BMW 84 64 0 153 493 Installation Instructions Manual

Parts and Accessories
Installation Instructions
Universal BMW Hands-Free Kit Upgrade
BMW X5 (E 53) from 09/01 to 03/02
These installation instructions are only valid for cars with SA 640 (telephone preparation).
Important information
This upgrade kit is for use within the BMW dealership organisation only.
Subject to technical modifications.
Target group
The target group for these installation instructions is specialist personnel trained on BMW cars with the
appropriate specialist knowledge.
All work must be completed using the latest BMW repair manuals, circuit diagrams, servicing manuals and
work instructions in a rational order using the prescribed tools (special tools) and observing current health and
safety regulations.
Installation information
Ensure that the cables/lines are not kinked or damaged as you install them in the car.
The installed cables are to be secured with cable ties.
If the specified PIN chambers are occupied, bridges, double crimps or twin-lead terminals must be used.
Ordering instructions
The snap-in adapter is not part of the upgrade kit and must be ordered separately.
Installation time
Approx. 4 hours, but this may vary depending on the condition of the car and the equipment in it.
Pictograms
denotes instructions that draw your attention to special features .
denotes the end of the instruction or caution text.
Retrofit kit No.
84 64 0 153 493
84 64 0 302 178
Special tools required
Removal tool (00 9 341)
Retrofit kit No. 84 64 0 153 493
Installation Instructions No. 01 29 0 153 674 Issue date: 09.2002
