- Page 1 CAD Re-assembly instructions for our neutral CAD file formats Product: Guide cylinders, Series MSC Parts assembled: 2 (5) Consists of following parts: 6 pcs Parts assembled: 2 (5) Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx 1(4)
- Page 2 Insert Constraint 1(3): Insert Align Constraint 2(3): Constraint 3(3): (1.9mm) Insert Constraint 2(3) : Mate Constraint 3(3) : 2 - Assemble C part. Parts assembled: 3 (6) Insert Constraint 1(2): Mate Constraint 2(2): Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx 2(4)
- Page 3 Parts assembled: 4 (6) Insert Constraint 1(2): 1. Assemble C part. No of parts assembled: 4 (5) Mate Constraint 2(2): 4 - Assemble 1 Stopper part. Parts assembled: 5 (6) Insert Constraint 1(2): Mate Constraint 2(2): Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx 3(4)
- Page 4 5 - Assemble 2 Stopper part. Parts assembled: 6 (6) Insert Constraint 1(2): Mate Constraint 2(2): Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx 4(4)
