Diese Bedienungsanleitung gilt für die Artikelnummer / This user manual is valid for the article number: 41602038 Das neueste Update dieser Bedienungsanleitung finden Sie im Internet unter: You can find the latest update of this user manual in the Internet under: www.eurolite.de 2/36 00131515, Version 1.0...
SICHERHEITSHINWEISE WARNUNG! Lesen Sie aufmerksam die Sicherheitshinweise und benutzen Sie das Produkt nur wie in dieser Anleitung beschrieben, damit es nicht versehentlich zu Verletzungen oder Schäden kommt. Verwendungszweck • Bei diesem Gerät handelt es sich um einen Scheinwerfer, mit dem sich dekorative Lichteffekte erzeugen lassen.
Page 5
Warnung vor Verbrennung und Brand • Der zulässige Umgebungstemperaturbereich (Ta) beträgt -5 bis +45 °C. Verwenden Sie das Gerät niemals außerhalb dieses Temperaturbereichs. • Die Gehäusetemperatur (Tc) kann im Betrieb bis zu 55 °C betragen. Vermeiden Sie den Kontakt mit Personen oder Gegenständen.
INSTALLATION WARNUNG! Verletzungsgefahr durch Herabfallen Über Kopf installierte Geräte können beim Herabstürzen erhebliche Verletzungen verursachen! Stellen Sie sicher, dass das Gerät sicher installiert ist und nicht herunterfallen kann. Die Montage darf nur durch eine Fachkraft erfolgen, die mit den Gefahren und den einschlägigen Vorschriften hierfür vertraut ist.
ANSCHLÜSSE Gerät 1 Gerät 2 Gerät 3 Startadresse 1 Startadresse 11 Startadresse 21 DMX-Controller Program Chase32 Step100 DMX512-Ansteuerung Für die Ansteuerung des Geräts per DMX512 ist eine Datenverbindung notwendig. Das Gerät verfügt dazu über 3-polige XLR-Anschlüsse. Verbinden Sie den Ausgang Ihres Controllers mit dem DMX-Eingang DMX IN des Geräts über ein DMX- Kabel.
Betriebsart. Nehmen Sie nun die notwendigen Menüeinstellungen für die jeweilige Betriebsart mit den Bedientasten vor. Auch wenn Sie das Gerät vom Stromnetz trennen, bleiben alle Einstellungen gespeichert. Das Gerät kann entweder im Standalone-Modus über das Bedienfeld und die Fernbedienung EUROLITE IR-7 oder im DMX-gesteuerten Modus über einen handelsüblichen DMX-Controller betrieben werden.
Menüstruktur Anzeige Modus Funktion 10CH 06CH DMX-Betrieb 05CH ADDR:001-512 04CH 03CH Konstantes Leuchten in einer von 27 Farbvoreinstellungen STATIC 01-27 Farben Automatikbetrieb AUTO 01-09 Auto Programm Musiksteuerung SOUND 01-09 Sound Programm Ablaufgeschwindigkeit Ablaufgeschwindigkeit für Automatikbetrieb und SPEED 01-09 langsam > schnell Musiksteuerung Mikrofonempfindlichkeit Mikrofonempfindlichkeit...
Standalone-Betrieb Farbvoreinstellungen Im Modus STATIC strahlt das Gerät konstant in einer von 27 vorgegebenen Farben. Drücken Sie die Taste MENU so oft, bis das Display die Betriebsart STATIC anzeigt. Bestätigen Sie mit der Taste ENTER. Wählen Sie mit den Tasten UP und DOWN die gewünschte Farbe (1-27). Bestätigen Sie mit der Taste ENTER.
Page 12
Gesamthelligkeit Im Menu DIMMING lässt sich die Gesamthelligkeit für alle Standalone-Betriebsarten einstellen. Drücken Sie die Taste MENU so oft, bis das Display das Menü DIMMING anzeigt. Bestätigen Sie mit der Taste ENTER. Wählen Sie mit den Tasten UP und DOWN die gewünschte Helligkeit (01 = dunkel, 99 = hell). Bestätigen Sie mit der Taste ENTER.
Fernbedienung IR-7 Das Gerät muss für die Ansteuerung per Fernbedienung aktiviert werden. Wählen Sie dazu im Menüpunkt INFRARED die Einstellung ON. Halten Sie beim Betätigen einer Taste die Fernbedienung immer in Richtung des Sensors auf der Gerätevorderseite. Zwischen Fernbedienung und Sensor muss Sichtverbindung bestehen.
Page 14
Hinweis: Bitte vergewissern Sie sich, dass sich die Steuerkanäle nicht mit anderen Geräten überlappen, damit das Gerät korrekt und unabhängig von anderen Geräten in der DMX-Verbindung funktioniert. Werden mehrere Geräte auf eine Adresse definiert, arbeiten sie synchron. Funktionen im DMX-Betrieb 3-Kanal-Modus Kanal Wert...
Page 15
030 – 039 Auto Programm 3 040 – 049 Auto Programm 4 050 – 059 Auto Programm 5 060 – 069 Auto Programm 6 070 – 079 Auto Programm 7 080 – 089 Auto Programm 8 090 – 099 Auto Programm 9 100 –...
REINIGUNG UND WARTUNG Das Gerät sollte äußerlich in regelmäßigen Abständen von Verunreinigungen wie Staub usw. gereinigt werden. Insbesondere die Linsen sollten sauber sein, damit das Licht mit maximaler Helligkeit abgestrahlt werden kann. Trennen Sie das Gerät vom Netz und lassen Sie es abkühlen, bevor Sie mit der Reinigung beginnen. Reinigen Sie die Oberflächen mit einem fusselfreien, angefeuchteten Tuch.
Direct color selection for 27 preset colors • Addressing via control panel with LCD and four operating buttons • Convenient wireless control via included IR remote control EUROLITE IR-7 • Sound-control via built-in microphone with adjustable microphone sensitivity • Supports QuickDMX - the wireless DMX system from Eurolite •...
SAFETY INSTRUCTIONS WARNING! Please read the safety warnings carefully and only use the product as described in this manual to avoid accidental injury or damage. Intended use • This device is a spotlight for creating decorative lighting effects. This device is designed for professional use in the field of event technology, e.g.
Page 22
Warning – risk of burns and fire • The admissible ambient temperature range (Ta) is -5 to +45°C. Do not operate the device outside of this temperature range. • The housing temperature (Tc) can be up to 55°C during use. Avoid contact by persons and materials. •...
DESCRIPTION OF THE DEVICE (1) Fixation screw (7) Safety eyelet (2) Infrared sensor for the remote control (8) Power input (3) 200 W COB LED,RGB+ WW (9) DMX input (4) Mounting stand/bracket (10) DMX output (5) LCD and operating buttons (11) USB port for QuickDMX wireless receiver (6) Microphone (12) Power output...
INSTALLATION WARNING! Risk of injury caused by falling objects Devices in overhead installations may cause severe injuries when crashing down. Make sure that the device is installed securely and cannot fall down. The installation must be carried out by a specialist who is familiar with the hazards and the relevant regulations. The device may be placed on the floor or fastened to a truss or similar rigging structure.
CONNECTIONS Device 1 Device 2 Device 3 Start Address 1 Start Address 11 Start Address 21 DMX Controller Program Chase32 Step100 DMX512 control A DMX512 data link is required in order to control the device via DMX. The device provides 3-pin XLR connectors for DMX connection.
The operating modes can be selected by means of the display and the control buttons. All settings remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone mode via the control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any commercial DMX controller.
Menu structure Display Mode Function 10CH 06CH DMX mode 05CH ADDR:001-512 04CH 03CH Preset colors STATIC 01-27 Constant lighting in one of 27 colors Automatic mode AUTO 01–09 Auto program Sound control SOUND 01-09 Sound program Running speed in Program running speed automatic mode and SPEED 01-09...
Stand-alone mode Preset colors In the STATIC mode the device will constantly emit one of 27 preset colors. Press the MENU button so many times until STATIC is indicated in the display. Confirm with the ENTER button. Use the buttons UP and DOWN to adjust the desired color. Confirm with the ENTER button. Automatic mode In automatic mode, 9 show programs are available that run at an adjustable speed.
Page 29
Color temperature In the TEMPERAT mode the device will constantly emit white light. The color temperature of the light beam is adjustable. Press the MENU button so many times until TEMPERAT is indicated in the display. Confirm with the ENTER button. Use the buttons UP and DOWN to adjust the desired color temperature (1800K –...
Remote control IR-7 The device must be activated for remote control. For this, set menu item INFRARED to ON. When actuating a button, always direct the remote control towards the sensor. There must be no obstacles between remote control and the sensor. Button Function BLACKOUT...
Page 31
Note: Please make sure that you do not have any overlapping channels in order to control each device correctly and independently from any other fixture on the DMX chain. If several devices are addressed similarly, they will work synchronically. Functions in DMX mode 3-channel mode Channel Value...
Page 32
020 – 029 Auto program 2 030 – 039 Auto program 3 040 – 049 Auto program 4 050 – 059 Auto program 5 060 – 069 Auto program 6 070 – 079 Auto program 7 080 – 089 Auto program 8 090 –...
Page 33
020 – 029 Green 030 – 039 Blue 040 – 049 Warm white 050 – 059 Yellow 060 – 069 Magenta 070 – 079 Cyan 080 – 089 Dark orange 090 – 099 Green yellow 100 – 109 Salmon 110 – 119 Turquoise 120 –...
CLEANING AND MAINTENANCE The outside of the device should be cleaned periodically to remove contaminants such as dust etc. The lenses, in particular, should be clean to ensure that light will be emitted at maximum brightness. Disconnect the device from power and allow it to cool before cleaning. Clean the surface with a soft lint-free and moistened cloth.
