MODEL
AVR-S510BT
AVR-X520BT
AVR-X518CI
• For purposes of improvement, specifications and design are subject to change without notice.
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
S1353V04DM/DG1610
SERVICE MANUAL
JP
AV SURROUND RECEIVER
e
D&M Holdings Inc.
Copyright 2016 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
E3
E2
EK
EA
P
P
Ver. 4
Please refer to the
MODIFICATION NOTICE.
E1
E1C E1K
P
P
f

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVR-S510BT and is the answer not in the manual?

Questions and answers

Related Manuals for Denon AVR-S510BT

Summary of Contents for Denon AVR-S510BT

  • Page 1 Please refer to the MODIFICATION NOTICE. SERVICE MANUAL MODEL E1C E1K AVR-S510BT AVR-X520BT AVR-X518CI AV SURROUND RECEIVER • For purposes of improvement, specifications and design are subject to change without notice. • Please use this service manual with referring to the operating instructions without fail.

  • Page 2: Table Of Contents

    NOTE FOR SCHEMATIC DIAGRAM ..........7 5. Bluetooth ................44 NOTE FOR PARTS LIST ..............7 6. SMPS ..................46 TECHNICAL SPECIFICATIONS for AVR-S510BT ......9 CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK .....48 DIMENSION for AVR-S510BT ...........10 LEVEL DIAGRAM ...............49 TECHNICAL SPECIFICATIONS for AVR-X520BT / X518CI ..11 AUDIO BLOCK DIAGRAM ............53...

  • Page 3: About This Manual

    ABOUT THIS MANUAL Readthefollowinginformationbeforeusingtheservicemanual. What you can do with this manual Search for a Ref. No. (phrase) Jump to the target of a schematic diagram connector (Ctrl+Shift+F) YoucanusethesearchfunctioninAcrobatReaderto searchforaRef.No.inschematicdiagrams,printed Click the Ref. No. of the target connector in the red wiringcircuitdiagrams,blockdiagrams,andparts box around a schematic diagram connector.

  • Page 4: Using Adobe Reader (Windows Version)

    Using Adobe Reader (Windows version) Add notes to this data (Sign) Magnify schematic / printed circuit board diagrams - 1 TheSignfunctionletsyouaddnotestothedatain (Ctrl+Space, mouse operation) thismanual. Savethefileonceyouhavefinishedaddingnotes. PressCtrl+Space onthekeyboardanddragthe [Example using Adobe Reader X] mousetoselecttheareayouwanttoview. Onthe"View"menu,click"Sign". • Theselectedareaismagnified. • TheSignpaneappears. Ctrl Space •  W henyouwanttomovetheareashown,hold...
  • Page 5 Magnify schematic / printed circuit board Magnify schematic / printed circuit board diagrams - 2 diagrams - 3 (Pan & Zoom function) (Loupe Tool function) ThePan&Zoomfunctionletsyouseewhichpartof TheLoupeToolfunctionletsyoumagnifyaspecific amagnifieddiagramisbeingshowninaseparate partofadiagraminaseparatewindow. window. [ExampleusingAdobeReaderX] [Example using Adobe Reader X] Onthe"View"menu,pointto"Zoom",andthenclick "Loupe Tool". Onthe"View"menu,pointto"Zoom",andthenclick "Pan &...

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS The following items should be checked for continued protection of the customer and the service technician. leakage current check Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check.

  • Page 7: Note For Schematic Diagram

    NOTE FOR SCHEMATIC DIAGRAM WARNING: Parts indicated by the z mark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer. CAUTION: Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set is defective.
  • Page 8 Personal notes:...

  • Page 9: Technical Specifications For Avr-S510Bt

    TECHNICAL SPECIFICATIONS FOR AVR-S510BT n Audio Section n Bluetooth Section Communications system : Bluetooth Version 2.1 + EDR • Power amplifier (Enhanced Data Rate) Rated output : Transmission power : Maximum 2.5 mW (Class 2) Front : Maximum communication range : Approx. 32.8 ft/10m in line of sight 70 W + 70 W (8 Ω/ohms, 20 Hz –...

  • Page 10: Dimension For Avr-S510Bt

    DIMENSION FOR AVR-S510BT Unit : in. (mm) Weight : 16 lbs 9 oz (7.5 kg) 17 1/16 (434) 2 3/8 (60) 13 9/16 (344)

  • Page 11: Technical Specifications For Avr-X520Bt / X518Ci

    TECHNICAL SPECIFICATIONS FOR AVR-X520BT / X518CI n Audio Section n Bluetooth Section • Power amplifier Communications system : Bluetooth Version 2.1 + EDR (Enhanced Data Rate) Rated output : Transmission power : Maximum 2.5 mW (Class 2) Front : Maximum communication range : Approx. 10m in line of sight 70 W + 70 W (8 Ω/ohms, 20 Hz –...

  • Page 12: Dimension For Avr-X520Bt / X518Ci

    DIMENSION FOR AVR-X520BT / X518CI Unit : in. (mm) Weight : 16 lbs 9 oz (7.5 kg)

  • Page 13: Precautions During Service (Avr-S510Bt)

    PRECAUTIONS DURING SERVICE (AVR-S510BT) Initializing This Unit Initialize this unit if you have replaced the microcomputer, one of the parts around the microcomputer, or the digital PCB. Press the power button ( X ) to turn off the power. Hold down buttons "SOUND MODE 1 " and "PRESET +" at the same time and press the power button to turn on the power.

  • Page 14: Precautions During Service (Avr-X520Bt / X518Ci)

    PRECAUTIONS DURING SERVICE (AVR-X520BT / X518CI) Initializing This Unit Initialize this unit if you have replaced the microcomputer, one of the parts around the microcomputer, or the digital PCB. Press the power button ( X ) to turn off the power. Hold down buttons "PRESET +"...

  • Page 15: Disassembly

    DISASSEMBLY • Remove each part following the flow below. • Reassemble the removed parts in the reverse order. • Read "Precautions During Work" before reassembling the removed parts. • If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work.

  • Page 16: Front Panel Assy

    • A, B, C and D in the photo below indicate the shooting directions of photos. • The photographs with no shooting direction indicated were taken from the top of the unit. • Photos of AVR-S510BT E3 are used in this manual. The viewpoint of each photograph (Shooting direction:X)[View from the top]•...

  • Page 17: Video Pcb

    2. VIDEO PCB Proceeding： TOP COVER → VIDEO PCB (1) Remove the screws. Remove the FFC. ↑Shooting direction: A↑ 3. DIGITAL PCB Proceeding： TOP COVER → VIDEO PCB → DIGITAL PCB (1) Remove the screws. Remove the connector wires and FFC. CN712 CN772 CN751...

  • Page 18: Main Pcb

    4. MAIN PCB Proceeding： TOP COVER → VIDEO PCB → DIGITAL PCB → MAIN PCB (1) Remove the screws. Remove the connector. CN503 ↑Shooting direction: A↑ 5. POWER PCB Proceeding ： TOP COVER → SMPS PCB See "EXPLODED VIEW" for instructions on how to remove each PCB of the "SMPS PCB". 6.

  • Page 19: Special Mode (Avr-S510Bt)

    SPECIAL MODE (AVR-S510BT) Special mode setting button b No. 1, 2 : H old down buttons A and B at the same time and press the power button ( X ) to turn on the power. No. 3, 4 : Hold down buttons A, B and C for at least 3 seconds while the power is on. Mode Button A Button B Button C Contents Backup data initialization is carried out. Initialization SOUND MODE 1 PRESET + (See page13 .) Firmware versions such as Main, DSP or OSD are displayed in the FL display. Errors are Version Display PRESET + TUNE - displayed or when they occur. (See page21 .) Change Video Format Select the mode shown below. PRESET -...

  • Page 20: Special Mode (Avr-X520Bt / X518Ci)

    SPECIAL MODE (AVR-X520BT / X518CI) Special mode setting button b No. 1, 2 : H old down buttons A and B at the same time and press the power button ( X ) to turn on the power. No. 3, 4 : Hold down buttons A, B and C for at least 3 seconds while the power is on. Mode Button A Button B Button C Contents Backup data initialization is carried out. Initialization PRESET + TUNE + (See page14 .) Firmware versions such as Main, DSP or OSD are displayed in the FL display. Errors are Version Display TUNE + DIMMER displayed or when they occur. (See page 21 .) Change Video Format Select the mode shown below. TUNE - TUNE + DIMMER...

  • Page 21: Initialization Mode

    1.1. Operations Hold down buttons below at the same time and press the power button to turn on the power. "SOUND MODE 1 ", "PRESET +" (AVR-S510BT) "PRESET +", "TUNE +" (AVR-X520BT / X518CI) Release the buttons after confirming that the display flashes in intervals of approximately 1 second.

  • Page 22: Change Video Format And Display Language Mode

    3.1. Operations Hold down buttons below for at least 3 seconds while the power is on. "PRESET -", "PRESET +", "TUNE -" (AVR-S510BT) "TUNE -", "TUNE +", "DIMMER" (AVR-X520BT / X518CI) f Note: Do not start in this mode when displaying the OSD MENU using the MENU button.

  • Page 23: Product Mode

    "PRESET -" （AVR-S510BT） "TUNE -" （AVR-X520BT / X518CI） f 4.2. Displaying and Selecting Each Mode Remote Lock Mode Press the "TUNE +"(AVR-S510BT) button. Press the "STATUS"(AVR-X520BT / X518CI) button. f Tuner Step Change Mode (at AM 9kHz step / FM 50kH step) (at AM 10kHz step / FM 200kH step) Press the "TUNE +"(AVR-S510BT) button.
  • Page 24 4.4.1. Remote Lock Mode To enter the Product Mode, to display the Remote Lock Mode. Press the button below to switch between On and Off. "PRESET +" / "TUNE -" (AVR-S510BT) "PRESET +" / "DIMMER" (AVR-X520BT / X518CI) f ↓↑ Press the button below to set On/Off. The display then return to the normal mode.
  • Page 25 Additional causes of protection can be due to loose connections, associated components, Microprocessor, etc. Press the button below to set On/Off. The display then return to the normal mode. "PRESET -" (AVR-S510BT) "TUNE -" (AVR-X520BT / X518CI) f Clearing the protection history There are two ways to clear the protection history, as described below.
  • Page 26 4.4.5. Mic Mode Not for service. Do not operate. Cancellation of the mode Press the power button to turn off the power or disconnect the AC plug of this unit to turn the power off.

  • Page 27: Procedure After Replacing The Microprocessor, Etc

    PROCEDURE AFTER REPLACING THE MICROPROCESSOR, ETC The procedure after replacing the u-COM (Microprocessor), flash ROM, etc. is as follows. Procedure PCB Name Ref. No. Description after Remark Replacement Digital IC711 STM32F101ZG SOFTWARE: Main Digital IC722 MX25L3206EM2I-12G SOFTWARE: GUI ROM Digital IC742 MX25L8006EM2I-12G SOFTWARE: DSP ROM...

  • Page 28: Firmware Update Procedure

    FIRMWARE UPDATE PROCEDURE 1. Updating via USB The latest firmware can be downloaded to a USB Memory for updates. 1.1. Connecting to the USB Memory (1) Preparation • Use a memory that supports USB2.0. • USB format: Prepare a USB memory formatted in FAT16 or FAT32. •...
  • Page 29 QUICK SELECT MEMORY CBL /SAT MODE Blu-ray GAME 1.5. Start the update Turn on the power of this unit. Then, push "SETUP" and select. TUNE CHANNEL TV AUDIO Bluetooth CH LEVEL RESTORER SLEEP SEARCH PUSH "SETUP" INFO OPTION VOLUME ENTER BACK SETUP MUTE...
  • Page 30 (3) Push "ENTER" m w a (4) Select "Yes", then, Push "ENTER" m w a • – ---Cautions on Firmware Update--- • Never remove the USB memory before the update is finished. • Never turn off the power before the update is completed. •...
  • Page 31 1.6. About the error code No FirmwareFile in USB. FirmwareFile in USB for unsupported Model name/area...

  • Page 32: Adjustment

    ADJUSTMENT Adjusting Idling Current 1. Preparation (1) Prepare a DC voltmeter. (2) P lace the unit under normal usage conditions, away from highly ventilated areas such as next to an air conditioning machine or electric fan. The set requires an ambient temperature of 15℃ to 30℃ (59 ° F ~ 86 ° F) and standard humidity. (2) Presetting • POWER (Power source switch) STANDBY • SPEAKER (Speaker terminal) No load (Do not connect equipment such as speakers or dummy resistors.) 2. Adjustment Procedure (1) R emove the top cover and turn VR510(FL), VR550(FR), VR530(C), VR520(SL) and VR540(SR) of the MAIN PCB counterclockwise(c) as far as possible. (2) C onnect DC Voltmeter to the test points. FRONT-Lch : CN510 FRONT-Rch : CN550 CENTER ch : CN530 SURROUND-Lch : CN520...

  • Page 33: Surround Modes And Parameters

    SURROUND MODES AND PARAMETERS Contents Connections Playback Settings Tips Appendix Sound modes and channel output S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”. (v p. 83) Channel output Sound mode Front L/R...
  • Page 34 Contents Connections Playback Settings Tips Appendix Types of input signals, and corresponding sound modes F This indicates the default sound mode. S This indicates the selectable sound mode. Type and format of input signals DTS-HD Dolby Dolby Digital DTS-HD Dolby Dolby Sound mode DTS-HD...

  • Page 35: Trouble Shooting

    TROUBLE SHOOTING 1. POWER 1.1. The unit does not power on The unit does not power on Does the power indicator Does the power indicator on on the front panel flash in the front panel flash in red green when the power is when the power is turned on? turned on? Has a fuse broken?

  • Page 36: Analog Video

    2. Analog video MONITOR OUT(CVBS) Output NG Check ± 5V The power supply circuitry is +5V : C7810 defective. -5V : C7811 Check input Check pattern from JK781 to IC781 and Check output (When the SAT/CBL function) check cable between AMP and player Output V IC781-1pin Vin3 :...

  • Page 37: Hdmi/Dvi

    (6) Is the BD/DVD player's HDMI output setting correct? referring to the BD/DVD player's operating instructions. (7) When you use a DENON BD/DVD player's, is the fluorescent display tube's "HDMI" indicator lit? If you use a non-DENON BD/DVD player's, proceed to "YES".
  • Page 38 "HDMI" indicator to the IC721,IC731 are Is communication waveform confirmed in Test lit? defective. point (DDC_CLK/DDC_DATA)? If using a non-DENON BD/ Replace the IC721,IC731. Is terminate the TMDS signal is 3.3V confirmed of DVD player, proceed to each HDMI connector? "NO".
  • Page 39 (19) Check power supply. q Are 1.8V or 3.3V supplied to IC721 (each power supply pin)? The power supply circuitry is defective. w Are 1.1V or 3.3V supplied to IC731 (each power supply pin)? q The X721 or IC721 is defective. (20) Check xtal oscillator.
  • Page 40 3.2. HDMI test point and waveforms HDMI test point and waveforms MEDIA PLAYER CBL/SAT COAX IN DVD/Blu-ray MONITOR GAME(4K) BD(4K) CBL/SAT(4K) MEDIA PLAYER JK771 R7627 C7702 C7703 R7738 R7765 R7655 T7325 T7208 C7621 R7764 JK726 JK725 JK723 JK722 C7622 JK721 JK784 D7326 JK724...
  • Page 41 DDC_CLK/DDC_DATA/TMDS : Check items (16),(18) 0.9V DDC_CLK 2.48V TMDS SIGNAL DDC_DATA DVDD/XTAL/RESET/SCL : Check items (19),(20),(21) P-ON HDMI_SDA/SCL(I2C) : Check item (22) HDMI_SDA HDMI_SCL...

  • Page 42: Audio

    4. AUDIO 4.1. AUDIO CHECK AUDIO OUTPUT : NG INPUT SURROND MODE SOURCE CHECK1 Check ANALOG AUDIO BLOCK. ANALOG 2CH DIRECT ANALOG INPUT SURROND MODE SOURCE CHECK2 Check Digital AUDIO BLOCK. COAX or OPT Legacy(PCM or DolbyDigital or dts…) INPUT SURROND MODE SOURCE CHECK3...
  • Page 43 4.2. Power AMP (MAIN UNIT) No sound is output. The protector operates. Is the power transistor open or short- circuited? Replace the power transistor. 2SB1560/2SD2390 Is the emitter resistance of the power transistor open? Replace the emitter resistance. 0.47 Ω Is the base resistance of the power transistor open? Replace the base resistance.

  • Page 44: Bluetooth

    5. Bluetooth 5.1. A connected Bluetooth device is not recognized. Check the Bluetooth device being used Are there other Bluetooth devices on close by? Turn off other Bluetooth devices. This unit supports devices with A2DP Is the Bluetooth device supported by this unit? support.
  • Page 45 5.2. A connected USB device is not recognized. Check the USB device being used Is a USB hub being used? Do not use a USB hub. This unit supports devices in the FAT16 and FAT32-formatted mass storage class, MTP- Is the USB device supported by this unit? compatible devices and iPods (with the exception of some models).

  • Page 46: Smps

    6. SMPS DC 5V is not output. Replace the IC601 (TOP268VG) and Is IC601 (TOP268VG) damaged? D6001 - D6004. Has a fuse (F6001) broken? Is there the damage in D6001 - D6004? Replace the damaged part(s). Are there any short circuits caused by Repair the short circuited area(s) by the the soldering of the PCB? soldering of the PCB.
  • Page 47 PART Operation waveform for each part SMPS Primary drain After primary side rectification (Caution: High voltage, electric shock) (Caution: High voltage, electric shock) OPTION C6002 0.01uF 250V E3,K T 2A L 250V *OPTION OPTION E2,E1C T 1.6A L 250V F6001 D6001 1N4007 After secondary rectifications D6002 1N4007...

  • Page 48: Clock Flow & Wave Form In Digital Block

    CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK IC721 ADV7623BSDZ HDMI Transceiver (W/GUI) IC731 Wave form MN864788 HDMI 1 - 2 CH1: RXP2 HDMI 3 - 5 IC744 CS42528 (DIR+CODEC) RMCK(55) Coaxial1 (47)RXP2/GPO2 Optical1 (49)RXP0 SAI_SCLK(61) (32)DAI2_LRCK IC741 (33)DAI2_SCLK CS497024CVZ SAI_LRCK(60) (34)DAI2_DATA,DSD5 (AUDIO DSP)

  • Page 49: Level Diagram

    LEVEL DIAGRAM AVR-S518BT / X520BT / X518CI LEVEL1 DIAGRAM...
  • Page 50 AVR-S518BT / X520BT / X518CI LEVEL2 DIAGRAM...
  • Page 51 AVR-S518BT / X520BT / X518CI LEVEL3 DIAGRAM...
  • Page 52 AVR-S518BT / X520BT / X518CI LEVEL4 DIAGRAM...

  • Page 53: Audio Block Diagram

    AUDIO BLOCK DIAGRAM AVR-S518BT / X520BT / X518CI ANALOG AUDIO DIAGRAM...

  • Page 54: Digital Audio/Hdmi Block Diagram

    DIGITAL AUDIO/HDMI BLOCK DIAGRAM AVR-S518BT / X520BT / X518CI DIGITAL AUDIO / HDMI BLOCK X520BT X518CI...

  • Page 55: Video Block Diagram

    VIDEO BLOCK DIAGRAM AVR-S518BT / X520BT / X518CI VIDEO BLOCK...

  • Page 56: Power Block Diagram

    POWER BLOCK DIAGRAM AVR-S518BT / X520BT / X518CI VCC DIAGRAM...

  • Page 57: Wiring Diagram

    WIRING DIAGRAM AVR-S518BT / X520BT / X518CI WIRING DIAGRAM DIGITAL PCB ASS'Y VIDEO PCB ASS'Y REGULATOR PCB ASS'Y SMPS PCB ASS'Y MAIN PCB ASS'Y FRONT PCB ASS'Y STANDBY PCB ASS'Y PHONE PCB ASS'Y USB&MIC PCB ASS'Y...
  • Page 58 PRINTED WIRING BOARDS Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu). DIGITAL (A SIDE) DIGITAL (B SIDE) COAX IN MEDIA PLAYER CBL/SAT MONITOR GAME(4K) BD(4K) CBL/SAT(4K) MEDIA PLAYER DVD/Blu-ray JK771 R7231 R7627 C7702 C7703 R7738 R7655 T7325 R7765 T7208 Q7202 C7621 R7764...
  • Page 59 MAIN (A SIDE) MAIN (B SIDE) D5806...
  • Page 60 USB&BT (A SIDE) USB&BT (B SIDE) FRONT (A SIDE) FRONT (B SIDE) C1402 C9034 CUP12743Z C1411 C1410 C1405 R9062 BN914 C1406 C9056 C9013 R9063 R1412 MP 2015.02.24 C9021 R9064 IC906 C9027 D1401 R1405 R9028 R9024 R1411 R1403 C9054 L9013 R9025 R9061 IC910 R1409...
  • Page 61 REGULATOR (B SIDE) BK301 1A569 CUP12738Z-2 C3024 REGULATOR PART MP_STAGE CN302 ADJ1 ADJ2 RP BN301 BN302 C3006 JK301 Q3002 Q3001 AVR-S710W/X1200W F3001/F3002 USE AVR-S510BT/X520BT F3003/F3004 USE J3015 C3005 BK302 1A569-V1 J3004 C3012 J3006 D3003 D3001 C3007 C3013 C3008 D3004 D3002...

  • Page 62: Schematic Diagrams (1/12)

    CN711 TO FRONT B'D TO BN12B1 FFC WAFER/27P/1.25mm FOR UPDATE MCU PART CN711 FFC 27P CN714 OPEN TO 1A *EMI Coutermeasure. *EMI Coutermeasure.(C7124/C7125/C7144) MCU+3V3 AGND *EMI Coutermeasure. SUB_MUTE L7103~L7105, L7119: 0 ohm-->600 ohm Bead DGND DAC_MUTE MAIN_VOL_CLK MAIN_VOL_DATA TUNER_INT TUNER_RST *EMI PREPARE(C7149) TUNER_CE TUNER_SDIO...

  • Page 63: Sch02_Hdmi Osd

    HDMI OSD PART * HDMI ATC_CEC Connectivity TEST COUNTERMEASURE TO A5 R7231: OPEN-->0 ohm Change R7231 CEC_COM CEC_5V ADV7623_RST INT_TX INT2_RX INT_RX HDMI_SCL HDMI_SDA HDMIOSD_HOLD HDMIOSD_CLK HDMI_RESET <PVDD_1V8> L7209 HDMIOSD_CS 36.7mA CB03YTYH600 INT_TX HDMIOSD_MO INT2 <DVDD_1V8> HDMIOSD_MI L7210 332.4mA INT1 HDMI_SCL CB03YTYH600 X721...

  • Page 64: Sch03_Hdmi 4K

    CEC5V HDMI 4K PART L7301 VDD33 CEC3V3 CB05YTYH221 DGND AVDD33TX L7302 CB05YTYH221 CEC1V1 TO 0B OPEN AVDD33RX0 C7352 OSDTX_2+ AVDD33RX1 OPEN L7303 L7309 OSDTX_2- C7353 CB05YTYH221 OPEN OSDTX_1+ AVDD33RX2 OSDTX_1- C7345 AVDD33RX3 OPEN OSDTX_0+ C7346 OSDTX_0- PVDD33 OPEN OSDTX_C+ OSDTX_C- L7304 CB05YTYH221 OSDTX_SDA...

  • Page 65: Sch04_Dsp

    DSP PART DIR_INT CODEC_MUTE DSP_MODE_SEL DIR_CE DIR_RST DIR_MOSI FROM/TO INPUT/VOLUME PART TO DIGITAL POWER PART DIR_CLK DIR_MISO TO 1B TO 2B HDMI_SW DSP_CS DSP_SPC1_IRQ DSP_PCP_BSY DSP_RST DSP_MOSI DSP_MISO * Cirrus Recommend DSP_CLK TO A3 R7424, R7425: 10K-->3.3K Change. C7442 100uF/50V +3V3D C7443 0.1uF...

  • Page 66: Sch05_Digital Power

    DIGITAL POWER PART TO HDMI 4K PART TO HDMI OSD PART TO B0 TO A7 CN751 CN751 L7501 1.D5.2V CB03YTYH600 L7502 2.D5.2V L7508 CB03YTYH600 R7450 3.M_RESET L7527 CB03YTYH600 L7503 4.D_GND CB03YTYH600 CB03YTYH600 5.D_GND R7558 L7429 6.MAIN_POWER TO BN601 CB03YTYH600 DA_POWER Q7521 RT1N441C *EMI Coutermeasure.

  • Page 67: Sch06_Input, Volume

    INPUT/VOLUME PART MCU+3V3 AGND *TUNER MODULE OPTION SUB_MUTE TU771 AVR-S510BT E3 CNVYST990-A9U1 AVR-X520BT E2 CNVYST990-D8E1 DGND AVR-X520BT/X518CI E1C CNVYST990-A2J1 DAC_MUTE TU771 MAIN_VOL_CLK 1.CH_GND MAIN_VOL_DATA R7637 2.INT TUNER_INT R7651 3./RST TUNER_RST R7653 4./CE TUNER_CE R7656 5.SDIO TUNER_SDIO R7657 6.SCLK TUNER_SCLK 7.VCC 8.R-OUT...

  • Page 68: Sch07_Amp

    DC PROTECTION DC RPTECT OPTION ( CEN, SR, SL CH ) MCU PART 2.0mm 13PIN WIRE OPT. BN508 2.0mm 9PIN WIRE *TUNER MODULE OPTION PTC Thermistors AVR-S510BT E3 CNVYST990-A9U1 THERMALDET_A FL-CH, SL-CH, CEN_CH AVR-X520BT E2 CNVYST990-D8E1 BN508 THERMALDET_B FR-CH, SR-CH...

  • Page 69: Sch08_Video, Optical Input

    VIDEO/OPTICAL PART NLM2595 S/W TABLE(SW2,5 CONTROL) FUNC.IN (14) (10) MUTE X (L) R7807 MEDIA 270(1W) PLAYER CBL/SAT R7808 CN781 270(1W) C7805 JK781 10uF/50V CJJ4S010Z CBL/SAT IN 1.+12V J7806 OPEN 2.VGND 3.-12V 4.CVBS_SW2 MEDIA PLAYER IN C7804 5.CVBS_SW5 10uF/50V 6.+5VD R7801 7.OPT1_IN MONITOR OUT 1.8K...

  • Page 70: Sch09_Usb, Bt

    USB / BT PART ( SETUP MIC ) D9014 CDS3C05HDMI1 C9107 OPEN C9029 0.1uF D9010 1SS355T L9022 OPEN JK91 D9011 1SS355T CJJ9X010Z 4.DGND 3.USBD+ C9037 OPEN 2.USBD- C9030 0.1uF 1.VBUS RN909 0 X 2 C9010 220/6.3V OPTION IC905 R9012 2.2K CVIBD82065FVJ-E2 D9015 CDS3C05HDMI1...

  • Page 71: Sch10_Front

    *OPTION 1. AGND R1071 R1072 R1073 R1074 R1075 R1409 C1406 2. MIC_SIGNAL R1408 0.047uF OPTION OPTION OPTION OPTION OPTION AVR-S510BT/AVR-X520BT/AVR-X518CI RESISTOR VALUE 3. -12V PRESET+ STATUS 4. +12V KEY_1 KEY_2 KEY_3 C1410 SW108 SW109 SW110 SW111 SW112 SW113 KEY2 C1408 5.

  • Page 72: Sch11_Regulator

    REGULATOR PART D3101 FUSE OPTION OPEN F3001 F3002 F3003 F3004 IC305 CVIKIA7805BPI S710W/X1200W 218Series 218Series OPEN OPEN S510BT/X520BT/X518CI OPEN OPEN 932Series 932Series FUSE OPTION F3004 IC301 T 1.25A L 250V CVIKIA7812BPI D3001 1N4007 F3002 D3002 1N4007 T 1.25A L 250V BN301 5.DA+5V 1.AC_S2...

  • Page 73: Sch12_Smps

    C6025 OPEN(1608) WIRE/6P/2.5mm YW396-NNB IC604 AVR-S710W/X1200W CVIPST8448NR_A TO CN751 E3,K T 6.3A L 250V E2,E1C T 3.15A L 250V C6029 AVR-S510BT/X520BT/X518CI 0.1uF(1608) E3 T 5A L 250V R6025 E2,E1C T 2.5A L 250V 4.7K(1608) OPTION C6022 OPEN *OPTION *OPTION* AVRS710W/X1200W, S510BT/X520BT/X518CI...

  • Page 74: Exploded View Avr-S510Bt

    EXPLODED VIEW AVR-S510BT See the last chapter the part list. S3 x2 S6 x1 S3 x2 S6 x3 S3 x6 S3 x1 S9 x3 S6 x7 S6 x4 S3 x2 S6 x3 S6 x1 S7 x2 S9 x3 S4 x1...

  • Page 75: Exploded View Avr-X520Bt / X518Ci

    EXPLODED VIEW AVR-X520BT / X518CI See the last chapter the part list. S6 x2 S3 x2 S6 x1 S6 x3 S3 x2 S3 x6 S3 x1 S9 x3 S6 x7 S6 x4 S3 x2 S6 x3 S6 x1 S7 x2 S9 x3 S4 x1 S1 x1...

  • Page 76: Packing View Avr-S510Bt

    PACKING VIEW AVR-S510BT See the last chapter part numbers. UK plug Adaptor...

  • Page 77: Packing View Avr-X520Bt / X518Ci

    PACKING VIEW AVR-X520BT / X518CI See the last chapter part numbers. 5-7 5-8 UK plug Adaptor...

  • Page 78: Semiconductors

    SEMICONDUCTORS Only major semiconductors are shown. General semiconductors etc. are omitted from list. The semiconductors which have a detailed drawing in a schematic diagram are omitted from list. STM32F101xC, STM32F101xD, STM32F101xE Pinouts and pin descriptions Pinouts and pin descriptions 1. IC's STM32F101ZE (DIGITAL : IC711) Figure 3.
  • Page 79 Pin Pin Name Symbol Pullup STBY stop Function 29 PC3 OPTION M3VPu MODEL OPTION 30 VSSA GND fixed 31 VREF- GND fixed 32 VREF+ 3.3V 33 VDDA 3.3V 34 PA0 / WKUP 35 PA1 USB_RESET BX8804(USB DECORDER) RESET control 36 PA2 USB_RX BX8804(USB DECORDER) RX control 37 PA3...
  • Page 80 Pin Pin Name Symbol Pullup STBY stop Function 95 VDD_9 3.3V 96 PC6 97 PC7 VFD_CE VFD_CE 98 PC8 VFD_CLK VFD_CLK 99 PC9 100 PA8 VFD_DATA VFD_DATA 101 PA9 UPDATE_TX UPDATE TX 102 PA10 UPDATE_RX UPDATE RX 103 PA11 104 PA12 MN864788_HAINT HDMI CONTROL 105 PA13...
  • Page 81 M24128, M24C64, M24C32 Description M24C32WMN6TP (DIGITAL : IC712) Table 2. Signal names Signal name Function Direction E0, E1, E2 Chip Enable Input Serial Data Serial Clock Input Write Control Input Supply voltage Ground Figure 2. DIP, SO, TSSOP and UFDFPN connections M24128 M24C64 M24C32 ADV7623 Hardware Manual V CC...
  • Page 82 ADV7623 Hardware Manual ADV7623 Terminal Functions Table 6. Function Descriptions Location Mnemonic Type Description DDCC_SCL Digital Input HDCP slave serial clock port C. DDCC_SCL is a 3.3 V input that is 5 V tolerant. CVDD Power Receiver comparator supply voltage (1.8V) CGND Ground TVDD and CVDD Ground RXC_C-...
  • Page 83 ADV7623 Hardware Manual Location Mnemonic Type Description D in the HDMI interface. RXD_0+ HDMI Input Digital input channel 0 True of port D in the HDMI interface. CGND Ground TVDD and CVDD Ground RXD_1- HDMI Input Digital input channel 1 complement of port D in the HDMI interface.
  • Page 84 ADV7623 Hardware Manual Location Mnemonic Type Description TXGND Ground TXAVDD Ground TX0- HDMI Output Differential Output Channel 0 Complement. Differential output of the red data at 10× the pixel clock rate; supports TMDS logic level. TX0+ HDMI Output Differential Output Channel 0 True. Differential output of the red data at 10×...
  • Page 85 ADV7623 Hardware Manual Location Mnemonic Type Description MCLK_IN Digital Input Audio Reference Clock. 128 × N × fs with N = 1, 2, 3, or 4. Set to 128 × sampling frequency (fs), 256 × fs, 384 × fs, or 512 × fs.
  • Page 86 ADV7623 Hardware Manual Location Mnemonic Type Description AP0_OUT Digital Output Audio output port 0. AP1_OUT Digital Output Audio output port 1. AP2_OUT Digital Output Audio output port 2. AP3_OUT Digital Output Audio output port 3. AP4_OUT Digital Output Audio output port 4. DGND Ground Ground for DVDD...
  • Page 87 ADV7623 Hardware Manual Location Mnemonic Type Description CGND Ground TVDD and CVDD Ground RXA_C- HDMI Input Digital input clock Complement of port A in the HDMI interface. RXA_C+ HDMI Input Digital input clock True of port A in the HDMI interface. TVDD Power Receiver terminator supply voltage (3.3 V)
  • Page 88 ADV7623 Hardware Manual Location Mnemonic Type Description B in the HDMI interface. RXB_1+ HDMI Input Digital input channel 1 true of port B in the HDMI interface. TVDD Power Receiver terminator supply voltage (3.3 V) RXB_2- HDMI Input Digital input channel 2 complement of port B in the HDMI interface.
  • Page 89 CS497024CVZ (DIGITAL : IC741)
  • Page 90 CS497024CVZ Block diagram MX25L8006EM2I-12G (DIGITAL : IC742) PIN DESCRIPTION SYMBOL DESCRIPTION SO/SIO1 HOLD# Chip Select Serial Data Input (for 1 x I/O)/ Serial Data SCLK SI/SIO0 Input & Output (for Dual Output mode) SI/SIO0 Serial Data Output (for 1 x I/O)/ Serial Data SO/SIO1 Output (for Dual Output mode) Clock Input SCLK Write protection...
  • Page 91 M12L16161A5TG (DIGITAL : IC743) M12L16161A5TG Terminal Functions Pin Name Input Function System Clock Active on the positive going edge to sample all inputs. Disables or enables device operation by masking or enabling all inputs except Chip Select CLK, CKE and L(U)DQM. Masks system clock to freeze operation from the next clock cycle. Clock Enable CKE should be enabled at least one cycle prior to new command.
  • Page 92 CS42528-CQ (DIGITAL : IC744) CS42528 Block diagram...
  • Page 93 CS42528 Terminal Functions...
  • Page 94 TC74VHC157F/FN/FT/FK TC74VHC157FT (DIGITAL : IC745-747) Pin Assignment IEC Logic Symbol (15) SELECT SELECT A S G 1 MUX (11) (10) (14) (12) (13) (top view) Truth Table Inputs Output SELECT EN5339QI t Number Package Markings Temp Rating (° C) Package Description N5339QI EN5339 -40 to +85 24-pin (4mm x 6mm x 1.1mm) QFN T&R 5339QI-E...
  • Page 95 NJU72340A (DIGITAL :IC761) NJU72340A Terminal Functions...
  • Page 96 BX8804(USB : IC901) TDO / GP44 GP05 / SPI0 CK TMS / GP45 GP04 / SPI0 CS GP03 / EXT Clock GP29 / CDDSP SCOR0 ECSN GP30 / CDDSP BCLK0 EOEN / GP42 GP31 / CDDSP DATA0 EWEN / GP41 GP32 / CDDSP LRCK0 EAD20 / GP40 / Boot Mode GP33 / SBDT0 EAD19 / GP39...
  • Page 97 BX8804 Terminal Functions Name Type Description Alternative Function ADIN1 ADC analog input[1] ADIN0 ADC analog input[0] AVDD33 ADC Analog Power supply (3.3V) AVSS33 ADC Analog Ground GP00 General Purpose IO 00 External Interrupt 0 GP01 General Purpose IO 01 External Interrupt 1 External SDRAM data bus [0] External program data bus [0] External SDRAM data bus [8]...
  • Page 98 External SDRAM Bank selector 1 External program address bus [14] LDQM SDRAM Lower byte data mask External program address bus [15] UDQM SDRAM Upper byte data mask External program address bus [16] SDCSN SDRAM Chip select VDD12 Digital power supply (1.2V) VSS12 Digital Ground SDRAM clock enable...
  • Page 99 GP19 General Purpose IO 19 SPI1 MISO GP20 General Purpose IO 20 SPI1 MOSI External Interrupt 3 GP21 General Purpose IO 21 SPI2 CS DDATA Audio serial data for external DAC IOVDD33 I/O Power supply (3.3V) IOVSS33 I/O Ground DMCK Master clock for external DAC DBCK Audio serial data Bit clock...
  • Page 100 GP30 General Purpose IO 30 CDDSP BCLK0 GP31 General Purpose IO 31 CDDSP DATA0 GP32 General Purpose IO 32 CDDSP LRCK0 GP33 General Purpose IO 33 SBDT0 GP34 General Purpose IO 34 SBCK Timer0 Output GP35 General Purpose IO 35 External Interrupt 10 GP36 General Purpose IO 36...
  • Page 101 W9864G6JH-6 (USB : IC902) W9864G6KH-6 Terminal Functions...
  • Page 102 MX25L1606EM2I-12G (USB : IC904) MX25L1606EM2I-12G Terminal Functions BD82065FVJ (USB : IC905)
  • Page 103 TOP268VG (SMPS : IC601) DRAIN (D) CONTROL (C) INTERNAL SUPPLY SHUNT REGULATOR/ ERROR AMPLIFIER SOFT START 5.8 V 4.8 V INTERNAL UV 5.8 V PS(UPPER) COMPARATOR V I (LIMIT) CURRENT LIMIT ADJUST ÷ 16 PS(LOWER) ON/OFF SHUTDOWN/ EXTERNAL CURRENT CURRENT LIMIT AUTO-RESTART LIMIT (X) COMPARATOR VOLTAGE STOP LOGIC...

  • Page 104: Fl Display

    2. FL DISPLAY FLD (018BT021GINK) (FRONT : FL101) PIN CONNECTION GRID ASSIGNMENT...
  • Page 105 ANODE CONNECTION...
  • Page 106 FRONT FRONT PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.
  • Page 107 FRONT REF No. Part No. Part Name Remarks Q'ty New Ver J1061 WIRE, COPPER(D0.6) C3A206 0.02 J1063-1072 WIRE, COPPER(D0.6) C3A206 J1074 WIRE, COPPER(D0.6) C3A206 0.02 JK104 90M-YT004500R JACK, PHONES(6.35mm,SILVER) CJJ2E026Z L1001 FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V L1010-1013 FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V LUG11 WIRE ASS'Y CWE8102100RV...
  • Page 108 USB PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.
  • Page 109 REF No. Part No. Part Name Remarks Q'ty New Ver L9026,9027 FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V X9001 943141100610S X-TAL, SMD 3.2X2.5, 12.000MHz, 10PF COX12000I100ST ★ 943606502450D CARD CABLE(1.0mm, 10P, 60mm, Btype, 80'C) CWC4F4A10A060A0 ★ 943606502440D CARD CABLE(1.25mm,27p,200mm,Btype, 105'C, Shield) CWC5C4A27B200B1 1...
  • Page 110 POWER POWER PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.
  • Page 111 MAIN MAIN PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.
  • Page 112 MAIN REF No. Part No. Part Name Remarks Q'ty New Ver R5305 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T R5306 RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT R5307 RES, CARBON(1/5W,220ohm,J) CRD20TJ221T R5308 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T R5309 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T R5310 RES, M-OXIDE FILM(1W/47ohm) 1W/47ohm CRG1SANJ470RT R5313 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T R5314 RES, CARBON(1/5W,560ohm,J)
  • Page 113 MAIN REF No. Part No. Part Name Remarks Q'ty New Ver C5402 CAP, MYLAR(100V/470pF/J) 100V/470pF/J HCQI2A471JZT C5403 CAP, CERAMIC(50V/82pF/J) CCCT1H820JC C5404 CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT C5405 CAP, ELECT(50V/220uF) CCEA1HH221T C5406 CAP, CERAMIC(50V/33pF/J) CCCT1H330JC C5407 CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T C5408 CAP , ELECT(63V/100uF) CCEA1JH101T C5409 CAP, MYLAR(50V/0.1uF/J)
  • Page 114 DIGITAL DIGITAL PCB ASS'Y ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.
  • Page 115 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R7254 RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T R7255 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R7256,7257 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R7258 RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T R7259 RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T R7260-7266 RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T R7267 RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T R7268 RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T R7269,7270...
  • Page 116 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver R7614 RES, CHIP(1608/5%/220ohm) CRJ10DJ221T R7615,7616 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R7617,7618 RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T R7619,7620 RES, CHIP(1608/5%/100ohm) CRJ10DJ101T R7621,7622 RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T R7623,7624 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R7625 RES, CHIP(1608/5%/470ohm) CRJ10DJ471T R7626 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R7627...
  • Page 117 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C7307 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C7308 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C7309 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C7310 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C7311 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS C7312-7328 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG...
  • Page 118 DIGITAL REF No. Part No. Part Name Remarks Q'ty New Ver C7613,7614 CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG CCUI1H101JAS C7615 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C7617 CAP, CHIP(1608, 50V/2700pF, X7R)_SAMSUNG CCUS1H272KCS C7618 CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS C7619,7620 CAP, CHIP(1608, 50V/220pF, C0G)_SAMSUNG 1608, 50V/220pF, C0G CCUS1H221JAS C7621,7622 CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG...
  • Page 119 AVR-S510BT_EXPLODED AVR-S510BT EXPLODED ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations.
  • Page 120 943446100590D PLATE, VOLUME KNOB CGX1A469 943412101070D KNOB, SELECT CBN1A274 943446100760D PLATE, VOLUME KNOB CGX1A481 VGU1A462N, 943416101320D WINDOW CGU1A462N 42141002400AD BADGE, DENON CGB1A254Z-V1 943402105390D FRONT/SUB PANEL ASS'Y VGW1A553RA 943411101750D BUTTON, POWER CBT1A1167 943423100510D INDICATOR, POWER CGL1A299A36 943411101770D BUTTON, 10KEY CBT2A1164 HOLDER, BT...
  • Page 121 ! P15 943101102400D TRANS,POWERAVR-X510BT/E1C,(85.8X57) VLT5U056ZH 943412100710D KNOB,VOLUME CBN1A263 943446100590D PLATE,VOLUMEKNOB CGX1A469 943412101070D KNOB,SELECT CBN1A274 943446100760D PLATE,SELECTKNOB CGX1A481 943416101320D WINDOW VGU1A462N 42141002400AD BADGE,DENON CGB1A254Z-V1 943402106380S FRONT/SUBPANELASS'Y VGW1A553FA 943411101750D BUTTON,POWER CBT1A1167 943423100510D INDICATOR,POWER CGL1A299A36 943411101770D BUTTON,10KEY VBT2A1164 HOLDER,BT VMH1A356 PLATE,EARTHUSB VMC1A430 CHASSIS,BOTTOM VUA4A335...
  • Page 122 AVR-S510BT_PACKING AVR-S510BT_PACKING ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.
  • Page 123 AVR-X520BT_PACKING AVR-X520BT_PACKING ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.
  • Page 124 AVR-X518CI_PACKING AVR-X518CI_PACKING ※Parts indicated by "nsp"on this table cannot be supplied. ※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions. NOTE:The symbols in the column Remarks indicate the following destinations. E3 : U.S.A.

This manual is also suitable for:

Avr-x520btAvr-x518ci

Table of Contents

Save PDF
