Denon AVR-X5200W Service Manual

Integrated network av receiver
Hide thumbs Also See for AVR-X5200W:
Table of Contents

Advertisement

Quick Links

e
AVR-X5200W
• For purposes of improvement, specifications and design are subject to change without notice.
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
SERVICE MANUAL
MODEL
INTEGRATED NETWORK AV RECEIVER
JP
E3
E2
P P
e
D&M Holdings Inc.
Ver. 2
Please refer to the
MODIFICATION NOTICE.
EK
EA
E1
E1C E1K
P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVR-X5200W and is the answer not in the manual?

Questions and answers

Related Manuals for Denon AVR-X5200W

Summary of Contents for Denon AVR-X5200W

  • Page 1 MODIFICATION NOTICE. SERVICE MANUAL MODEL E1C E1K AVR-X5200W INTEGRATED NETWORK AV RECEIVER • For purposes of improvement, specifications and design are subject to change without notice. • Please use this service manual with referring to the operating instructions without fail.

  • Page 2: Table Of Contents

    CONTENTS ABOUT THIS MANUAL .............3 CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK ...115 What you can do with this manual ..........3 LEVEL DIAGRAM ..............116 Using Adobe Reader (Windows version) ........4 GND DIAGRAM ..............124 SAFETY PRECAUTIONS ............6 POWER DIAGRAM ..............125 NOTE FOR SCHEMATIC DIAGRAM .........7 CPU DIAGRAM ..............126 NOTE FOR PARTS LIST ............7...

  • Page 3: About This Manual

    ABOUT THIS MANUAL Read the following information before using the service manual. What you can do with this manual Search for a Ref. No. (phrase) Jump to the target of a schematic diagram connector (Ctrl+Shift+F) You can use the search function in Acrobat Reader to search for a Ref.

  • Page 4: Using Adobe Reader (Windows Version)

    Using Adobe Reader (Windows version) Add notes to this data (Sign) Magnify schematic / printed circuit board diagrams - 1 TheSignfunctionletsyouaddnotestothedatain (Ctrl+Space, mouse operation) this manual. Savethefileonceyouhavefinishedaddingnotes. Press Ctrl+Spaceonthekeyboardanddragthe [Example using Adobe Reader X] mousetoselecttheareayouwanttoview. On the "View" menu, click "Sign". • Theselectedareaismagnified.
  • Page 5 Magnify schematic / printed circuit Magnify schematic / printed circuit board diagrams - 2 board diagrams - 3 (Pan & Zoom function) (Loupe Tool function) ThePan&Zoomfunctionletsyouseewhichpartof TheLoupeToolfunctionletsyoumagnifyaspecific amagnifieddiagramisbeingshowninaseparate part of a diagram in a separate window. window. [Example using Adobe Reader X] On the "View"...

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS The following items should be checked for continued protection of the customer and the service technician. leakage current check Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set is defective.

  • Page 7: Note For Schematic Diagram

    NOTE FOR SCHEMATIC DIAGRAM WARNING: Partsindicatedbythe z markhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer. CAUTION: Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassisresistancecheck. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set is defective. WARNING: DONOTreturnthesettothecustomerunlesstheproblemisidentifiedandremedied.
  • Page 8 Personal notes:...

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS n Audio section n Tuner section • Power amplifier Reception frequency range： FM 87.5 MHz - 107.9 MHz(for E3) FM 87.5 MHz - 108.0 MHz(for E2, E1C) Rated output : AM 530 kHz - 1710 kHz(for E3) Front： AM 522 kHz - 1611 kHz(for E2, E1C) 140W+140W (8Ω, 20Hz - 20kHz with 0.05% T.H.D.) Effective sensitivity：...

  • Page 10: Precautions During Service

    PRECAUTIONS DURING SERVICE Initializing This Unit Initialize this unit if you have replaced the microcomputer, one of the parts around the microcomputer, or the digital PCB. Press the power button to turn off the power. Hold down buttons "CURSOR d " and "CURSOR f " at the same time and press the power button to turn on the power. Release the buttons after confirming that the display flashes in intervals of approximately 1 second.

  • Page 11: Disassembly

    DISASSEMBLY • Remove each part in the order of the arrows below. • Reassemble removed parts in the reverse order. • Read "Precautions During Work" before reassembling removed parts. • If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work.
  • Page 12 Explanatory Photos for DISASSEMBLY • The angles from which the photos are taken are shown by "Photo angle: A, B, C, D". • See the diagram below about the shooting direction of each photograph. • Photographs with no shooting direction indicated were taken from the top of the unit. •...

  • Page 13: Front Panel Assy

    1. FRONT PANEL ASSY Proceeding : TOP COVER → FRONT PANEL ASSY (1) Remove the screws. View from the bottom (2) Remove the screws. Remove the STYLE PIN, HOLDER, FFC and connector wire. N6401 HOLDER STYLE PIN N904 N901...

  • Page 14: Radiator Assy

    2. RADIATOR ASSY Proceeding : TOP COVER → FRONT PANEL ASSY → RADIATOR ASSY (1) Remove the STYLE PIN and connector wire. Remove the screws. STYLE PIN N5812 N5842 N5832 N5831 L-AMP CONNECT R-AMP CONNECT (2) Remove the connector wire. L-AMP CONNECT R-AMP CONNECT N5814...

  • Page 15: Smps Assy

    3. SMPS ASSY Proceeding : TOP COVER → FRONT PANEL ASSY → RADIATOR ASSY → SMPS ASSY (1) Remove the screws. ↑Shooting direction: A↑ Shooting direction: C (2) Cut the wire clamp, then remove the connector wires. N6502 N6501...

  • Page 16: Power Trans

    4. POWER TRANS Proceeding : TOP COVER → FRONT PANEL ASSY → RADIATOR ASSY → SMPS ASSY → POWER TRANS (1) Remove the screws. Remove the HOLDER. HOLDER (2) Remove the STYLE PIN and connector wire. STYLE PIN STYLE PIN N6012 N6201 N9022...

  • Page 17: Back Panel Assy

    5. BACK PANEL ASSY Proceeding : TOP COVER → FRONT PANEL ASSY → RADIATOR ASSY → SMPS ASSY → POWER TRANS → BACK PANEL ASSY (1) Remove the screws. ↑Shooting direction: A↑ Shooting Shooting direction: D direction: C...

  • Page 18: Special Mode

    ↑ ↑ (E3 and E2 model only) (See page) If there are multiple DENON AV receivers in the same area, this mode stops the other AV receivers from being operated concurrently with Remote ID Setup Mode ↑ ↑ this device.

  • Page 19: Version Display Mode

    1. Version Display Mode 1.1. Actions Version information is displayed when the device is started in this mode. 1.2. Starting up Hold down buttons "SETUP" and "OPTION" at the same time and press the power button to turn on the power. Press the "OPTION"...
  • Page 20 u GUI SFLASH : G U I : 7 0 1 Z * * * * Z ： Region code(E3/E2=1, E1C=5) i Ethernet 1st Boot Loader, Hardware ID : E t h e r n e t F B L * * * * * * - A A AA :Hardware ID o Ethernet 2nd Boot Loader, Rhapsody Flag :...
  • Page 21 1.4. Error display See the table below for descriptions of displayed errors and countermeasures for these. Display order is q , w , e , r , t , y , u . Condition States Display TROUBLE SHOOTING The model name, brand name and region F I R M E R R O R information written in the firmware are...
  • Page 22 1.5. Version Display in the Setup Menu Follow the steps below to display the firmware information. (1) Press the "SETUP" button on the remote control. (2) Select "General - Information - Firmware". The version information is displayed as a 14-digit number as shown in the screenshot below. General/Firmware Version XXXX - XXXX - XXXX - XX...

  • Page 23: Panel / Remote Lock Selection Mode

    2. PANEL / REMOTE LOCK Selection Mode 2.1. Actions Turn the PANEL LOCK and REMOTE LOCK modes on and off. 2.2. Starting up Hold down buttons "STATUS" and "INFO" at the same time and press the power button to turn on the power. Select the mode using the button "CURSOR f ", and press the button "ENTER"...

  • Page 24: Selection Modes For Service-Related Operations

    3. Selection Modes for Service-related Operations 3.1. Actions Select diagnostic mode (service path check mode), protection history display mode, or 232C standby clear mode. 3.2. Starting up Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power. Select the mode using the button "CURSOR f ", and press the button "ENTER"...
  • Page 25 Personal notes:...
  • Page 26 3.4 PROTECTION DIAGRAM AVR-X5200 ASO/DC/THERMAL PROTECTION DIAGRAM 8U-110157-5 L AMP CONNECT UNIT 8U-110130-10 R AMP CONNECT UNIT 8U-110157-1 P.AMP UNIT 8U-110157-1 P.AMP UNIT 8U-310150 DIGITAL UNIT N101 N101 13P-SOCKET(C125Z2) 13P-SOCKET(C125Z2) TR Thermal TR Thermal N5801 N5805 13P-PLUG(C125Z1) 13P-PLUG(C125Z1) TR_THERMAL_B 109 PE0 TR_THERMAL_A FANDET_HIGH 110 PD7...
  • Page 27 3.5. DIAGNOSTIC MODE (Service Path Check Mode) 3.5.1. Actions This function is convenient for confirming problem paths in the product and executing a path check after repair. The Video and Audio paths can be checked. The backup data is not rewritten. 3.5.2.
  • Page 28 Paths confirmation item Display Settings Contents of confirmation Remarks Input Source : CBL/SAT ・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R) A 0 6 : A D (MAIN ZONE) Input Mode : Analog(fixed) ・...
  • Page 29 Paths confirmation item Display Settings Contents of confirmation Remarks Front Amp>>Height 1 Input Source : CBL/SAT ・Analog input ⇒ Speaker output (Height1 L/R → Top Front L/R） A 2 0 : F - A M P H E I G H T Input Mode:Auto ・Analog input ⇒...
  • Page 30 3.5.6. Video system confirmation items fig. XX: See the block diagram of the fig.XXth. Paths confirmation item Display Settings Contents of confirmation Remarks Analog Video Input Source : CBL/SAT ・Component input ⇒ Component output V 0 1 : V I D E O P A S S fig.16 Video Convert(IP Scaler) : OFF, All sources...

  • Page 31: Diagnostic Path Diagram

    DIAGNOSTIC PATH DIAGRAM fig.01 AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL...
  • Page 32 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 33 fig.02b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 34 fig.03a AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 35 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 36 fig.03c AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 37 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 38 fig.04b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 39 fig.05a AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 40 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 41 fig.05c AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 42 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 43 fig.06b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 44 fig.07 AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 45 fig.08 AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 46 fig.09 AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 47 DA_SW2 fs Assign Sel. DA_RSV O U T P U T Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 48 fig.10b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 49 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 50 fig.11b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 51 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 52 fig.12b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 53 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 54 fig.13b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 55 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 56 fig.14b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 57 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 58 fig.15b AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 59 fig.16 AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 60 fig.17 AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 61 fig.18 AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 62 fig.19 AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 63 fig.20a AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 64 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 65 fig.20c AVR-X5200 BLOCK DIAGRAM (A.AUDIO/Z2,3HPF) H/P OUT PREOUT PRE_FL PRE_FR PRE_C PRE_SW1 PRE_SW2 PRE_SL PRE_SR PRE_SBL X7200/AV8802 PRE_SBR PRE_FWL PRE_FWR 8ch EXT.IN PRE_HL1 PRE_FL PRE_HR1 EXT-FL PRE_FR HDAM AV8802 PRE_HL2 EXT-FR PRE_HR2 EXT-C EXT-SW VOLUME IC1 EXT-FL (FLIN1) 9ch AMP SP OUT EXT-SL DA-FL (FLIN2)
  • Page 66 fig.21a AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 67 DA_SW2 fs Assign Sel. O U T P U T DA_RSV Wired Network I2S_CX870/CY920 Input Netowrk Module DSD_CX870/CY920 DLHD AVR-X5200 DENON Link HD CX870/CY920 Generator Module O U T P U T DA_SL CX870/CY920_VBUclk USB-A CX870/CY920_VBUSdata(8bit) Input(FRONT) Main ZONE Div.
  • Page 68 fig.22 AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 69 fig.23 AVR-X5200 BLOCK DIAGRAM (VIDEO) DIGITAL PCB BLOCK Z2 SPDIF TO D.AUDIO (SPDIF) DIGITAL AUDIO SPDIF_Z2HDMI HDMI TMDS BLOCK DIAGRAM HDMI 1 INPUT HDMI HDMI TMDS HDMI 2 Matlix SW TMDS MONITOR1 INPUT HDMI 3 ZONE2 HDMI TMDS MN864778 HDMI 3 INPUT HDMI TMDS...
  • Page 70 3.6. Protection History Display Mode 3.6.1. Actions This mode records and displays an event in which the THERMAL, CURRENT, ASO or DC protection was activated. If protections have been activated multiple times, the latest protection operation is recorded. 3.6.2. Starting up Hold down buttons "STATUS"...
  • Page 71 3.6.4. Clearing the Protection History There are two ways to clear the protection history. (a) Start Protection History Display Mode. Press the button "STATUS" to display the protection history. Press and hold the button "ENTER" for 3 seconds. P R O T E C T H I S T O R Y : D C Press and hold the button "ENTER"...
  • Page 72 3.8. Operation Info Mode 3.8.1. Actions This mode displays the accumulated operating time, power on count and each protection count. 3.8.2. Starting up Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power. Select the "4.
  • Page 73 3.9. TUNER STEP mode (E2/E3 only) 3.9.1. Actions This is a special mode for enabling reception STEP of the ANALOG TUNER to be changed. 3.9.2. Starting up Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power. Select the "5.

  • Page 74: Remote Id Setup Mode

    4. Remote ID Setup Mode 4.1. Actions This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are used in the same room. 4.2. Starting up Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power.

  • Page 75: Protection Pass Mode

    5. Protection Pass Mode 5.1. Actions • This mode allows the power to be turned on without activating protections. • This is the same as normal power-on, except that protections are not activated. 5.2. Operations Hold down buttons "CURSOR 0 ", "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power.

  • Page 76: Cx870 / Cy920 Initialization Mode

    7. CX870 / CY920 Initialization Mode 7.1. Actions The following items are initialized. (1) Favorites (2) Quick Select (3) Presets (4) Internet Radio Recently Played (5) Flickr contacts (6) User ID (7) Resume Playback station 7.2. Operations (1) Select "Online Music" (2) Hold down buttons "DIMMER"...

  • Page 77: Jig For Servicing

    JIG FOR SERVICING The following jigs (extension cable kit) are used when repairing the PCBs. Order the jigs from your dealer if necessary. CAUTION : Incorrect connections may cause malfunction. • Connection of Jig for DIGITAL PCB -Items to Be Prepared- 8U- 110084S EXTENSION UNIT KIT 1 Set...
  • Page 78 (3) Remove the DIGITAL PCB from the chassis and turn it over. Place an insulation sheet larger than the PCB underneath the DIGITAL PCB. Connect the earth of the PCB to the chassis using an earth wire, etc. PCB DIGITAL Insulation sheet CHASSIS-HDMI CONNECTOR (4) Connect the expansion cables.

  • Page 79: Procedure After Replacing The Microprocessor, Etc

    PROCEDURE AFTER REPLACING THE MICROPROCESSOR, ETC. The procedure after replacing the u-COM (microprocessor), flash ROM, etc. is as follows. Proce- dure after PCB Name Ref. No. Description Remark Replace- ment R5F56108VNFP SOFTWARE: Main DIGITAL U5001 DIGITAL U2101 R5F5210ABDFP SOFTWARE: Sub U103/U203/ MX25L1606EM2I-12G SOFTWARE: DSP1 / 2 / 3 / 4 ROM...
  • Page 80 1.3. File structure on USB Memory Copy the update files to the USB memory with the following structure: USB memory root Model Name Model Area Product ID AVR-X5200WE3 North America (E3) 000100710100 AVR-X5200WE2 Europe (E2) 000100710200 AVR-X5200WE1C China (E1C) 000100710500 + firmwares + 000100XXXXXX + APLD.bin...
  • Page 81 1.5. Start the update. Hold down buttons "STATUS" and "OPTION" at the same time and press the power button to turn on the power. 1.6. Display during USB update The following message appears on the display after around 30 seconds Display * F I R M W A R E U P D A T E...
  • Page 82 1.10. About the error code See the table below for error codes and details of faults when the firmware is updated through USB memory. Error USB Update Error Display Details of Error code Coping strategies Code C o n n e c t i o n f a i l Disconnect and connect the USB Unable to detect USB.
  • Page 83 Error USB Update Error Display Details of Error code Coping strategies Code This unit automatically retries several times. Wait until the FL display stops. M a i n * * * m i n Block Write failed while rewriting If the FL display stops at the Error dis- Main.
  • Page 84 Error USB Update Error Display Details of Error code Coping strategies Code This unit automatically retries several times. Wait until the FL display stops. M a i n * * * m i n Time Out in USB Check. If the FL display stops at the Error dis- C o n n e c t i o n F a i l 3 9 play, press and hold the "Power opera- tion"...
  • Page 85 Error USB Update Error Display Details of Error code Coping strategies Code This unit automatically retries several NACK received in response or no times. Wait until the FL display stops. S u b * * * m i n response from Sub for L com- If the FL display stops at the Error dis- U p d a t i n g f a i l...
  • Page 86 Error USB Update Error Display Details of Error code Coping strategies Code This unit automatically retries several Abnormal data in Update Packet times. Wait until the FL display stops. G U I * * * m i n received from CX870 / CY920 If the FL display stops at the Error dis- U p d a t i n g f a i l...
  • Page 87 Error USB Update Error Display Details of Error code Coping strategies Code This unit automatically retries several times. Wait until the FL display stops. E t h e r I M G * * * m i n Failed to transit to Application If the FL display stops at the Error dis- Mode.

  • Page 88: Updating By Dpms

    HDMI (ASSIGNABLE) ZONE2 MONITOR1 MONITOR2 To WAN port Blu-ray GAME MEDIA AUX2 PLAYER /SAT Router Denon Link HD NETWORK 1 CBL/SAT 4 GAME FRONT CENTER FRONT WIDE 1 CBL/SAT 4 GAME 1 CBL/SAT 2 DVD MONITOR/ZONE2 To LAN port 2 DVD...
  • Page 89 2.3. About the error code See the following table for details on the error code, details of the error code, display and coping strategies when updating the firmware from DPMS. (DPMS:Denon Product Management Server). Error DPMS Update Error Display Details of Error code...
  • Page 90 Error DPMS Update Error Display Details of Error code Coping strategies Code Abnormal data in Update Packet M a i n * * * m i n Turn on the power again. Update will received from CX870 (PacketNo- start automatically. U p d a t i n g f a i l Error).
  • Page 91 Error DPMS Update Error Display Details of Error code Coping strategies Code Check the network connection. Update M a i n * * * m i n Connect Time Out by DPMS con- in an environment where there is a nection.
  • Page 92 Error DPMS Update Error Display Details of Error code Coping strategies Code NACK received in response or no S u b * * * m i n Turn on the power again. Update will response from Sub for L com- start automatically.
  • Page 93 Error DPMS Update Error Display Details of Error code Coping strategies Code Check the network connection. Update E t h e r I M G * * * m i n IP Address acquisition failure in an environment where there is a (Time Out).
  • Page 94 Device display during firmware update Display of target device during firmware update. Target device DPMS Update Display Error code when an error occurs M a i n * * * m i n 10 - 16 Main CPU 36 - 3F U p d a t i n g * * % 50 - 52...

  • Page 95: Adjustment

    ADJUSTMENT Adjusting Idling Current 1. Preparation (1) Prepare a DV voltmeter. (2) Place the unit in normal usage conditions, away from highly ventilated areas such as next to an air conditioning machine or electric fan. The set requires an ambient temperature of 15℃ to 30℃ and standard humidity. (3) Settings of This Unit •...

  • Page 96: Surround Modes And Parameters

    SURROUND MODES AND PARAMETERS Contents Connections Playback Settings Tips Appendix Sound modes and channel output S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.” (v p. 230). Channel output Front L/R Center...
  • Page 97 Contents Connections Playback Settings Tips Appendix Surround Parameter Audyssey Dialog Tone Restorer Sound mode Enhancer Center Center Gain Dunamic EQ Dunamic Audyssey Audyssey MultEQ ® Spread Volume ® XT 32 Direct/Pure Direct (2-channel) Direct/Pure Direct (Multi-channel) DSD Direct (2-channel) DSD Direct (Multi-channel) Stereo Multi Ch In Dolby Surround...
  • Page 98 Contents Connections Playback Settings Tips Appendix Types of input signals, and corresponding sound modes F This indicates the default sound mode. S This indicates the selectable sound mode. 2-channel signal Multi-channel signal Analog / Dolby DTS-HD DTS ES DTS ES Dolby Dolby Dolby...

  • Page 99: Trouble Shooting

    TROUBLE SHOOTING 1. POWER 1.1. The unit does not power on The unit does not power on Does the power indicator on Does the power indicator on the the front panel flash in green front panel flash in red when the or white when the power is power is turned on? turned on?

  • Page 100: Analog Video

    2. Analog video b Function is set to CBL/SAT. b ZONE2 is set to POWER ON (functin CBL/SAT). Input CVBS CVBS MONITOR OUT COMPONENT MONITOR OUT Z2 CVBS MONITOR OUT To A Not output To A Input COMPONENT CVBS MONITOR OUT COMPONENT MONITOR OUT Z2 CVBS MONITOR OUT Not output...
  • Page 101 Extend DIGITAL UNIT using a jig Check power supply voltage. Defective connection of N9014. AUDIO/VIDEO PCB Power supply IC flaw. V +3.3V : C3748 + q SPEAKER PCB V -5V : C3749 - w U6203(V+3.3V), U6204(V-5V) (See page) Check the I2C control signsl of video selector IC (U3703) Defective connection of the connector.

  • Page 102: Hdmi/Dvi

    (7) Are the HDMI output settings of the Blu-ray/DVD player correct? and set the HDMI output correctly. (8) If using a DENON Blu-ray/DVD player, is the "HDMI" indicator of the fluorescent display lit? Proceed to YES if using a Blu-ray/DVD player from another com- pany.
  • Page 103 (11) Are a picture and sound output when a different Blu-ray/DVD The Blu-ray/DVD player is faulty. player is used? Check the TV. Use a TV that supports HDCP. Computer monitors can- (12) Does the TV support HDCP? not be used. If the TV does not support 1080P/4K, a picture cannot be (13) Does the TV support 1080P/4K? output even if the Blu-ray/DVD player is set to 1080P/4K.

  • Page 104: Audio

    4. AUDIO 4.1. AUDIO CHECK No audio output See"Audio Check PATH" (114 page). CHECK1 INPUT SURROND MODE SOURCE Check the ANALOG AUDIO BLOCK Audio output OK? ANALOG 2CH DIRECT ANALOG CHECK2 INPUT SURROND MODE SOURCE Check the DIGITAL AUDIO Legacy BLOCK Audio output OK? COAX or OPT...
  • Page 105 4.2. Power AMP (AMP PCB) No audio output. Protection is activated. Is the power transistor open or short circuited? Replace the power transistor. DHCT-A3 / DHCT-C3 Is the emitter resistor of the power transistor open? Replace the emitter resistor. 0.47Ω Is the base resistor of the power transistor open? Replace the base resistor.
  • Page 106 4.3. Analog audio No audio output. Is a voltage of ±7V supplied to Repair the ±7V power supply. SPEAKER PCB N6203 1-3pin? Is there an audio signal in L-AMP Repair the power amplifier. CONNECT PCB N5811? Connect the connectors correctly. Is the connector correctly connected with DIGITAL PCB? Repair the DIGITAL PCB.

  • Page 107: Network/Bluetooth/Usb

    5. Network/Bluetooth/USB 5.1. Cannot connect to the network Check the connection environment Insert the LAN cable correctly and then turn Is the LAN cable correctly inserted? on the power again. Check the connection environment Set the IP address, etc. correctly. If the IP settings are fixed, check that no Are the network settings of this unit correct? other devices have the same IP address and...
  • Page 108 The circuit between the AC inlet and N6502 Can a voltage (5V) be confirmed between pin 2 and pin 5 of is faulty. Check the SMPS PCB. N6502? Can an output voltage (3.3V) to Is D5V_POWER (U5001 uCOM 85pin) The circuit of D5V_POWER between U611(DC-DC Conv.) be confirmed? "Hi"...
  • Page 109 5.2. Cannot connect to the Bluetooth Can a voltage (5V) be confirmed between pin 1 and pin 4 of N903 on The circuit between the AC inlet and N903 is faulty. DIGITAL PCB? Check the SMPS PCB. The circuit between N903 of the DIGITAL PCB and Can a voltage (5V) be confirmed pin 10 of N901 on Bluetooth PCB? N1 of the Bluetooth PCB are faulty of wire or board.
  • Page 110 5.3. A connected USB device is not recognized. Check the USB device being used Is a USB hub being used? Do not use a USB hub. This unit supports devices in the FAT16 and FAT32-formatted mass storage class, MTP- Is the USB device supported by this unit? compatible devices and iPods (with the exception of some models).
  • Page 111 DIGITAL test point 63301015010AS B1801 8U-310150 N1001 R5044 C1820 N1808 N5008 N5009 C9013 N5003 C5033 N5004 R5045 N1805 C1821 R5075 C9012 C5031 R5046 R5047R5048 R5049 R5050 U5004 B601 C3029 L1802 C3027 C9006 R5051 R5052 R5053 C3026 C5018 C5019 C5020 C5021 R5026 C1819 C9007...

  • Page 112: Smps

    6. SMPS DC 5V is not output. Replace the U6503 (TOP267EG) and Is U6503 (TOP267EG) damaged? D6503. Has a fuse (F70) broken? Replace the damaged part. Are there the damage in U6503 and D6503 / C6506? Are there any short circuits caused by Repair the short circuited area by the the soldering of the PCB? soldering of the PCB.
  • Page 113 Operation waveform for each part Primary drain After primary side rectification (Caution: High voltage, electric shock) (Caution: High voltage, electric shock) C6512 0.01/250 After secondary rectifications R6511 2.2M (2.2M) Z6516 Europe/China=OPEN 3X10_CBTS(S)-Z R6512 D6503 2.2M D3SB60 Z651 5 (2.2M) R6521 C6532 HEAT_SINK(SMPS)-A C6511 0.01/250...

  • Page 114: Audio Check Pass

    AUDIO CHECK PASS See troubleshooting "4.1. AUDIO CHECK"(104 page). HDMI BLOCK CHECK6 HDMI HDMI OUTPUT INPUT CHECK5 HDMI INPUT CHECK4 HDMI Tranceiver HDMI Tranceiver MN8647771 MN8647771 TMDS FRONT BUFFER HDMI AD8195 INPUT Digital audio BLOCK SPDIF COAXIAL PCM9211PTR DIGITAL INPUT OPTICAL PCM1690DCAR CHECK2...

  • Page 115: Clock Flow & Wave Form In Digital Block

    CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK WAVE FORM MCKO Z2DIR256fs Z2DAC256fs U1004 U5002 BCKO Z2DIR64fs Z2DAC64fs LC89091JA PCM5100 RXIN LRCKO ZONE2 DIR Z2DIRfs Z2DACfs LRCK ZONE2 DAC DATAO Z2DIRDATA Z2DACDATA MCKO Z3DIR256fs Z3DAC256fs U1005 U5003 BCKO Z3DIR64fs Z3DAC64fs RXIN LC89091JA PCM5100...

  • Page 116: Level Diagram

    LEVEL DIAGRAM AVR-X5200 LEVEL DIAGRAM FRONT ch LINE IN MUTE PRE OUT ＋ GAIN PCM1690 ＋ ＋ AK5358 － － ANALOG H/P OUT ZONE2 x 3pcs SPEAKER ＋ ZONE3 R2A15220FP EXT IN +30dB SP OUT R2A15220FP MAX. OUTPUT 3.8Vrms 4.48Vrms/8Ω Differential Out PCM1690 2.82Vrms:A/D FULL SCALE...
  • Page 117 AVR-X5200 LEVEL DIAGRAM CENTER ch MUTE PRE OUT GAIN PCM1690 ＋ ＋ － － R2A15220FP x 3pcs ＋ SPEAKER +30dB SP OUT R2A15220FP MAX. OUTPUT 3.8Vrms 4.48Vrms/8Ω Differential Out PCM1690 2.83Vrms=0dBFS MAX. SIGNAL LEVEL +20dB +20dB DOLBY LIMIT LEVEL (ALLch-3dBFS) +29dB -10dBFS +10dB...
  • Page 118 AVR-X5200 LEVEL DIAGRAM SUBWOOFER ch PCM1690 ＋ ＋ MUTE PRE OUT － － R2A15220FP GAIN x 3pcs +30dB R2A15220FP MAX. OUTPUT 3.8Vrms Differential Out PCM1690 2.83Vrms=0dBFS +20dB +20dB MAX. SIGNAL LEVEL -10dBFS DOLBY LIMIT LEVEL (ALLch-3dBFS) +10dB +10dB PREOUT -20dBFS 310mVrms 200mVrms PRE OUT...
  • Page 119 AVR-X5200 LEVEL DIAGRAM SURROUND ch MUTE PRE OUT GAIN PCM1690 ＋ ＋ － － R2A15220FP x 3pcs ＋ SPEAKER +30dB SP OUT R2A15220FP MAX. OUTPUT 3.8Vrms 4.48Vrms/8Ω Differential Out PCM1690 2.83Vrms=0dBFS MAX. SIGNAL LEVEL +20dB +20dB DOLBY LIMIT LEVEL (ALLch-3dBFS) +29dB -10dBFS +10dB...
  • Page 120 AVR-X5200 LEVEL DIAGRAM SURR.BACK ch R2A15220FP MUTE PRE OUT GAIN PCM1690 ＋ ＋ － － x 3pcs ＋ SPEAKER +30dB SP OUT R2A15220FP MAX. OUTPUT 3.8Vrms 4.48Vrms/8Ω Differential Out PCM1690 2.83Vrms=0dBFS MAX. SIGNAL LEVEL +20dB +20dB DOLBY LIMIT LEVEL (ALLch-3dBFS) +29dB -10dBFS +10dB...
  • Page 121 AVR-X5200 LEVEL DIAGRAM FRONT WIDE ch R2A15220FP MUTE PRE OUT GAIN PCM1690 ＋ ＋ － － x 3pcs ＋ SPEAKER +30dB SP OUT R2A15220FP MAX. OUTPUT 3.8Vrms 4.48Vrms/8Ω Differential Out PCM1690 2.83Vrms=0dBFS MAX. SIGNAL LEVEL +20dB +20dB DOLBY LIMIT LEVEL (ALLch-3dBFS) +29dB -10dBFS +10dB...
  • Page 122 AVR-X5200 LEVEL DIAGRAM HEIGHT1,2 ch R2A15220FP MUTE PRE OUT GAIN PCM1690 ＋ ＋ － － x 3pcs ＋ SPEAKER +30dB SP OUT R2A15220FP MAX. OUTPUT 3.8Vrms 4.48Vrms/8Ω Differential Out PCM1690 2.83Vrms=0dBFS MAX. SIGNAL LEVEL +20dB +20dB DOLBY LIMIT LEVEL (ALLch-3dBFS) +29dB -10dBFS +10dB...
  • Page 123 R2A15220FP R2A15220FP AVR-X5200 LEVEL DIAGRAM from SPEAKER ZONE2/ZONE3 ＋ LINE IN SB-ch ＋ MAIN from SPEAKER ＋ FRONT WIDE-ch ZONE2 NJW1194 TONE MONO MUTE PREOUT PCM5100 MONO ZONE3 NJW1194 TONE MONO MUTE PREOUT PCM5100 MONO +30dB SP OUT NJW1194 MAX. OUTPUT 3.8Vrms 4.48Vrms/8Ω...

  • Page 124: Gnd Diagram

    GND DIAGRAM AVR-X5200/7200 GND DIAGRAM Analog GND Power GND FRONT PANEL DAC GND A.Video GND FRONT USB FRONT HDMI VAUX F.SELECTOR BUTTONS VOLUME ETC GND H/P GND Digital GND FRONT JACK POWER AMP UNIT POWER AMP UNIT BACK PANEL BACK PANEL ETHERNET HDMI INPUT/OUTPUT DSP1...

  • Page 125: Power Diagram

    POWER DIAGRAM AVR-X5200 BLOCK DIAGRAM (P.SUPPLY) DIGITAL PCB BLOCK ＡＣ　ＰＬＵＧ 5.2V 5.2V FRONT_USB_VBUS NCP380 FRONT_USB_VBUS MAIN_POWER cam_xclka RESET/B_DOWN form_870 M+3.3V CONTR OLLER MAINCPU_CONTROL NJM2845DL MAIN CPU M+3.3V SWM+3.3V 870_CONTROL 5.2V DC-DC_CONV. 3.3V 3.3V 3.3V NET3.3V SWM+3.3V HD_RADIO EX3AV NET3.3V 2SA2018 SWM3.3V M3.3V CX870...

  • Page 126: Cpu Diagram

    CPU DIAGRAM AVRX5200/X7200/AV8802 CPU Control Block Diagram ZONE3 ZONE3 OUT Control signal ANALOG ZONE2 ANALOG ZONE2 /3 SELECTOR Control signal SELECTOR Analog Audio Signal VOLUME ZONE2 OUT Digital Audio Signal HPF/TONE Analog Video Signal INPUT INPUT ZONE2 Digital Video Signal ZONE2 /ZONE3 HDMI Signal...

  • Page 127: Printed Wiring Boards

    PRINTED WIRING BOARDS Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu). DIGITAL (A SIDE) DAC (A SIDE) 63301015010AS C5568 R5384 C5256 R5303 R5307 C5018 C5240 C5242 R5243 R5380 B1801 R5018 R5242 R5238 R5239 N1001 8U-310150 R5295 R5044 C1820 N1808 R5231 C5324 C5236...
  • Page 128 CONNECTOR-1 (A SIDE) CONNECTOR-1 (B SIDE) AUDIO VIDEO (A SIDE) AUDIO VIDEO (B SIDE) CONNECTOR-3 (A SIDE) CONNECTOR-3 (B SIDE) N9016 TO AUDIO/VIDEO 8U-210163-6 CONNECTOR-3 UNIT TO PHONO/232C FRONT JACK FRONT JACK N9017 (A SIDE) (B SIDE) CONNECTOR-2 (A SIDE) CONNECTOR-2 (B SIDE) C5586 C5583...
  • Page 129 SPEAKER (A SIDE) HL SPEAKER (A SIDE) C6061 N6828 C6051 K6010 K6009 K6008 K6007 K6004 K6003 K6002 K6001 K6006 K6005 JV221 B6409 15.0 C6060 C6059 C6058 C6057 C6056 C6055 C6054 C6053 C6052 JV196 12.5 JV206 JV171 JV71 JV103 15.0 22.5 25.0 22.5 JV161...
  • Page 130 FLD (A SIDE) ON/STBY S6401 8U-110156-3 K6403 K6402 DOWN 15.0 S6412 J6406 15.0 BACK J6401 SETUP N6403 S6409 S6415 15.0 12.5 J6405 JV32 JV159 15.0 B6401 12.5 JV162 J6404 ENTER S6405 S6404 S6403 S6402 S6411 15.0 J6402 Q.SEL4 17.5 15.0 RIGHT LEFT JV35...
  • Page 131 AMP (A SIDE) AMP (B SIDE) L-AMP CONNECT (A SIDE) L-AMP CONNECT (A SIDE) R-AMP CONNECT (A SIDE) R-AMP CONNECT (A SIDE) N5842 N5841 Z106 N101 C101 (P=1.9) R131 Q111 R132 R101 N5822 N5821 N102 JV41 JV11 R130 N5801 Z5815 15.0 C114 R103...
  • Page 132 Bluetooth (A SIDE) Bluetooth (B SIDE) CX870 CONNECT (A SIDE) CX870 CONNECT (B SIDE) R960 R962 R906 R964 R959 R961 R958 R957 R963 C996 R974 C997 N901 B901 R975 L901 C905 R971 R970 8U-310201-2 R969 R968 N904 R9037 R915 R9038 R908 R9039 R9040...

  • Page 133: Schematic Diagrams (1/35 )

    N1804 N1805 N1808 TO N5202 TO N5909 6P-EHs MAINPW L1801 BLM21PG221 N1808 D5.2V L1802 BLM21PG221 D5.2V TO N6502 N1805 L1803 BLM21PG221 DGND N1804 N1806 B1801 L1804 BLM21PG221 33P-SOCKET(C125Z2) OPEN 21P-SOCKET(C125Z2) DGND M3-SIDE L1805 BLM21PG221 7200 only SN-M3 Q1909 HN1K02FU DA1.1V-2 DA1.1V TO 3A DA3.3V...

  • Page 134: Sch02_Dir Adc Zonedac

    TO 9A TO A1 TO 0B TO 1B TO 2B R1026 3.3K R1001 C1009 C1025 10/6.3 C1022 MC/SCL C1011 37 RXIN0 MDI/SDA 10/6.3 38 GNDRX MDO/ADR0 C1010 DIR_XIN 39 XTI DVDD 40 XTO DGND C1016 10/6.3 R1037 33x4 MAINDIR256fs 41 AGND SCKO C1018 0.1 R1037...

  • Page 135: Sch03_Audio Pld

    RX256fs/DSDMCK RX256fs/DSDMCK R1216 I N P U T TO 1C RX64fs/DSDSCK RX64fs/DSDSCK .PLDAERRMAIN T5 PLDAERRMAIN I N P U T RXSPDIF/DSD0 RXSPDIF/DSD0 RXSPDIF is common port with ARC I N P U T RXI2S0/DSD1 RXI2S0/DSD1 I N P U T RXI2S1/DSD2 RXI2S1/DSD2 I N P U T...

  • Page 136: Sch04_Dsp1

    TO B7 TO 3C TO 4C N402 OPEN DSPI_CLK DSP_MOSI DSP_MISO DSP1_CS DSP2_CS DSP3_CS DSP4_CS C151 1000P C152 L106 NFM18PS105R0J 3 C192 1000P C185 0 . 1 C155 0. 1 C156 1000P U103 A3V56S40GTP-60 R182 4.7K DSP1D0 R175 56x4 R176 56x4 DSP1D15 DQ15...

  • Page 137: Sch05_Dsp2

    TO B8 TO C3 TO 5C L206 NFM18PS105R0J 3 C234 1000P C235 C252 1000P C253 0 . 1 C236 0. 1 U203 C237 1000P A3V56S40GTP-60 R275 56x4 DSP2D0 R276 56x4 DSP2D1 5 DQ15 R248 4.7K VDDQ VSSQ DSP2D1 R275 56x4 R276 DSP2D14 R247...

  • Page 138: Sch06_Dsp3

    TO B9 TO 6C L306 NFM18PS105R0J3 C334 C352 1000P 0. 1 C353 0 . 1 C335 1000P U303 A3V56S40GTP-60 C336 C337 1000P DSP3D0 R375 56x4 R376 56x 4 DSP3D1 5 DQ15 VDDQ VSSQ DSP3D1 4 DSP3D1 R375 56x4 R376 56x 4 DQ14 C356 0 .

  • Page 139: Sch07_Dsp4

    TO B6 TO 7C L406 NFM18PS105R0J3 C452 1000P C434 0. 1 1000P C453 0 . 1 C435 U403 A3V56S40GTP-60 C436 C437 1000P DSP4D0 R475 56x4 R476 DSP4D1 5 56x 4 DQ15 VDDQ VSSQ DSP4D1 4 DSP4D1 R475 56x4 R476 56x 4 DQ14 C456 0 .

  • Page 140: Sch08_Main Cpu

    TO 8C TO 9C TO N5905 TO 0D TO C1 TO 1D TO N5907 N5003 N5004 TO A5 DGND R5047 C5018 R5048 C5019 R5049 C5020 R5050 C5021 R5051 C5022 R5052 C5023 R5053 C5024 DGND N5007 A-7V DGND A+7V DGND GREENLED GREENLED PREGND FRONT_RST...

  • Page 141: Sch09_Sub Cpu

    TO B2 TO C2 TO C4 TO C5 TO C6 TO C7 TO 2D TO 3D TO 4D TO 5D TO 6D TO 7D TO 8D TO D1 TO A6 R215 8 U2102 OPEN C2191 R2145 4.7K R2154 R2041 DAC_RST2 R2112 33x4 DAC_CCS2...

  • Page 142: Sch10_Decoder

    CEC5V DV5V DV3.3V DV1.8V DGND BLM21PG221 L2001 TVDD SD_R C2000 TO 9D VIN8 SD_B C2001 VIN9 SD_G C2002 VIN7 C2003 1000P RXB_2+ RXB_1+ RXB_0+ RXB_C+ ARC_B TVDD RXC_2+ RXC_1+ RXC_0+ RXC_C+ ARC_C RXD_2+ RXD_1+ RXD_0+ RXD_C+ ARC_D DV3.3V AB21 SYNC2 R2000 R2017 C2004...

  • Page 143: Sch11_Hdmi Sw1

    SCPU5V CEC5V Q2404 CEC3.3V TO 6E L2406 BLM21PG221 HPD5 CEC1.1V1 C2400 R2436 DGND Q2400 KRC402E-RTK KRC402E-RTK HP_DET RX5_5V SW1VDD33I O L2407 BLM21PG221 R2424 0 R2425 RX5_DDCDA DDC_SDA R2426 RX5_DDCCL DDC_SCK N . C . CE_REMOTE RX5_C- TXC- L2400 BLM21PG221 P3_HPD SW1VDD33 TXC_SHLD RX5_C+...

  • Page 144: Sch12_Hdmi Sw2

    CEC5V CEC3.3V Q2605 HPD1 L2606 TO 7E Q2604 CEC1.1V2 C2685 R2664 BLM21PG221 DGND KRC402E-RTK KRC402E-RTK SW2VDD33 R2659 HP_DET RX1_5V L2600 R2662 RX1_DDCDA BLM21PG221 DDC_SDA R2663 RX1_DDCCL DDC_SCK N . C . CE_REMOTE RX1_C- TXC- L2607 TXC_SHLD RX1_C+ BLM21PG221 TXC+ RX1_0- TX0- TX0_SHLD RX1_0+...

  • Page 145: Sch13_Ip Scaler

    DV5V DV3.3V L2815 DV1.8V BLM21PG221 DGND DVDD_TX AVDD3_1_TX PVDD_TX PVDD3_TX PVDD5_TX AVDD2_TX L2801 L2803 L2805 L2807 L2808 BLM21PG221 BLM21PG221 BLM21PG221 BLM21PG221 BLM21PG221 TO 9E L2817 BLM21PG221 DDR_1.8V PVDDR_TX CVDD1 PVDD6_TX DVDDIO_TX AVDD3_2_TX R2892 OPEN L2802 AVDD3_2_TX2 L2806 L2810 L2816 TX1_DDCSCL K20 R2893 OPEN BLM21PG221...

  • Page 146: Sch14_Ip Scaler Ddr

    TO F1 R3011 R3013 OPEN OPEN 1 A2 2 A3 1 A2 2 A3 7 A8 8 A9 7 A8 8 A9 DDR_1.8V DDR_1.8V DDR_1.8V DR_TXDQSB1 DDR_1.8V DGND DGND DGND DGND DR_TXDQSB3 10 B2 11 B3 16 B8 17 B9 10 B2 11 B3 16 B8...

  • Page 147: Sch15_Video Pld

    SD/HD M9 SD/HD TO D4 NET/HDMI R10 NET/HDMI RGB/YC T10 RGB/YC .PO8KI_C0/B0 .POHI_C5/R 1 VP3.3V . POHI_C6/R 2 . POHI_C8/R4 .POHI_C10/R6 . POHI_VSYN C VP3.3 V .POHI_Y0/B0 DGND DGND VPLD_TRANS2 T9 VPLD_TRANS2 VPLD_TRANS1 P8 VPLD_TRANS1 TO C8 VPLD_TRANS0 R9 VPLD_TRANS0 .PO8KI_C1/B1 920_VD0 920_VD2...

  • Page 148: Sch16_Hdmi Rx Tx

    SCPU5V CEC5V HDMI CEC3.3V 777AVDD33Tx CEC1.1V3 OUT 2 L3402 DGND BLM21PG221 TO 5F R3463 777AVDD11Tx PTX0_HPD PTX0_2+ TX2+ L3406 777PVDD33 PTX1_HPD PTX0_2- TX2_SHLD BLM21PG221 L3403 TX2- BLM21PG221 PTX0_1+ TX1+ PTX0_1- TX1_SHLD R3450 R3464 TX1- PTX0_0+ TX0+ PTX0_0- TX0_SHLD L3401 TX0- BLM21PG221 PTX0_C + TXC+...

  • Page 149: Sch17_Hdmi Supply

    U3601 DGND TO A7 NCP380HMUAJAATBG SCPU5V SCPU5V ILIM CEC_POWER R3609 FLAG# DV_POWER1 DV_POWER1 DV_POWER2 TO D8 DV_POWER2 CEC3.3V CEC1.1V CEC_POWER CEC_POWER L3622 L3600 L3608 L3616 BLM21PG221 BLM21PG221 BLM21PG221 BLM21PG221 20 PVIN VOUT 20 PVIN VOUT CEC1.1V1 21 PVIN 21 PVIN VOUT VOUT L3601...

  • Page 150: Sch18_Network

    TO A4 TO F2 TO D0 TO B5 TO B0 Basic Extended Connector Connector TO N905 TO N906 N607 N607 N608 C622 64P(GPEC244-3202B) 64P(GPEC244-3202B) N608 10/6.3 920_B4 R699 R715 920_VD0 OPENx4 920_B5 R699 OPENx4 R716 920_VD1 NET1.2V NET2.5V 920_B6 R699 OPENx4 R717 920_VD2...

  • Page 151: Sch19_Audio Video Connect

    N3001 N9018 N9019 N4818 TO N5904 TO N5906 TO N5908 TO N5910 N3001 N9019 N4818 N9018 33P-SOCKET(C125Z2) 17P-SOCKET(C125Z2) 19P-SOCKET(C125Z2) 21P-SOCKET(C125Z2) B3001 B3002 M3-SIDE M3-SIDE USA/CANADA ONLY PREGND TURST N3009 N3009 TUSCL 3P-PH TUSDA R3113 C3115 C3108 R3122 10/63 HDR_R R3108 OPEN R3118 HDRGND R3119...

  • Page 152: Sch20_Audio Volume

    TO F6 R3374 47Kx4 H/PIN_F L H/PIN_FL H/PIN_FR H/PIN_FR PREGND B3202 OPEN PREOUT_Z3R PREOUT_Z3R PREOUT_Z3L PREOUT_Z3L PREOUT_Z2 R PREOUT_Z2R K3102 RCA-637-00-04 DA_FR PREOUT_Z2 L PREOUT_Z2L DA_FL OPEN N3204 R3378 R3379 B3201 C3242 OPEN C3201 R3223 220/25 R3201 N3206 820K R3371 330P OPEN 47Kx4...

  • Page 153: Sch21_Preout

    U3501 C3538 R3577 NJM4556AD 220P H/PIN_FR R3578 C3536 N3501 [ 2 / 2 ] 10/63 C3540 OPEN R3534 100 100/16 R3532 S3501 R3530 R3526 R3528 G6J-2P-Y 2.2K 220K 220K R3527 R3529 R3531 220K 220K R3533 S3501 2.2K C3541 G6J-2P-Y R3579 100/16 C3537 R3535 100...

  • Page 154: Sch22_Video Selector

    TO F8 K3501 RCA-637-00-04 C3705 10/6.3 SAT_Y R3701 C3706 10/6.3 SAT_CB R3702 C3707 10/6.3 SAT_CR R3703 VAUX_V C3708 10/6.3 DVD_Y R3704 C3709 10/6.3 DVD_CB R3705 C3710 10/6.3 DVD_CR R3706 C3711 OPEN BD_Y K3502 R3707 OPEN OPEN C3712 OPEN BD_CB R3708 x 5 2 0 0 o p e n OPEN C3713...

  • Page 155: Sch23_Connect

    N5901 N5905 N5907 N5909 TO N1001 TO N5003 TO N5004 TO N1805 N5901 N5905 N5907 N5909 19P-PLUG(C125Z1) 33P-PLUG(C125Z1 17P-PLUG(C125Z1 21P-PLUG(C125Z1) C558 3 OPEN C558 4 OPEN C558 5 OPEN C558 6 OPEN N5903 TO N5206 N5903 33P-PLUG(C125Z1) N5902 N5902 33P-PLUG(C125Z1) TO N5001 C5577 0 .

  • Page 156: Sch24_Zonedac Adc

    DA3.3V D_GND DAC_CCLK TO 0G DAC_CCLK DAC_RST2 DAC_RST2 DAC_RST1 DAC_RST1 DAC_CDATA DAC_CDATA DAC_CCS2 DAC_CCS2 DAC_CCS1 DAC_CCS1 U5004 NJM2115M R5013 R501 9 C5045 C5043 4.7u R5023 10/63 ( 2 / 2 4.7K C5027 C503 6 R5024 10/63 470P R5011 R5020 OPEN 3.3K R5012 R5021...

  • Page 157: Sch25_Main Dac

    DACGND C5222 0. 1 DA+5V. A+7V. C5223 4.7u R5310 150K R5311 C5294 220/25 R5214 R5278 C5260 270P C5292 220/25 U5201 C5310 PCM1690 C5228 R5279 47/50 DAFL TO G1 DA3.3V ( 1 / 2 ) 1800P U5203 R5342 D_GND RSV2 RSV2 C5296 R5358 R5372...

  • Page 158: Sch26_Front Hdmi Usb

    N9999 OPEN N9998 OPEN MOSI R5501 R5502 R5503 R5504 MISO MISO OPEN K5501 A0D7ABAR19N0 Q5501 HPDF HPD/HEAC- KRC102S Q5502 KRC104S DDCDATA DDCCLK N5501 UTILITY/HEAC+ 25P-FFC CE_Remote DDC_SDA CKshield DDC_SDA DDC_SCL DDC_SCL TXEN. TXEN. TXEN HPDF HPDF DOshield RX_5V CEC5V CEC5V CEC3.3V D1shield CEC3.3V...

  • Page 159: Sch27_Speaker

    N6001-N6009 -HIGHB FRONT K6001 S6002 2P-SP-TERMINAL G5PA-28-MC_DC12 C6051 N6001 C6039 +HIGHB N6814 FRONT- R S6002 2200P OPEN 5P-EH OPEN FRONT_WIDE S6003 -HIGHB G5PA-28-MC_DC12 C6029 1000P S6003 N6002 +HIGHB K6002 5P-EH 2P-SP-TERMINAL FRONT_S.BACK S6004 C6052 C6040 FRONT-L G5PA-28-MC_DC12 N6805 OPEN 2200P OPEN -HIGHB S6004...

  • Page 160: Sch28_Reg

    RLYB+12V Q6204 F6203 J6208 KTC2026 J6212 FUSE(SCT2A ) 1N4003 SHORT D6216 SHORT D6217 1N4003 Q6202 KTC3875S A+7V D6218 1N4003 D6219 R6207 1N4003 R6206 J6210 SHORT N6201 5P-EH N6203 A_AC C6225 3P-SAN N6203 D6228 470/25 UDZS8.2B TO N3009 AGND D6229 UDZS8.2B A_AC C6226 470/25...

  • Page 161: Sch29_Front

    Z6411 STYLE-PIN DGND DGND Z6412 STYLE-PIN DGND N6401 GREENLED GREENLED 7P-EHs R6413 FRONT_RST FLAC (F 2 ) R6414 OPEN FRONT_NO_FI L R6409 SWM3.3V FLAC(F 1 ) C6415 FL_CLK FLCLK C6417 OPEN M3.3V VKKAC R6410 R6415 FL_CE1 FLCE1 Z6403 Z6404 R6416 OPEN B/PIRIN B/PIRIN...

  • Page 162: Sch30_Smps

    B6501 CMD1A834 C6501 1000P/250V FUSE(SCT2A) C6512 0.01/250 Z6502 AC-INLET(R-30190) R6501 2.2M L6501 R6511 C6504 R6502 C6505 2.2M C6502 0.1/250V 0.1/250V (2.2M) 1000P/250V 2.2M Z6516 Europe/China=OPEN 3X10_CBTS(S)-Z L.FILTER-12290(SQE24*24) R6503 D6503 R6512 B6503 2.2M 2.2M D3SB60 Z651 5 CMD1A834 (2.2M) R6521 C6532 HEAT_SINK(SMPS)-A C6511 0.01/250 2200P...

  • Page 163: Sch31_Amp Connect

    8 U - 1 1 0 1 5 7 - 5 L_AMP_CONNECT_UNIT Z5809 OPEN Z5810 STYLE-PIN Z5811 STYLE-PIN N5832 10P-PHs Z5812 OPEN Z5817 STYLE-PIN N5832 TO N3201 To_8U-110157-1_(N9032) To_8U-110157-1_(N9032) To_8U-110157-1_(N9032) To_8U-110157-1_(N9032) To_8U-110157-1_(N9032) P.AMP_UNIT P.AMP_UNI T P.AMP_UNIT P.AMP_UNIT P.AMP_UNIT N5833 N5811 OPEN OPEN IDDLE-...

  • Page 164: Sch32_232C Phono

    K3901 A+7V 2PIN-JACK(RCA-206BG-00-05) R3903 R3904 C3914 R3917 N3902 10/63 U3902 R3926 C3927 7P-SOCKET(C125Z2) NJM8080G 10/63 C3921 R3908 A+7V ( 1 / 2 ) 100P N3902 C3902 C3907 150K D3901 A-7 V C3919 R3930 OPEN 220P R3912 C3931 TO N9017 PHONOR OPEN PREGND 220/6.

  • Page 165: Sch33_Power Amp

    D101 R106 R136 R110 C105 C113 KDS160 R131 100/16 D102 V101 V6QB301T PRF18BC471QB5RB J105 SHORT Q112 KDS160 To_8U-110157-5 Q103 2N5401S R117 OPEN Z101 J106 SHORT R132 Q110 L_AMP_CONNECT_UNIT J101 2N5401S Q107 C111 C104 100P R118 SHORT 2N5401S R133 2N5401S To_8U-110157-4 C101 R102 SHORT...

  • Page 166: Sch34_Cx870 Connect (Cx870 Only)

    N903 N902 120P-PLUG(5046) TO N602 U902 L3601 N903 L3606 DV1.9V NCP380HMU21AATBG BLM21PG221 6P-PHs BLM21PG221 3.3V 3.3V FLAG# 3.3V 3.3V C903 I LIM L3607 L3602 OPEN USBVBUSDRV OPEN OPEN 1.2V 1.2V C902 20 PVIN USBVBUS VOUT N905 N906 1.2V 1.2V VBUS C904 860USBD + 21 PVIN...

  • Page 167: Sch35_Bt Module (Cx870 Only)

    OPEN 11P-PH BT_ACTIV E BT_PRIORITY LDO_ON BT_ACTIV E BT_EIN T BT_TX TO N901 BLM21PG221 10/6.3 1000P 0 . 1 BLM21PG221 0 . 1 0 . 1 TC7SGU04FE 32.768kHz 32.768K 820K 8 U - 3 1 0 2 0 1 - 2 BT MODULE UNIT SCHEMATIC DIAGRAMS (35/35) SCH35_BT MODULE (CX870 Only)

  • Page 168: Exploded View

    EXPLODED VIEW Please see the last chapter for the part list. CX-870 106 106 WARNING: Parts marked with this symbol z have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.

  • Page 169: Packing View

    PACKING VIEW Please see the last chapter for the part list. P13 P14 P15 P16 P17 P18 P19 P20 P21 P22 P23 P24 P25 P26 UK plug (UK Only)

  • Page 170: Semiconductors

    SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. The semiconductor which described a detailed drawing in a schematic diagram are omitted to list. 1. IC's R5F56108VNFP (HDMI : U5001) PE0/D8 PC4/A20 PD7/D7 PC5/A21/SCK5/CS5#-D PD6/D6 PC6/A22/RxD5/CS6#-D PD5/D5 PC7/A23/TxD5/CS4#-D/CS7#-D PD4/D4...
  • Page 171 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY 17 P86 (CEC POWER2) Reserve (CEC POWER2 control) R E M O T E 232C POWER SUPPLY (REMOTE 18 P85 POWER(232C) 3.3V) control pin.(ON: H) 19 RES# RESET Reset input (reset: L) 20 XTAL XTAL Clock input...
  • Page 172 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY ETHERNET communication control pin 55 P54/TRDATA0 E SPI MIEO N3VPu (DM860) ETHERNET communication control pin 56 P83 E SPI CLK N3VPu (DM860) 57 VSS 58 P82/TRCLK FL CE VFD control pin 59 VCC +3.3V 60 P81/TRSYNC...
  • Page 173 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY P A 3 / A 3 / P O 1 9 / D A C ( E T H E R ) DAC (ETHER) MUTE control pin T I O C C 6 / T I O C D 6 / MUTE (PCM5100 for DM860) TCLKF...
  • Page 174 Pull up/ Pin Name Symbol LvCnv STBY STOP Function down STBY HDMI INPUT 5V (for EDID / HOT 139 P41/IRQ9-B/AN1 HDMI IN 5V SET PLUG) detection pin 140 AVSS AVSS 141 P40/IRQ8-B/AN0 CEC_IN SW3VPu CEC-D signal input pin Reference voltage (+3.3V) input pin for 142 VREF VREF A/D port...
  • Page 175 RX210 Group 1. Overview R5F5210ABDFP (HDMI : U2101) RX210 Group PLQP0100KB-A (100-pin LQFP) (Top view) VREFL0 VREFH0 AVCC0 AVSS0 R5F5210ABDFP Terminal Functions Note: • This figure indicates the power supply pins and I/O port pins. For the pin configuration, see the table “List of Pins and Pin Functions (100-Pin LQFP)”.
  • Page 176 Symbol Pin Name Pu/Pd STBY Function LvCnv STBY 34 P12/SCL/IRQ2 778_1_RST HDMI MN8647781(TX) RESET control pin ※ 35 PH3 HSDA HDMI I2C- MN8647781 3VPu 36 PH2/IRQ1 HSCL HDMI I2C- MN8647781 3VPu 37 PH1/IRQ0 778_1_HINT HDMI MN8647781(TX) HDMI INT input pin 38 PH0 778_2_RST HDMI MN8647781(RX) RESET control pin...
  • Page 177 Symbol Pin Name Pu/Pd STBY Function LvCnv STBY 85 PD1/IRQ1 DSP1CS DSP control pin (ADSP21487KSWZ-3B) 3VPu 86 PD0/IRQ0 DSP1FLAG0 DSP control pin (ADSP21487KSWZ-3B) 87 P47/AN007 88 P46/AN006 VIN A COMPOSITE VIDEO SELECT IC(NJM2595) 89 P45/AN005 VIN B COMPOSITE VIDEO SELECT IC(NJM2595) 90 P44/AN004 VIN C COMPOSITE VIDEO SELECT IC(NJM2595)
  • Page 178 SBAS495 – JUNE 2010 www.ti.com PIN CONFIGURATIONS PT PACKAGE PCM9211 (HDMI : U1000) LQFP-48 (TOP VIEW) ERROR/INT0 VDDRX NPCM/INT1 RXIN1 MPIO_A0 MPIO_A1 RXIN2 MPIO_A2 RXIN3 MPIO_A3 RXIN4/ASCKIO PCM9211 MPIO_C0 RXIN5/ABCKIO MPIO_C1 RXIN6/ALRCKIO MPIO_C2 RXIN7/ADIN0 MPIO_C3 MODE MS/ADR1 MPIO_B0 MPIO_B1 MC/SCL PIN FUNCTIONS PIN Functions DESCRIPTION...
  • Page 179 DESCRIPTION NAME TOLERANT Reset Input, active low(2) (4) RXIN1 Biphase signal, input 1, built-in coaxial amplifier VDDRX – – Power supply, 3.3 V (typ.), for RXIN0 and RXIN1. RXIN0 Biphase signal, input 0, built-in coaxial amplifier GNDRX Ground, for RXIN Oscillation circuit input for crystal resonator or external XTI clock source input(5) Oscillation circuit output for crystal resonator AGND...
  • Page 180 LC89091JA (DIGITAL : U1004, U1005) LC89091JA SDIN XOUT...
  • Page 181 ADSP21487KSWZ4B (DIGITAL:U101, U201, U301, U401) PIN 1 GND PAD (PIN 177) at BOTTOM TOP VIEW (PINS DOWN) ADSP21487KSWZ3B Terminal Function Pin Name Pin No. Pin Name Pin No. Pin Name Pin No. Pin Name Pin No. SDDQM DAI_P10 DPI_P08 FLAG0 SDCKE DPI_P07 FLAG1...
  • Page 182 A3V56S40GTP-60(DIGITAL:U103, U203, U303, U403) PIN CONFIGURATION (TOP VIEW) PIN CONFIGURATION (TOP VIEW) DQ15 VddQ VddQ VssQ VssQ DQ14 DQ13 VssQ VssQ VddQ VddQ DQ12 DQ11 VddQ VddQ VssQ VssQ DQ10 VssQ VssQ VddQ VddQ DQML DQMU /CAS /CAS /RAS /RAS A10(AP) A10(AP)
  • Page 183 A3V56S30FTP A3V56S40FTP 256M Single Data Rate Synchronous DRAM A3V64S40GTP-60 Pin Function Pin Descriptions SYMBOL TYPE DESCRIPTION Clock: CLK is driven by the system clock. All SDRAM input signals are sampled on the positive edge of CLK. CLK also increments the internal burst counter and controls the output registers. Input Clock Enable: CKE activates (HIGH) and deactivates (LOW) the CLK signal.
  • Page 184 A3V56S30FTP A3V56S40FTP 256M Single Data Rate Synchronous DRAM A3V64S40GTP-60 Block Diagram Note:This figure shows the A3V56S30FTP The A3V56S40FTP configuration is 8192x512x16 of cell array and DQ0-15 Type Designation Code A 3Ｖ 56 Ｓ４０F ＴＰ－G6 Speed Grade 75： 133MHz@CL=3 7： 143MHz@CL=3 6：...
  • Page 185 MX25L1606EM2I-12G (DIGITAL : U102, U202, U302, U402) MX25L1606EM2I-12G Block Diagram...
  • Page 186 SLAS764 – MAY 2011 www.ti.com DEVICE INFORMATION PCM5100 (DAC : U5002, U5003) TERMINAL FUNCTIONS, PCM510x PCM510X (top view) Table 2. TERMINAL FUNCTIONS, PCM510x TERMINAL DESCRIPTION NAME CPVDD Charge pump power supply, 3.3V CAPP Charge pump flying capacitor terminal for positive rail CPGND Charge pump ground CAPM...
  • Page 187 PCM1690(DAC : U5201, U5202) PCM1690 Pin Function TERMINAL PULL- DESCRIPTION DOWN TOLERANT NAME RSV2 — — — Reserved, tied to analog ground RSV1 — — — Reserved, left open RSV2 — — — Reserved, tied to analog ground RSV1 — —...
  • Page 188 TERMINAL PULL- DESCRIPTION DOWN TOLERANT NAME VOUT1+ Positive analog output from DAC1 VOUT1- Negative analog output from DAC1 PCM1690 RSV2 — — — Reserved, tied to analog ground AGND2 — — — Analog ground 2 VCC2 — — — Analog power supply 2, +5 V RSV2 —...
  • Page 189 CONFIDENTIAL 8-CHANNEL ELECTRONIC VOLUME With 14-Input selector And Tone control R2A15220FP (INPUT : U3201, U3202) BLOCK DIAGRAM AND PIN CONFIGURATION (TOP VIEW) TRER MUTE AVEE AVCC BASSR2 AVEE BASSR1 ADCL 0/-6/-12/-18dB TREL ADCR SUB2 AGND BASSL2 MAIN INR1 BASSL1 Bass/ Treble 0~-95dB, +42~0dB -14~+14dB...
  • Page 190 R2A15220FP R2A15220FP CONFIDENTIAL 8-CHANNEL ELECTRONIC VOLUME With 14-Input selector And Tone control PIN DESCRIPTION R2A15220FP Pin Function PIN No. Function Name FROUT,FLOUT, 22,20, COUT,SWOUT, 16,14, Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel SROUT, SLOUT, 10, 8, SBROUT,SBLOUT 2, 100 23,19, FR Pre-out,FL Pre-out, Pre-output pin of FL/FR/SL/SR/SBL/SBR channel 11, 7, SR Pre-out, SL Pre-out,...
  • Page 191 G   G    I I I I BLOCK DIAGRAM NJW1194A (INPUT : U3203, U3204)                        ...

  • Page 192: Fl Display

    2. FL DISPLAY FLD(17-BT-40GINK) (FRONT/SPK : Z6402) PIN CONNECTION GRID ASSIGNMENT...
  • Page 193 ANODE CONNECTION...
  • Page 194 FRONT SPK FRONT SPK PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed b NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model BK : Black model SP : Premium Silver model REF No.
  • Page 195 FRONT SPK REF No. Part No. Part Name Remarks Q'ty New Ver R6077,6078 RM73B--0R0KT +2125 00D2470018905 R6079 RM73B--333JT +1608 00D2472011900 R6080 RM73B--0R0KT +2125 00D2470018905 R6081,6082 RM73B--103JT +2125 00D2470009985 R6083,6084 RM73B--103JT +1608 00D2472009983 R6085 RM73B--0R0KT +2125 00D2470018905 R6087 RM73B--332JT +1608 00D2472008968 R6088 RM73B--334JT +1608...
  • Page 196 FRONT SPK REF No. Part No. Part Name Remarks Q'ty New Ver C6227,6228 13405014840AS CE04W1J100MT(KR3) 13405014840AS C6229,6230 13405013340AS CE04W1E471MT(KR3) 13405013340AS C6235,6236 13405014840AS CE04W1J100MT(KR3) 13405014840AS C6403 CK73B1E104KT +1608 00D2570516954 C6404 CK73B1H102KT +1608 00D2570509929 C6405 CK73B1H222KT +1608 00D2570509990 C6406 CK73B1E104KT +1608 00D2570516954 C6407 CK73B1H102KT +1608...
  • Page 197 P.AMP SMPS P.AMP SMPS PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed b NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model BK : Black model SP : Premium Silver model REF No.
  • Page 198 P.AMP SMPS REF No. Part No. Part Name Remarks Q'ty New Ver R6504-6506 RD14B2E105JT(5) 00D2412405974 R6507 RD14B2E334JT(5) 00D2412404959 R6508 RM73B--105JT +1608 00D2472014965 R6509 RM73B--392JT +1608 00D2472008984 R6509 RM73B--622JT +1608 E2,E1C 00D2472009938 R6510 RM73B--822JT +1608 00D2472009967 R6511,6512 RD14B2E225JT(5) 00D2412405990 R6514 RM73B--563JT +1608 00D2472011968 R6515...
  • Page 199 P.AMP SMPS REF No. Part No. Part Name Remarks Q'ty New Ver N5815 S4B-PH-K-S (LF)(SN) 00MYJ06006440 N5816 4P 80mm PH-SAN 61205049600AS N5823 S9B-PH-K-S (LF)(SN) 00MYJ06006490 N5824 S3B-PH-K-S (LF)(SN) 00MYJ06006430 N5831 S8B-PH-K-S (LF)(SN) 00MYJ06006480 N5832 S10B-PH-K-S (LF)(SN) 00MYJ06006500 N5834 B11B-PH-K-S (LF)(SN) 00MYJ06006310 N5842 B12B-PH-K-S (LF)(SN)
  • Page 200 AUDIO VIDEO AUDIO VIDEO PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed b NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model BK : Black model SP : Premium Silver model REF No.
  • Page 201 AUDIO VIDEO REF No. Part No. Part Name Remarks Q'ty New Ver R3501-3508 RM73B--100JT +1608 00D2472002964 R3509-3525 RM73B--104JT +1608 00D2472012925 R3526-3529 RM73B--224JT +1608 00D2472013908 R3530,3531 RM73B--102JT +1608 00D2472007943 R3532,3533 RM73B--222JT +1608 00D2472008926 R3534,3535 RM73B--101JT +1608 00D2472005903 R3536-3539 RM73B--222JT +1608 00D2472008926 R3540-3556 RM73B--104JT +1608...
  • Page 202 AUDIO VIDEO REF No. Part No. Part Name Remarks Q'ty New Ver R8071 RM73B--0R0KT +2125 00D2470018905 R8072 RM73B--0R0KT +1608 E2,E1C 00D2472018903 R8076-8079 RM73B--103JT +1608 00D2472009983 CAPACIITORS GROUP C3022-3025 CK73B1E104KT +1608 00D2570516954 C3026 CK73X5R0J106MT(2125) 132450038507S C3028 CK73B1E104KT +1608 00D2570516954 C3101 CK73B1E104KT +1608 00D2570516954 C3102-3104...
  • Page 203 AUDIO VIDEO REF No. Part No. Part Name Remarks Q'ty New Ver C5310-5312 00D2544583971 CE04W1H470MT(ROB) 00D2544583971 C5313 13405014340AS CE04W1H470MT(KR3) 13405014340AS C5314,5315 00D2544583971 CE04W1H470MT(ROB) 00D2544583971 C5316 13405014340AS CE04W1H470MT(KR3) 13405014340AS C5318-5323 13405014340AS CE04W1H470MT(KR3) 13405014340AS C5324-5331 CK73B1A104KT +1005 00D2575008933 C5501 CK73B1E104KT +1608 00D2570516954 C5502-5505 CK73B1A104KT +1005 00D2575008933...
  • Page 204 DIGITAL DIGITAL PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed b NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model BK : Black model SP : Premium Silver model REF No.
  • Page 205 DIGITAL REF No. Part No. Part Name Remarks Q'ty New R0151 MNR04=472(1005X4) 126210007557S R0152 MNR04=103(1005X4) 126210008536S R0153 RM73B--472JT+1005 00D2473010900 R0155,0156 MNR04=472(1005X4) 126210007557S R0157-0160 MNR04=100(1005X4) 126210001511S R0162-0168 RM73B--820JT 00D2473005986 R0169,0170 RM73B--100JT 00D2473003962 R0175-0178 MNR04=560(1005X4) 126210002590S R0179,0180 MNR04=330(1005X4) 126210002538S R0181-0183 RM73B--472JT+1005 00D2473010900 R0184 MNR04=330(1005X4) 126210002538S...
  • Page 206 DIGITAL REF No. Part No. Part Name Remarks Q'ty New R0465,0466 RM73B--100JT 00D2473003962 R0475-0478 MNR04=560(1005X4) 126210002590S R0479 RM73B--560JT 00D2473005944 R0481 RM73B--472JT+1005 00D2473010900 R0482,0483 RM73B--820JT 00D2473005986 R0602-0604 RM73B--0R0KT+1005 00D2473001906 R0611 RM73B--103JT +1005 00D2473010984 R0612 RM73B--0R0KT+1005 00D2473001906 R0615,0616 RM73B--0R0KT+1005 00D2473001906 R0623-0626 RM73B--0R0KT+1005 00D2473001906 R0632 RM73B--100JT...
  • Page 207 DIGITAL REF No. Part No. Part Name Remarks Q'ty New R2000-2003 RM73B--471DT(1608) 122350001547S R2014,2015 RM73B--103JT +1005 00D2473010984 R2016 RM73B--472JT+1005 00D2473010900 R2017-2020 RM73B--151DT(1608) 00D2472032976 R2021 RM73B--472JT+1005 00D2473010900 R2022-2025 RM73B--331DT(1608) 122350001530S R2026,2027 RM73B--103JT +1005 00D2473010984 R2031 MNR04=100(1005X4) 126210001511S R2032,2033 RM73B--103JT +1005 00D2473010984 R2034 RM73B--102JT 00D2473008941...
  • Page 208 DIGITAL REF No. Part No. Part Name Remarks Q'ty New R2625 RM73B--473JT+1005 00D2473012940 R2626 RM73B--0R0KT+1005 00D2473001906 R2628 RM73B--105JT +1608 00D2472014965 R2630,2631 RM73B--470JT +1005 00D2473005928 R2632,2633 RM73B--102JT 00D2473008941 R2634-2636 RM73B--103JT +1005 00D2473010984 R2637,2638 RM73B--182JT 00D2473009908 R2639 RM73B--473JT+1005 00D2473012940 R2640,2641 RM73B--182JT 00D2473009908 R2642,2643 RM73B--511DT(1608) 00D2472034903...
  • Page 209 DIGITAL REF No. Part No. Part Name Remarks Q'ty New R3472 RM73B--104JT 00D2473013923 R3473 RM73B--332JT 00D2473009966 R3474,3475 RM73B--103JT +1005 00D2473010984 R3476 MNR04=820(1005X4) 126210003531S R3477,3478 RM73B--0R0KT+1005 00D2473001906 R3479 MNR04=820(1005X4) 126210003531S R3480 MNR04=100(1005X4) 126210001511S R3481 RM73B--510DT(1608) 00D2472031977 R3482 MNR04=820(1005X4) 126210003531S R3483 RM73B--820JT 00D2473005986 R3484 RM73B--510DT(1608)
  • Page 210 DIGITAL REF No. Part No. Part Name Remarks Q'ty New C0139 CK73B1A104KT +1005 00D2575008933 C0140 CK73B1H102KT +1005 00D2575006993 C0145 CK73B1A104KT +1005 00D2575008933 C0146,0147 CK73B1H102KT +1005 00D2575006993 C0148,0149 CK73B1A104KT +1005 00D2575008933 C0150 CK73B1H102KT +1005 00D2575006993 C0151 CK73B1A104KT +1005 00D2575008933 C0152 CK73B1H102KT +1005 00D2575006993 C0155 CK73B1A104KT +1005...
  • Page 211 DIGITAL REF No. Part No. Part Name Remarks Q'ty New C0413,0414 CK73B1A104KT +1005 00D2575008933 C0415 CK73B1H102KT +1005 00D2575006993 C0416 CK73B1A104KT +1005 00D2575008933 C0417 CK73B1H102KT +1005 00D2575006993 C0418 CK73B1A104KT +1005 00D2575008933 C0419,0420 CK73B1H102KT +1005 00D2575006993 C0421,0422 CK73B1A104KT +1005 00D2575008933 C0423 CK73B1H102KT +1005 00D2575006993 C0425 CK73B1A104KT +1005...
  • Page 212 DIGITAL REF No. Part No. Part Name Remarks Q'ty New C1905 CK73B1E103KT(1005) 00D2575008946 C1906 CK73B1A104KT +1005 00D2575008933 C1907,1908 CK73X5R0J106MT(2125) 132450038507S C1909 CC73CH1H100DT +1005 00D2575002926 C1910 CK73B1A104KT +1005 00D2575008933 C1911 CK73B1H102KT +1005 00D2575006993 C1912,1913 CK73B1A104KT +1005 00D2575008933 C1916 CK73X5R0J106MT(2125) 132450038507S C1917 CK73B1E103KT(1005) 00D2575008946 C1918...
  • Page 213 DIGITAL REF No. Part No. Part Name Remarks Q'ty New C2185 CK73B1A104KT +1005 00D2575008933 C2186 CK73B1H102KT +1005 00D2575006993 C2187 CK73B1A104KT +1005 00D2575008933 C2188 CK73B1H102KT +1005 00D2575006993 C2189 CK73B0J475KT +1608 00D2570522906 C2191,2192 CK73B1A104KT +1005 00D2575008933 C2193 CK73B1H221KT +1005 00D2575006919 C2194,2195 CK73B1A104KT +1005 00D2575008933 C2400-2402 CK73B1A104KT +1005...
  • Page 214 DIGITAL REF No. Part No. Part Name Remarks Q'ty New C3017-3024 CK73B1H102KT +1005 00D2575006993 C3025 CK73X5R0J106MT(2125) 132450038507S C3026-3041 CK73B1A104KT +1005 00D2575008933 C3042-3049 CK73B1H102KT +1005 00D2575006993 C3050 CK73B1A104KT +1005 00D2575008933 C3052 CK73B1A105KT +1608 00D2570521907 C3200 CK73B0J475KT +1608 00D2570522906 C3201 CK73B1A104KT +1005 00D2575008933 C3202 CK73B1H102KT +1005...
  • Page 215 DIGITAL REF No. Part No. Part Name Remarks Q'ty New L0607 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L0609 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L0611 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L0613 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L0615 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L0617 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L1201 CHIP EMIFIL(11A121) +1608 00D2350130903 L1801-1805 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L1901 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L1903-1905 E.FIL(BLM21PG221SN1)+2125 00D2350147909 L1907-1909...
  • Page 216 TRANS LABEL 54411039100AD RUBBER SHEET 00D4610866009 40231043500AD FRONT PANEL 40231043500AD 40231043501AD FRONT PANEL BKE2 40231043501AD 40231043502AD FRONT PANEL 40231043502AD 42141003400AD DENON BADGE 42141003400AD 42141002300AD DENON BADGE BKE2 42141002300AD 42141002301AD DENON BADGE 42141002301AD 42131003300AD IN-COMMAND BADGE 42131003300AD 44351008110AD INNER PANEL 44351008110AD...
  • Page 217 EXPLODED REF No Part No. Part Name Remarks Q'ty New Ver BACK PANEL 40631014012AD 18301004000AS HD RADIO MODULE(UMH-AVR) 18301004000AS CARD SPACER(L=10) 00D4122814028 PWB BRACKET (FRONT/CNT) 44431033100AD CARD SPACER (L=6) 00D4122814044 SMPS HOLDER 44431033300AD SMPS COVER 44431033200AD Terminal PHONO 48801000200AM ★57 WIRE CLAMPER 00D4458004007 ★58...
  • Page 218 SERVICE CONTRACT SHEET 54311020400AD 11601005100AS AM LOOP ANTENNA 11601005100AS 11601005200AS FM ANTENNA ASSY 11601005200AS 54311032100AD SP CABLE LABEL 54311032100AD CAUTION SHEET 54311025200AD WARRANTY FOR CHINA DENON 8W5431016500D ANTENNA ISOLATOR 18901004900AS 53121041103AD CARTON CASE 53121041103AD 53121041101AD CARTON CASE 53121041101AD 53121041102AD CARTON CASE 53121041102AD...
  • Page 219 CX870 CONNECT CX870 CONNECT PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed b NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model BK : Black model SP : Premium Silver model REF No.
