- Page 1 JVA ElEctric FEncE EnErgizEr RSG1 • SV2 • SV5 • SV10 installation and User Manual Mounted JVA SV10 JVA RSG1 JVA SV10 JVA SV5 JVA SV2 October 2019 Edition JVA AGRIRANGE ENERGIZERS...
- Page 2 JVA AgriRange Energizers INTRODUCTION Congratulations, and welcome to the shocking world of JVA. We thank you for placing your faith in our product range. In doing so you have joined the world-wide body of satisfied JVA users who are benefiting from our products.
-
Page 3: Table Of Contents
Battery replacement – RSG1 and SV2 ........ - Page 4 RSG1, SV2, SV5, SV10 JVA AgriRange Energizers Table of Contents (continued) COMMON FENCE PROBLEMS ............
-
Page 5: Important Notes - Please Read
The JVA SV series of electric fence energizers are fully self-contained, solar powered energizers. Each energizer in the SV series comes with an internal 12V battery, integrated battery charger, solar panel bracket and solar panel. The JVA RSG1 energizer has limited power supply options. For more information please refer to section 2.2. -
Page 6: Solar Panels
10 degrees. If in doubt, confirm with an online solar panel angle calculator. Solar panels need as much direct sunlight as possible, preferably full sun all day. Unlike small solar powered items such as calculators, all JVA Solar-Powered Energizers need direct sunlight to generate enough electricity to charge the battery. - Page 7 RSG1, SV2, SV5, SV10 JVA AgriRange Energizers RSG1 SV10 Lightning protection Reverse battery protection Self-resetting fuse Solar Ready (includes battery, regulator & solar panel) Low battery indication ...
-
Page 8: Benefits Of Features
RSG1, SV2, SV5, SV10 JVA AgriRange Energizers 2.2 Benefits of Features The battery life maximization works by slowing the frequency of high voltage pulses just ► before the battery dies to keep the energizer operating for as long as possible without damaging the battery. -
Page 9: Parts Of The Energizer
RSG1, SV2, SV5, SV10 JVA AgriRange Energizers 3. PARTS OF THE ENERGIZER On/Off button (not on M1.5 and M3) Fence OK indicator (red LED) Energizer On and OK indicator (green LED) Rubber O-ring seal between front and back case pieces... -
Page 10: Fence Connectors
Southern hemisphere, due south in the Northern hemisphere, and at an angle of degree latitude plus 10 degrees). Mounting the Energizer • The RSG1 can be hung from the plastic hanger bracket. • There are two different methods for mounting the SV2,5 and 10. These are shown on the following page. -
Page 11: Connecting The Energizer To The Fence
For battery choice see specification table 3 on page 4. Turn the energizer ON at the On/ Off switch. Solar Power Source (RSG1) It is recommended that a solar regulator is used in conjunction with a solar panel and a rechargeable battery. Please refer to the instructions provided with the solar regulator for information regarding its setup. -
Page 12: Operation
For best results locate the energizer as centrally as possible in a fencing layout. The fence and the earth voltages can be measured using an electric fence digital voltmeter, or a digital electric fence directional fault finder, such as the JVA Electric Fence Digital Directional Fault Finder. -
Page 13: All-Live Earth Return System
RSG1, SV2, SV5, SV10 JVA AgriRange Energizers ► They improve pasture and grazing control ► They can improve existing fence life as a result of less physical pressure on the fence ► They are easy to set up compared with traditional fences. -
Page 14: Earthing Your Energizer
RSG1, SV2, SV5, SV10 JVA AgriRange Energizers Fig 2 Earth Stake The circuit is closed when the animal nudges both the live and Earth wires The earthed fence wire provides the current flow required of a fence to complete the circuit when the ground cannot 5.5 Earthing Your Energizer... -
Page 15: Maintenance
However, nature is capable of performing more extremely than can be tested for in the laboratory; to ensure the wellbeing of your JVA investment for the long term, it is recommended that a Lightning Protection Kit is installed to prevent lightning damage and possible costly repairs. -
Page 16: Moisture And Ants
WARNING: Risk of electrical shock! (See Important Notes on page 1) Turn the SV2/RSG1 off. Be careful not to press firmly on the front of the case as this can sometimes turn the unit on. -
Page 17: Battery Replacement - Sv5 And Sv10
6.6 Battery Replacement – SV5 and SV10 The JVA SV series of energizers contain a sealed lead-acid (SLA) battery that is charged by the solar panel. If the unit indicates a depleted battery it will flash the red Error LED twice. The unit should be turned off and placed in full sun for 2 to 3 days to allow the battery to charge fully. -
Page 18: Errors And Error Codes
Short the end of your fence to earth by hammering a metal stake into the soil and connecting this to the live fence wire. Using an electric fence voltmeter or a JVA Electric Fence Fault Finder, (Do not use a standard multimeter.) check the voltage is at the earth terminal of the energizer. In... - Page 19 To test the performance of the fence or find faults on the fence, an electric fence voltmeter is essential, and a JVA Electric Fence Fault Finder is even better. An effective fence will have more than 2 kV (2000 volts).
- Page 20 RSG1, SV2, SV5, SV10 JVA AgriRange Energizers a) The size of the warning sign shall be at least 100 mm × 200 mm. b) The background colour of both sides of the warning sign shall be yellow. The inscription on the sign shall be black and shall be either: •...
- Page 21 JVA AgriRange Energizers 9. WARRANTY 9.1 For Assistance If you have any questions or need further assistance, or for more information on our complete range of electric fencing products, please see the JVA website at www.jva-fence.com.au www.jva.security.co.za 9.2 Service or Repairs If service is required, package your energizer carefully and return it to the place of purchase or your nearest JVA distributor along with your proof of purchase.
- Page 22 For full par culars of our ranges of e The JVA range of agricultural and security electric fence energizers are the result of a joint venture between the Australian company, Pakton Technologies and South African...
