Graco Fluid Automation 633 Operation

Graco Fluid Automation 633 Operation

Meter-mix dispense systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation
633 Meter-Mix
Dispense Systems
For metering, mixing, and dispensing of silicone material.
For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
See page 3 for model information, including maximum
working pressure and approvals.
If the visuals in the printed copy are unclear, refer to the
electronic version available on www.graco.com.
332078C
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fluid Automation 633 and is the answer not in the manual?

Questions and answers

Related Manuals for Graco Fluid Automation 633

Summary of Contents for Graco Fluid Automation 633

  • Page 1 Read all warnings and instructions in this manual. Save these instructions. See page 3 for model information, including maximum working pressure and approvals. If the visuals in the printed copy are unclear, refer to the electronic version available on www.graco.com.

  • Page 2: Table Of Contents

    Startup ........40 Graco Information......52 Shutdown .

  • Page 3: Models

    Models Models Maximum Working Pressures Part No. psi (MPa, bar) Description PLC, Potentiometer Controlled, Fixed Ratio Meter Mix Dispense Sys- tem. Dispense System has proportional pneumatic control to provide automatic adjustment during material dispense. PLC, Potentiometer Controlled, Fixed Ratio Meter Mix Dispense System 3000 (21, 207) mounted to a Pneumatic Controlled 1:1 to 2:1 Variable Ratio 55-Gallon Feed Machine.

  • Page 4: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
  • Page 5 Warnings WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent fire and explosion: • Use equipment only in well ventilated area. • Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop cloths (potential static arc).
  • Page 6 Warnings WARNING MOVING PARTS HAZARD Moving parts can pinch, cut or amputate fingers and other body parts. • Keep clear of moving parts. • Do not operate equipment with protective guards or covers removed. • Pressurized equipment can start without warning. Before checking, moving, or servicing equipment, follow the Pressure Relief Procedure and disconnect all power sources.

  • Page 7: Component Identification

    Component Identification Component Identification Model 633 Stack Light Indicator Refill Solenoid (Red = Fault, Amber = Pump Started) Bleed Ball Valve Air Inlet Refill Valve Operator Interface Panel Feed Pressure Gauge Main Air Solenoid Pump Linear Position Automatic Pressure Regulator and Air Motor Solenoids Stop Button Cylinder Pressure Transducer .

  • Page 8: Model 633-Sr657-1M-Lr

    Component Identification Model 633-SR657-1M-LR Stack Light Indicator Refill Solenoid (Red = Fault, Amber = Pump Started) Bleed Ball Valve Air Inlet Refill Valve Operator Interface Panel Feed Pressure Gauge Main Air Solenoid Pump Linear Position Automatic Pressure Regulator and Air Motor Solenoids Stop Button Cylinder Pressure Transducer Refer to the SR657-1M-LR Meter-Mix...

  • Page 9: General Information

    General Information General Information Pressure Settings All pressure settings are controlled through the Operator Interface Panel. Refer to Screen 2, page 27, to set the feed station pressure. NOTICE To avoid machine damage, do not exceed 120 psi (0.8 MPa, 8.3 bar) air pressure at the machine inlet. Fluid Pressure Gauges All A and B material pressure gauges should read the same as each other during normal operation of...

  • Page 10: Screen Navigation

    Screen Navigation Screen Navigation 332078C...
  • Page 11 Screen Navigation 332078C...
  • Page 12 Screen Navigation Refer to Screen 1, page 25, for mor details. 332078C...
  • Page 13 Screen Navigation Refer to Screen 2, page 26, for mor details. 332078C...
  • Page 14 Screen Navigation Refer to Screen 3, page 26, for mor details. 332078C...
  • Page 15 Screen Navigation Refer to Screen 4, page 27, for mor details. 332078C...
  • Page 16 Screen Navigation 332078C...
  • Page 17 Screen Navigation 332078C...

  • Page 18: Screen Identification

    Screen Identification Screen Identification Main Screen This is the default screen that shows up when the machine is powered on. It shows the current state of the machine and navigates to all screens related to setup and running. Icon Description Shows the current mode of the machine.
  • Page 19 Screen Identification Icon Description Navigates to a screen allowing calibration of: • Pressure Transducers • Cylinder Linear Position Sensor Navigates to a screen allowing the user to select if a condition is either a Warning (keeps the machine running) or a Fault (stops dispensing). Navigates to a screen showing the history of alarms that have occurred.
  • Page 20 Screen Identification Mode Select Screen The Mode Select Screen is used for the following: • Select the mode to operate the machine in. • Turn color injectors on or off. • Enable/Disable Frequency Fault Alarms. Icon Description This mode allows the machine to operate in a fully automatic mode. It waits for a signal from the press to begin dispensing material.
  • Page 21 Screen Identification Icon Description “Outlets Closed” is the default state. It allows the button to open during a “Manual Feed”. Toggling the button to “Outlets Open” keeps the outlet valve open at all times - even during a refill. The unit will refill the pump cylinders while this button is pressed. Letting go of the button mid-refill will cause the machine to stop refilling.
  • Page 22 Screen Identification Monitor Screen The Monitor Screen shows the vitals of the system at a glance. It indicates how much material remains in the pump and what pressures are in the system. If color injection is enabled, it shows the injection interval and when the next injection will occur.
  • Page 23 Screen Identification Alarm History Screen Shows a history of the alarms generated by the unit. System IO Screen Shows what inputs and outputs are active on the unit. 332078C...
  • Page 24 Screen Identification Calibration Screen The calibration screen allows the user to adjust any sensor on the system that appears to be out of calibration. The top half of the screen is for pressure transducers and the bottom half is for the position sensor of the pump. Icon Description Configuring pressure transducers on the unit.
  • Page 25 Screen Identification Presets Screen Screen 1 Icon Description The total shot volume of the 633 machine is 150 cc’s. The value in this field indicates how much material is required to fill the mold in the press. If there is not enough material left in the cylinders to fill the mold, the machine will trigger a refill.
  • Page 26 Screen Identification Screen 2 Icon Description Minimum pressure must be present on both the A and B cylinders during refill. The cylinders will stop refilling until the pressure rises above this set point. Amount of pressure that is supplied to the pump to assist in refill. It may cause the material to dip below the “A - B Min Refill Pressure”...
  • Page 27 Screen Identification Screen 4 Icon Description Both material pressures are being monitored during the refill and dispense cycles of the machine. If the one component material pressure drops below the other component material pressure by X amount, the machine will alert the user. This is the amount of time before the alarm is checked after the refill done bit activates.
  • Page 28 Screen Identification Alarm Setting Screen Icon Description Conditions listed above can be configured as a “Warning” or a “Fault” condition by User #4 (Refer to Select User Level Screen, page 29). Touching the “Warning”/”Fault” text will tog- gle the condition. A “Warning”...
  • Page 29 Screen Identification Select User Level Screen This screen is accessible through the “Alarm Setting Screen”. It selects user levels and allows the “System Admin.” to change passwords. User Level Description Default Password Level 1 - User Not Currently Used. 1970 Level 2 - Setup &...
  • Page 30 Screen Identification Security - Update Passwords Screen This screen is only accessible by User Level 4 when they are logged in. Icon Description The current password is displayed here. To change the password, touch the field. When finished, press the “Confirm” button. New passwords are not official until the “Confirm”...
  • Page 31 Screen Identification Warning and Alarms Screens Refer to the Calibration section of the manual for details on calibrating the pressure transducers and the position sen- sor of the pump. If equipped with a material level sensor on the color reservoir, the warning will indicate that the material level is low. If the warning has never been generated before the machine runs out of colorant, the low level sensor may need to be recalibrated.
  • Page 32 Screen Identification These screens indicate that the machine was not able to refill its plungers properly. The likely cause for this is the feed system was not able to provide material. It is detected by monitoring the pressure in each cylinder during a refill. If installed, refer to the SR657-1M-LR Meter-Mix Dispense Systems-Operation manual for additional details.
  • Page 33 Screen Identification This indicates that the unit could not fill its plungers completely. Verify the following: • Verify the feed system is functioning and providing enough pressure. If installed, refer to the SR657-1M-LR Meter-Mix Dispense Systems-Operation manual for additional details. •...
  • Page 34 Screen Identification The feed station has indicated that it requires attention. This indicates that it may no longer be able to supply material to the metering unit. Refer to the feed station manual and check if there is sufficient material in it. These warnings indicate that the combination of the shot size and the injection percent will result in inconsistent mix- ture in the material.

  • Page 35: Installation

    Installation Installation Locate and Secure the Machine Ground the System. a. Move the machine to a desired location. b. Install the feet onto the base. The equipment must be grounded to reduce the risk of static sparking. Static sparking can cause fumes to ignite or explode.
  • Page 36 Installation Fill the Colorant Tank and Prime Adjust the Colorant Tank Regulator to the desired pressure. For 2000 centipoise colorant, the Color Injector (Optional) 50 psi (345 kPa, 3.4 bar) should be sufficient. a. Reduce the air pressure supplied to the Colo- rant Tank by turning the regulator on top of the tank in a counter-clockwise direction.

  • Page 37: Setup

    Setup Setup is facing sideways or even slightly up to remove all the trapped air. Set the Material Specific Gravity Bleed Valve a. Navigate to the “Calibration Screen” from the “Main Screen”. b. Using the specific gravity data from the material manufacturer, enter the data in the column labeled “S.G.”.
  • Page 38 Setup Adjust the Colorant Injector Shot e. Prime Metering Cylinder and Material Supply Line by pressing the Inlet Valve A solenoid but- Size ton located on the machine frame. Purge until it appears that no air is remaining in the hose. To properly deliver the correct percentage of colorant to the “A”...
  • Page 39 Setup Adjust the Feed Station Pressure Collect a sample of 20 cycles into a tare weighed cup using the manual actuator on the Refer to the SR657-1M-LR Meter-Mix Dispense Sys- color injector solenoid valve. tems-Operation manual for additional details. a. Monitor the pressures in the individual cylinders during a dispense.

  • Page 40: Startup

    Startup Startup Moving parts can pinch or amputate fingers. When the pump is operating and when raising or lowering the pail shelf, keep fingers and hands away from the pump intake, platen, pail shelf, and lip of the pail. Once the Setup procedures have been accomplished, the machine is ready to run.

  • Page 41: Shutdown

    Shutdown Shutdown Short Term Long Term Perform the procedure if the machine will be left idle Perform the procedure if the machine will be left idle less than the pot life of the material. more than the pot life of the material. 1.

  • Page 42: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure This equipment stays pressurized until pressure is manually relieved. To help prevent serious injury from pressurized fluid, such as skin injection, splashing fluid and moving parts, follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or servicing the equipment.

  • Page 43: Bleed Valves

    Operation Operation Bleed Valves Perform the procedure mechanically and if the dispense Normal operation of the machine will take place in “Auto head is plugged or there is no air to actuate the dis- Mode.” The metering unit will wait for a “screw rotate pense head solenoid.

  • Page 44: Testing Procedures

    Testing Procedures Testing Procedures Pump Testing If the machine is suspected of pumping inaccurately, fol- low these procedures to check each pump. At normal operating pressure, test if the pump is leaking inside, which will cause one pump to run at a higher pressure than the other.

  • Page 45: Troubleshooting

    Troubleshooting Troubleshooting Before performing any troubleshooting procedure: 1. Perform Pressure Relief Procedure on page 42. 2. Press the Stop Button. 3. Remove air supply. 4. Allow the press equipment to cool. Calibrate Pressure Transducers Perform this procedure when the “Actual” Value shown on the “Calibration”...

  • Page 46: Schematics

    Schematics Schematics . 3: Electrical - 1 332078C...
  • Page 47 Schematics . 4: Electrical - 2 332078C...
  • Page 48 Schematics . 5: Electrical - 3 332078C...

  • Page 49: Dimensions

    Dimensions Dimensions Model 633 Dimensions A - Height 72 in. (183 cm) B - Width 36 in. (91 cm) C - Depth 48 in. (122 cm) 332078C...

  • Page 50: Model 633-Sr657-1M-Lr

    Dimensions Model 633-SR657-1M-LR Dimensions 633-SR657-1M-LR A - Height 85 in. (216 cm) B - Width 64.5 in. (164 cm) C - Depth 49.5 in. (126 cm) 332078C...

  • Page 51: Technical Data

    * Flow rates and viscosities are general estimates. Flow rates drop as viscosity increases. Fluids are expected to shear under pressure. New applications or fluids should always be tested to determine proper line sizes and equipment selections. See your Graco authorized distributor for other capabilities. Contact us today! 763-428-5075 www.endisys.com.
