- Page 1 Document No.: LEY-MM00102 Maintenance Manual Motor Replacement Product Name Electric Actuator / Rod Type Model/Series LEY Series Applicable model: LEY*，LEYG* LEYG Series LEY Series (Guide rod type) (Rod type)
- Page 2 Revision history Rev. Date of Person Details of the changes Approved Remarks symbol change in charge...
- Page 3 Contents 1. How to Replace the Motor (Parallel Mounting Type)………………………..p 3 2. How to Replace the Motor (Straight Type)……………………………………p 5 3. Motor Assembly No. (Order No. for Replacement Motor)………………….p 7...
- Page 4 1. How to Replace the Motor (Parallel Mounting Type) 1-1. Motor Removal Procedure * Tools required are a hexagon wrench set and a Phillips screwdriver. 1. Remove the cover and grommet. (For motor option "with cover" or "with lock cover" only.) Grommet Grommet Lift the cover hook up...
- Page 5 1-2. Motor Replacement Procedure 1. Mount the grommet onto the lock cable, then mount the motor cover with lock onto the motor. (For motor option "with lock cover" only.) Lock cable Motor cover with lock Grommet 2. Mount the motor with screws (2 pcs.) temporarily to assemble the belt. * For size 32/40, hold the hexagon nuts with a spanner when tightening the screws.
- Page 6 2. How to Replace the Motor (Straight Type) 2-1. Motor Removal Procedure * Tools required are a hexagon wrench set and a Phillips screwdriver. 1. Remove the cover and grommet. (For motor option "with cover" or "with lock cover" only.) Grommet Motor cover Grommet...
- Page 7 2-2. Motor Replacement Procedure 1. Mount the grommet onto the lock cable, then mount the motor cover with lock and cover support onto the motor. (For motor option "with lock cover" only.) Lock cable Cover support Grommet Motor cover with lock 2.
- Page 8 3. Motor Assembly No. (Order No. for Replacement Motor) 3-1. Motor Assembly No. (Parallel Mounting Type) ＬＥＹ (1) Motor type Step motor (servo 24 VDC) Servo motor (24 VDC) For size 16/25 only (3) Motor option (2) Size LEY16/LEYG16 LEY25/LEYG25 LEY32/40/LEYG32/40 List of included items Part name...
- Page 9 3-2. Motor Assembly No. (Straight Type) ＬＥＹ Ｄ (1) Motor type Step motor (servo 24 VDC ) Servo motor (24 VDC) For size 16/25 only (2) Size (3) Motor option LEY16/LEYG16 LEY25/LEYG25 LEY32/40/LEYG32/40 List of included items Part name Qty. Remarks Motor with hub Motor mounting...
