Technical data
4.3

Options

The board APCI-3003 is available in the following options:
PC-Diff.: ................................................... Current input for 1 differential channel
................................................................... (0-20 mA, 4-20 mA)
Note:
4.4

Limit values

Max. Altitude: ........................................... up to 2000 m above sea level
Operating temperature: ............................. 0 to 60°C
Storage temperature: ................................. -25 to 70°C
Relative humidity at indoor installation
50% at +40 °C
80% at +31 °C
Minimum PC requirements:
PCI BIOS from Version 1.0
Bus speed: ................................................. < 33 MHz
Operating system: ..................................... Windows 2000, XP, Linux (other
Slot:............................................................ PCI 5 V or PCI 3.3 V, 32-bit
Current consumption (without load): ........ typic. See table ± 10%
4.4.1

Analog inputs

Number of analog inputs: .......................... 4 differential channels
Analog resolution: ..................................... 16-bit, 1 in 65535
Max. sampling rate: ................................... 400 kHz
Data transfer: ............................................. data to the PC via FIFO buffer,
12
Measuring range
0 mA
4 mA
20 mA
At 4-20 mA a reduced precision is possible.
+ 5 V from PC
With 16-bit resolution
Corresponds 0 digit
Corresponds 13107 digits
Corresponds 65535 digits
operating systems on request)
APCI-3003
1.55 A
via I/O commands,
interrupt at EOC or DMA transfer at
EOC
APCI-3003
