DISASSEMBLY

• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read "Precautions During Work" before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the
work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FLD PCB
(Ref. No. of EXPLODED VIEW : C1)
HP PCB
(Ref. No. of EXPLODED VIEW : C2)
HDMI USB FRONT PCB
(Ref. No. of EXPLODED VIEW : B2)
Bluetooth PCB
(Ref. No. of EXPLODED VIEW : E1)
TOP COVER
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
(Ref. No. of EXPLODED VIEW : D)
R-AMP CONNECT PCB
(Ref. No. of EXPLODED VIEW : D1)
L-AMP CONNECT PCB
(Ref. No. of EXPLODED VIEW : D2)
RADI_PROTDET2 PCB
(Ref. No. of EXPLODED VIEW : D5)
11
SMPS PCB
See "DISASSEMBLY"
3. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
(Ref. No. of EXPLODED VIEW : D3)
MAIN TRANS
See "DISASSEMBLY"
4. MAIN TRANS
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 8)
BACK PANEL ASSY
See "DISASSEMBLY"
5. BACK PANEL ASSY
and "EXPLODED VIEW"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : A)
AUDIO/VIDEO PCB
(Ref. No. of EXPLODED VIEW : B)
DAC PCB
(Ref. No. of EXPLODED VIEW : B1)
CONNECTOR-1 PCB
(Ref. No. of EXPLODED VIEW : B4)
CONNECTOR-2 PCB
(Ref. No. of EXPLODED VIEW : B5)
CONNECTOR-3 PCB
(Ref. No. of EXPLODED VIEW : B6)
CONNECTOR-5 PCB
(Ref. No. of EXPLODED VIEW : B8)
SPEAKER PCB
(Ref. No. of EXPLODED VIEW : C)
HL SPEAKER PCB
(Ref. No. of EXPLODED VIEW : C3)
232C POHNO PCB
(Ref. No. of EXPLODED VIEW : D4)
CX870 CONNECT PCB
(Ref. No. of EXPLODED VIEW : E)
CX870 MODULE
(Ref. No. of EXPLODED VIEW : 59)
