Adapters - IAR SYSTEMS I-jet User Manual

The USB indicator
Indicator status Description
Off No USB power.
Green steady Initial state or no transfer.
Green blinking USB transfers to or from I-jet.
Red blinking USB enumeration.
Red steady USB did not enumerate or broken hardware.
Table 7: USB indicator statuses

ADAPTERS

There are a number of useful adapters available. All of them are automatically
recognized by I-jet. The following adapters are described in detail:
The ADA-MIPI20-ISO isolation adapter
●
The ADA-MIPI20-ARM20 adapter
●
The ADA-MIPI20-TI14 adapter
●
The ADA-MIPI20-cTI20 adapter
●
The ADA-MIPI20-STSWD6 adapter
●
Adapters not included in the I-jet package can be purchased from IAR Systems.
These are the mating target headers for the adapters
TI-14
HTST-107-01-L-DV
Table 8: Mating target headers, part numbers
The ADA-MIPI20-ISO isolation adapter
The ADA-MIPI20-ISO isolation adapter galvanically isolates signals between the I-jet
MIPI-20 connector and the target MIPI-20 connector. You can use it to reduce the risk
of damage to the I-jet debug probe associated with power ground loops, voltage spikes,
electrostatic discharge (ESD), and noisy power and ground lines generated by targets
which drive high-current motors and other machinery.
The adapter has two MIPI-20 headers marked TO I-JET and TO TARGET. Make sure
to connect the headers correctly because switching the sides will not work and might
damage the adapter. The target side of the isolation adapter can be used with any passive
IAR I-jet adapters, for example, the ADA-MIPI20-ARM20, ADA-MIPI20-TI14, and
ADA-MIPI20-CTI20 adapters, and the MIPI20-MIPI10 cable.
cTI-20
TML-110-02-GD-SM-006 (shrouded)
FTR-110-51-S-D-06 (unshrouded)
