condition of the car and the
equipment in it.
Important information:
- These installation instructions are primarily intended for use in the BMW dealer organisation and
by authorised BMW dealerships;
Irrespective of where these installation instructions are used, their target group is specialist
personnel trained on BMW cars with the appropriate specialist knowledge.
- All work must be completed using the latest repair manuals, circuit diagrams, servicing manuals
and work instructions in a rational order using the prescribed tools (special tools) and observing
current health and safety regulations.
- Ensure that the cables/lines are not kinked or damaged as you install them in the car.
- If the specified PIN numbers are occupied, bridges, double crimps or twin-lead terminals must
be used.
- All the figures show LHD cars, proceed accordingly on RHD cars.
- Item numbers refer only to the overview drawing and to the texts next to the appropriate figure.
- Subject to technical modifications.
- See the EBA CD or ASAP (Aftersales Assistance Portal) for explanations of the pictograms.
- Do not print out these installation instructions, since daily updates are available via ASAP!
Special tools:
None
© BMW Group
84 64 0 301 448
Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003
Advertisement
Table of Contents
Related Manuals for BMW 84 64 0 301 448
Summary of Contents for BMW 84 64 0 301 448
-
Page 1: Important Information
The installation time is 4.0 hours, but this may vary depending on the condition of the car and the equipment in it. Important information: - These installation instructions are primarily intended for use in the BMW dealer organisation and by authorised BMW dealerships; Irrespective of where these installation instructions are used, their target group is specialist personnel trained on BMW cars with the appropriate specialist knowledge. -
Page 2: Table Of Contents
Concluding work ..............17 © BMW Group Installation Instructions No. -
Page 3: Parts List
Parts list 085 0136 B © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/3... -
Page 4: Preparations
Remove the trim for the rear storage box 51 16 235 Remove the glove compartment Remove the A pillar trim on the right Remove the interior light © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/4... -
Page 5: Connection Overview
X18126/11 Fakra plug casing To Fakra socket casing of eject box K Black 18-pin socket casing To black 18-pin plug casing of eject box K © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/5... - Page 6 Aerial cable extension Fakra socket casing To branch A3 of telephone adapter cable A Fakra socket casing To connection provided in amplifier of rubber aerial © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/6...
-
Page 7: Installation And Cabling Diagram
To eject box K To eject box K Microphone cable extension B To branch A7 To microphone E Aerial cable extension C To branch A3 To aerial amplifier © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/7... -
Page 8: To Cut The Centre Console
Transfer the cut line 1 with dimension a onto the console cover 2 and cut across as shown in the figure. Dimension a = 185 mm &# © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/8... - Page 9 To cut the centre console Use screws to attach the cut console cover 1 to the centre console 2. 085 0202 B © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/9...
-
Page 10: To Install The Wiring Harness
A 12 085 0213 B Route branch A7-A10 as illustrated. A 10 085 0214 B Route branch A8-A10 to the radio connection plug 1. )& &# © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/10... - Page 11 1. The arrow on hands-free microphone E must point to the front of the car. Connect branch B2 to hands-free microphone 085 0138 B © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/11...
- Page 12 1. 085 0210 B Connect branch C2 to the slot provided in the aerial amplifier 1. 085 0211 B © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/12...
-
Page 13: To Install The Eject Box
Connect branch A11/A12 to eject box K. Pull back telephone adapter cable A at the provided point 2 and tie it back. 085 0215 B © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/13... - Page 14 Remove the cable tie 1 from the bellows 2. Remove the handbrake grip 3. 085 0223 B Use cable tie M to attach the handbrake grip 1 to bellows H. 085 0224 B © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/14...
- Page 15 Stick Velcro strip I to armrest J and glue into console cover F. 085 0226 B Attach bellows H to the centre console 1. 085 0225 B © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/15...
-
Page 16: Coding
Coding This system is not diagnostics-capable and does not have to be coded. © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/16... -
Page 17: Concluding Work
Connect battery Conduct a function test on the hands-free device. Assemble the car following the instructions to dismantle it in reverse order Print out error memory © BMW Group Installation Instructions No. 01 29 0 301 626 Issue date: 02.2003 EN/17...
