Technical specifications
IAR Debug Probes User Guide
44
I-jet®, I-jet Trace, and I-scope™
JTAG/SWD/ETM voltage range 1.2 V to 5 V
Current draw from target VTref < 50 uA
Power requirement
Operating temperature
Storage temperature
I-Jet Trace A/R/M features
In addition to the above model specifications, I-jet Trace A/R/M has these features:
Support for ETMv3, ETMv4, and PTM/PFT trace and debug interfaces on any Arm
●
Cortex-A/R/M device equipped with CoreSight
Trace port support of up to 350 MHz double data rate (DDR) (700 Msamples/s for
●
each trace data line) for a total of 11.2 Gbit/s throughput
Support for streaming of trace data at up to 3.2 Gbytes/s
●
Automatic alignment of parallel trace data skew on individual bits to compensate
●
for PCB layout and signal integrity problems
Automatic trace data and clock voltage threshold adjustments to get the most
●
reliable trace data collection with noisy or unterminated target boards
64-bit timestamp with 5 ns resolution (or CPU cycle accurate) for precise timing
●
analysis
No external power adapter needed when powering target boards that take less than
●
200 mA

HARDWARE REVISION HISTORY

These are the versions of I-jet Trace CM:
Version Change specification
Version A IAR Systems internal version
Version B Production version
Version C Added 100k pull-up on nSRST
Version C1 Increased voltage level on JTAG output pins for better
compatibility with 5 V devices
Version D0 No functional changes (PCB changes only)
Version D1 No functional changes (PCB changes only)
Table 13: I-jet Trace CM versions
3000 mW maximum (from USB or external DC,
without target)
32-86°F (0-30°C)
32-176°F (0-80°C)
Date
24/Mar/2014
26/May/2014
26/Nov/2014
15/May/2015
19/Feb/2016
28/Jul/2016
