Operating and display elements
[1]
Display of system, subsystem or function
[2]
Status display of active menu level
[3]
Display of temperature set (set temperature)
[4]
Display of operating mode set
[5]
Display of time program set
[6]
Display of system components
[7]
Advanced functions for heating circuit, DHW
[8]
Display of time
[9]
Field for switching between the display type (old/new display
version) on the display
[10] Information menu
[11] Field for returning to the previous level/screen
[12] Field for returning to the system overview
[13] Status display of system components
Control 8311/8313 – 6720859790 (2020/02)
