ADC resolution
Maximum sampling rate
V1, V2, V3 voltage channels range 0 to 6 V
V1, V2, V3 voltage channels
resolution
V1, V2, V3 voltage channels
accuracy
Maximum differential voltage
between I+ and I- probes
These are the I-scope specifications per shunt:
1 Ohm shunt
Current channel resolution 26.8 uA
Current channel accuracy 53.7 uA
Current channel 0-110 mA
measurement range
Applications General purpose
MCU current and
power
measurements
Table 23: I-scope specifications per shunt
12 bits
200 ksps
1.49 mV (1 LSB)
2.98 mV (2 LSB)
110 mV
10 Ohm shunt 100 Ohm shunt
2.68 uA 0.268 uA
5.37 uA 0.537 uA
0-11 mA 0-1.1 mA
Low-power MCU Measuring power-down
current and power and sleep modes
measurements current consumption
I-scope
