Technical specifications
IAR Debug Probes User Guide
36
I-jet®, I-jet Trace, and I-scope™
I-jet
Pin Name
direction
6 Input TDO
/SWO
Yellow Input VTref
Red Output 5V Output This pin can be used for supplying 5V power to the
Table 12: ADA-MIPI20-STSWD6 adapter pin definitions (Continued)
Description
SWD trace output port. Optional—not required for
SWD operation.
The target reference voltage. Used by I-jet to check
whether the target has power, to create the logic-level
reference for the input comparators, and to control the
output logic levels to the target. It is normally fed from
the target's VDD voltage.
target hardware from I-jet.
