EuroLite AKKU UP-7 QCL Spot QuickDMX User Manual page 36

11 channel mode
Channel Value
1 0-255
2 0-255
3 0-255
4 0-255
5 0-255
0-14
6
15-255
0-31
32-63
64-95
7
96-127
128-159
160-191
192-223
224-255
8 0-255
0-5
6-55
9
56-105
106-155
156-205
206-255
0-124
10
125-249
250-255
0-3
4-10
11-17
18-24
25-31
32-38
39-45
46-52
53-59
60-66
67-73
11
74-80
81-87
88-94
95-101
102-108
109-115
116-122
123-129
130-136
137-143
144-150
151-157
158-164
Feature
Dimmer, dimmer intensity from 0 to 100 %
Red, 0 - 100 % increasing
Green, 0 - 100 % increasing
Blue, 0 - 100 % increasing
White, 0 - 100 % increasing
No function
Strobe effect with increasing speed
Fading in/out
Neutral
Fade in (0 % - 100 %) (speed and effect depending on the control
channels 1 - 5)
Fade out (100 % - 0 %) (speed and effect depending on the control
channels 1 - 5)
Fade out and fade in (100 % - 0 % - 100 %) (speed and effect depending
on the control channels 1 - 5)
Program "Fading"
Program "Fade out - fade in"
Program "Switching"
Sound control
Speed Fading in/out, programs channel 7 and internal programs
channel 11
increasing speed
Dimmer speed (step response)
Control Board setting dimmer speed
OFF: Response characteristics of LEDs
Dim1: Response characteristics of halogen lamps, fast
Dim2: Response characteristics of halogen lamps, less fast
Dim3: Response characteristics of halogen lamps, middle
Dim4: Response characteristics of halogen lamps, slow
Jump/fade internal programs
Jump -Switching colors
Fade - Fading colors
Power-save mode, 50 % power
Internal programs
Black - Blackout (no internal program)
Pty 1 - Red Green Blue
Pty 2 - Cyan Magenta Yellow
Pty 3 - Red Green Blue Cyan Magenta Yellow
Pty 4 - Red Green Blue White
Rbw - Rainbow Red, Yellow, Green, Cyan, Blue, Magenta
RD - Red Dark
RG - Red Green
RB - Red Blue
RY - Red Yellow
RC - Red Cyan
RM - Red Magenta
RW - Red White
GD - Green Dark
GB - Green Blue
GY - Green Yellow
GC - Green Cyan
GM - Green Magenta
GW - Green White
BD - Blue Dark
BY - Blue Yellow
BC - Blue Cyan
BM - Blue Magenta
BW - Blue White
36/40 00128199, Version 1.0
