JIG FOR SERVICING
The following jigs (extension cable kit) are used when repairing the PCBs.
Order the jigs from your dealer if necessary.
CAUTION : Incorrect connections may cause malfunction.
•
Connection of Jig for DIGITAL PCB
-Items to Be Prepared-
8U- 110084S
:
Insulation sheet (Not supplied)
Ground lead (Not supplied)
-Procedures-
(1) Remove the screws.
(2) Remove the connector PCB.
EXTENSION UNIT KIT
:
1 sheet
:
1 pc
N1001
N5003 N5004
N1804
:
1 Set
Front side
N1805
77
