I-jet®, I-jet Trace, and I-scope™
Signal
DBGACK
TRACECLK
GND
TRACECTL
TRACEDATA[00]
TRACEDATA[01]
TRACEDATA[02]
TRACEDATA[03]
TRACEDATA[04]
TRACEDATA[05]
TRACEDATA[06]
TRACEDATA[07]
TRACEDATA[08]
TRACEDATA[09]
TRACEDATA[10]
TRACEDATA[11]
TRACEDATA[12]
TRACEDATA[13]
TRACEDATA[14]
TRACEDATA[15]
GND
GND
Table 21: ADA-MICTOR-MIP160 adapter pinout (Continued)

DESIGNING TARGET BOARDS FOR ETM TRACE

Because ETM trace port signals might have very fast rise and fall times—regardless of
the trace frequency—it is important that the target PCB is designed properly so it does
not distort the trace signals before they get to the connector.
For best results, it is recommended that the ETM trace signals be simulated for signal
integrity on a routed PCB by HyperLinx (or similar signal integrity SW).
Pin Pin Signal
11 12 VREF TRACE
13 14
15 16 GND
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
41 42
43 44
45 46
47 48
49 50
51 52
53 54
55 56
57 58 GND
59 60
