OPERATION

After you switch on the device with the power switch, the device starts running. The display lights up and you
can choose the desired mode via the buttons MENU, ENTER, UP, DOWN.
The device features a memory function. The last program selected will begin anew when the device is
restarted.
The device has two operating modes. It can be operated in stand-alone mode via the control board and the
EUROLITE IR-35 remote control or in DMX-controlled mode via a standard DMX controller and QuickDMX
with suitable wireless transmitter.

Stand-alone mode

In the stand-alone mode, you can do without a controller. Disconnect the device from the controller, de-
activate QuickDMX and call the desired setting. Please refer to the instructions under Control Board.

Master/slave operation

Several devices may be interconnected. Then all slave units can be synchronized and controlled with the
master unit without the need for a DMX controller. The devices must be set to the corresponding operating
modes.
1
Set the master device to the mode Master. Set the slave mode Slave on every slave device. Please
refer to the instructions under Control Board.
2
Connect the DMX output of the master unit to the DMX input of the first slave unit. Then connect the
DMX output of the first slave unit to the DMX input of the second slave unit, etc. until all units have been
connected in a chain. Make sure the master unit is the first in the chain. Do not connect a DMX
controller to the DMX input of the master unit.
3
The interconnected devices will now operate synchronously.

Master/Slave operation via QuickDMX

Set the master device and each slave device to the same transmission channel using the function
"WIRELESS" -"ID Set", to change the transmission channel and pair the devices.
The selected transmission channel is indicated by the status indicator.
Channel Color
1 Red
2 Green
3 Blue
4 Yellow (red/green)
5 Cyan (green/blue)
6 Magenta (red/blue)
Choose the device which is to control the effects. This device then works as master device and controls all
other slave devices.
Set the master device to the master mode. Set the slave mode on every slave device. Please refer to the
instructions under Control Board.
30/40 00128199, Version 1.0
