This is the pinout of the target cTI20 JTAG header. Pin 6 should be missing to indicate
the proper orientation.
TMS 1 2
TDI 3
4
TVD (PD)
5 6
TDO
8
7
TCKRTN
9 10
TCK
11
12
EMU0
13 14
nSYSRST
15 16
EMU2 (NC)
17 18
EMU4 (NC)
19
20
These are the top view dimensions of the ADA-MIPI20-cTI20 adapter:
A 0.74 in (18.9 mm)
B 0.7 in (17.7 mm)
C 0.76 in (19.4 mm)
D 0.07 in (1.8 mm)
J 0.24 in (6.0 mm)
K 0.50 in (12.8 mm)
These are the side view dimensions of the ADA-MIPI20-cTI20 adapter:
nTRST
TDIS
KEY
GND
GND
GND
EMU1
GND
EMU3 (NC)
GND
