Summary of Contents for Atlas Copco PHD 26
- Page 2 Repair Instructions No. 162.11/95 PAGE PHD 26/ PH(D) 38/ PH 240 D/ PH 350 (D) Special Tools Pressing-in tool 276 8000 Required Assembly tip 283 5000 Assembly cone 283 1000 (PH 350 (D)/ PH (D) 38) Assembly cone 283 1100 (PH 240 D/ PHD 26)
- Page 3 Repair Instructions No. 162.11/95 PAGE PHD 26/ PH(D) 38/ PH 240 D/ PH 350 (D) Dismantling the Remove the pillow block (4) of the cylinder sleeve reduction gear shaft as well as the sleeve. Only applicable for "D"-models: Completely remove the switch lever (1) and the selector shaft (2).
- Page 4 Repair Instructions No. 162.11/95 PAGE PHD 26/ PH(D) 38/ PH 240 D/ PH 350 (D) Dismantling the Remove the brush holders (1) from the motor machine. Remove the screw of the retaining clip (8). Remove the retaining clip and the carbon brushes.
- Page 5 Repair Instructions No. 162.11/95 PAGE PHD 26/ PH(D) 38/ PH 240 D/ PH 350 (D) Maintenance General It is recommended to regularly submit the tool to maintenance, or as soon as the hammer mechanism gets weak, or when the carbon brushes switch off. When carrying out maintenance all parts of the maintenance set must be exchanged.
- Page 6 Repair Instructions No. 162.11/95 PAGE PHD 26/ PH(D) 38/ PH 240 D/ PH 350 (D) Assembly Assembling the Fix the switch (3), the capacitor (2), and On/Off switch the other electric parts with screws. Mount the pair of handle shells (1).
- Page 7 Repair Instructions No. 162.11/95 PAGE PHD 26/ PH(D) 38/ PH 240 D/ PH 350 (D) Mounting the Press the ball bearing on the reduction reduction gear gear shaft (4) and secure it with the shaft locking ring. Press the distance sleeve (5), the two...
- Page 8 Repair Instructions No. 162.11/95 PAGE PHD 26/ PH(D) 38/ PH 240 D/ PH 350 (D) Mounting the Fit the bearing end plate (2). If necessary, nosepiece with aid of a plastic hammer. Insert the washer. First insert a pair of disk...
