Explanatory Photos for DISASSEMBLY
•
The angles from which the photos are taken are shown by "Photo angle: A, B, C, D".
•
See the diagram below about the shooting direction of each photograph.
•
Photographs with no shooting direction indicated were taken from the top of the unit.
•
The photograph is AVR-X5200WE3 model.
The viewpoint of each photograph
(Shooting direction:X)[View from the top]
Shooting
direction: D
↓Shooting direction: B↓
↑Shooting direction: A↑
12
Front side
Shooting
direction: C
