- Page 1 SMARTPACK 40H (7230) Owners & Operators Manual SERVICE MAINTENANCE AIR COMPRESSOR – HYDRAULIC DRIVEN Revision: 1.5 Reviewed: 07/03/2019 7235-D0001-01...
- Page 2 THIS PAGE IS LEFT BLANK INTENTIONALLY. Document No 7235-D0001-01...
- Page 3 MEA Product Warranty Registration Form THIS FORM MUST BE COMPLETED AND RETURNED WITHIN 30 DAYS OF INSTALLATION WARRANTY WILL BE VOID Document No 7235-D0001-01...
- Page 4 CUT HERE MEA Product Warranty Registration Form This form must be completed and returned to MEA at the time of Installation. Warranty will be void if this form is not received by MEA within 30 days of installation. MEA Dealer Information...
-
Page 5: Table Of Contents
MOBILE ENERGY AUSTRALIA CONTACTS ............23 APPENDIX - A COMPRESSOR INFORMATION Both the MEA Product Warranty Registration form (located at the FRONT of this Manual) and the Kohler Engine Warranty Registration form (located at the back of this manual) are to be returned to MEA. -
Page 6: Product Safety
1. PRODUCT SAFETY (COMPRESSOR / COMPRESSED AIR) MEA DISCLAIMS ALL LIABILITIES FOR DAMAGE OR LOSS OF EQUIPMENT AND PROPERTY, PERSONAL INJURIES (INCLUDING DEATH), AND CONSEQUENTIAL DAMAGES ARISING OUT OF ANY MEA SYSTEM NOT USED IN ACCORDANCE WITH THE OPERATOR’S MANUAL. - Page 7 PRODUCT SAFETY -continued HYDRAULIC SAFETY ALL HYDRAULIC EQUIPMENT MUST BE TREATED WITH EXTREME RESPECT AND CARE. AS THE WORKING FLUID IS UNDER EXTREME PRESSURE, UP TO 5000PSI, WITH HIGH FLOW RATES GENERATING HIGH HEAT, ALL APPROPRIATE SAFETY PRECAUTIONS MUST BE TAKEN IN TO ACCOUNT AND SAFETY EQUIPMENT MUST BE WORN IF IN CONTACT WITH THE EQUIPMENT UNDER OPERATION.
-
Page 8: Introduction
2. INTRODUCTION This MEA vehicle mounted air compressor system utilizes the available hydraulic power for the running of the installed compressor to supply compressed air at the specified flow rate and pressure. Only those who have been properly trained and delegated to do so, and who have read and understand the operation and installation procedures should install MEA compressor systems. -
Page 9: Specifications
Safety Features: 200 PSI relief valve in compressor sump Temperature safety sensor in compressor Rapid blow-down valve to discharge system pressure on shutdown Lubrication: MEA Certified and Approved Oil Filters: Paper-type replaceable air filter Spin-on type oil filter Coalescing separator element... -
Page 10: Operating Procedure
4. OPERATING PROCEDURE WARNING CAREFULLY READ THE OPERATING INSTRUCTIONS BELOW. FAILURE ADHERE FOLLOWING COMPRESSOR OPERATING INSTRUCTION COULD RESULT IN SERIOUS INJURY. 1. Check Oil Level (Refer to Page 53). 2. Check Hoses and fittings for leaks. Make sure the hoses are not loosened nor damaged. 3. -
Page 11: Installation
The SMARTPACK 40H is designed as an integrated compressor system for connection to an existing hydraulic system. The SMARTPACK 40H only requires connection of a pressure line in and a return line out (optional: a motor drain line) connections to the tank line and a method for controlling flow such as solenoid valve and flow orifice. -
Page 12: Schedule Maintenance
6. SCHEDULE MAINTENANCE Maintenance schedules are given as per components’ manufacturer standards under normal operating. If the operating conditions deviate from standard (such as severe environmental conditions), it is necessary to take steps for the affected areas to be maintained at shorter intervals. For details on maintenance procedures, consult “Compressor Information (APPENDIX-A, Page 52”. -
Page 13: Troubleshooting
7. TROUBLESHOOTING (Detailed procedures on troubleshooting of the compressor system can be found in “Compressor Information (APPENDIX-A, Page 65)”. Document No 7235-D0001-01... -
Page 14: Spare Parts
UNLOADER VALVE 12V 20012-P0004 RELAY 12V 20012-P0005 RELAY 24V TO BE REQUESTED COUPLING SET TO BE REQUESTED COUPLING (SPIDER) TO BE REQUESTED SHAFT SEAL PLEASE CONTACT MEA SALES-SPARE PARTS FOR FURTHER INFORMATION ON ANY MAINTAINANCE PARTS REQUIRED. Document No 7235-D0001-01... -
Page 15: Drawings & Illustrations
9. DRAWINGS & ILLUSTRATIONS GENERAL ARRANGEMENT DRAWING ( FRAMED) Document No 7235-D0001-01... - Page 16 Document No 7235-D0001-01...
- Page 17 Document No 7235-D0001-01...
- Page 18 Document No 7235-D0001-01...
- Page 19 GENERAL ARRANGEMENT DRAWING ( FRAMELESS) Document No 7235-D0001-01...
- Page 20 HYDRAULIC/PNEUMATIC CIRCUIT DIAGRAM Document No 7235-D0001-01...
- Page 21 ELECTRICAL DIAGRAM ( FRAMED) Document No 7235-D0001-01...
- Page 22 ELECTRICAL DIAGRAM (MURPHY CONTROL BOX - FRAMELESS) Document No 7235-D0001-01...
- Page 23 REMOTE ELECTRONIC CONTROL WIRING Document No 7235-D0001-01...
- Page 24 REMOTE ELECTRONIC CONTROL WIRING - continued Document No 7235-D0001-01...
-
Page 25: Warranty
MEA are defective. The obligation of MEA is limited to replacement of faulty parts. No liability is accepted for any freight costs, consequential damages, injuries or expenses directly or indirectly related to the Product(s) failure. - Page 26 WARRANTY (continued) BUYER OBLIGATIONS Buyer shall notify MEA of the alleged defect within 10 days of initial discovery and return the allegedly defective component(s) within 30 days of initial discovery. The Buyer must prepay all costs associated with the warranty.
-
Page 27: Mobile Energy Australia Contacts
MOBILE ENERGY AUSTRALIA - CONTACTS Management Managing Director – Rob Pulz Office: 07 3273 6803 Sales Email: sales@mobileenergyaustralia.com.au Office: 07 3273 6803 Spare Parts BH Office: 07 3273 6803 Email: sales@mobileenergyaustralia.com.au Service Email: workshop@mobileenergyaustralia.com.au Office: 07 3273 6803 Document No 7235-D0001-01... -
Page 28: Appendix - A Compressor Information
APPENDIX - A COMPRESSOR INFORMATION Document No 7235-D0001-01... - Page 29 Document No 7235-D0001-01...
- Page 30 Document No 7235-D0001-01...
- Page 31 Document No 7235-D0001-01...
- Page 32 Document No 7235-D0001-01...
- Page 33 Document No 7235-D0001-01...
- Page 34 Document No 7235-D0001-01...
- Page 35 Document No 7235-D0001-01...
- Page 36 Document No 7235-D0001-01...
- Page 37 Document No 7235-D0001-01...
- Page 38 Document No 7235-D0001-01...
- Page 39 Document No 7235-D0001-01...
- Page 40 Document No 7235-D0001-01...
- Page 41 Document No 7235-D0001-01...
- Page 42 Document No 7235-D0001-01...
- Page 43 Document No 7235-D0001-01...
- Page 44 Document No 7235-D0001-01...
- Page 45 Document No 7235-D0001-01...
- Page 46 Document No 7235-D0001-01...
- Page 47 Document No 7235-D0001-01...
- Page 48 OPTIONAL INTEGRATED AFTERCOOLER PICTURED Document No 7235-D0001-01...
- Page 49 Document No 7235-D0001-01...
- Page 50 Document No 7235-D0001-01...
- Page 51 Document No 7235-D0001-01...
- Page 52 Document No 7235-D0001-01...
- Page 53 Document No 7235-D0001-01...
- Page 54 Document No 7235-D0001-01...
- Page 55 Document No 7235-D0001-01...
- Page 56 Document No 7235-D0001-01...
- Page 57 Document No 7235-D0001-01...
- Page 58 Document No 7235-D0001-01...
- Page 59 Document No 7235-D0001-01...
- Page 60 Document No 7235-D0001-01...
- Page 61 Document No 7235-D0001-01...
- Page 62 Document No 7235-D0001-01...
- Page 63 Document No 7235-D0001-01...
- Page 64 Document No 7235-D0001-01...
- Page 65 Document No 7235-D0001-01...
- Page 66 Document No 7235-D0001-01...
- Page 67 Document No 7235-D0001-01...
- Page 68 Document No 7235-D0001-01...
- Page 69 Document No 7235-D0001-01...
- Page 70 Document No 7235-D0001-01...
- Page 71 Document No 7235-D0001-01...
- Page 72 Document No 7235-D0001-01...
