Instructions - Parts List
Hurricane
Electric Dispense System
For dispensing oil, gear lube, anti-freeze, and automatic transmission fluid.
DO NOT use with flammable fluids or in Class 1 hazardous locations.
200 psi (1.38 MPa, 13.8 bar) Maximum Working Pressure
See page 2 for model numbers and configurations.
Patent Numbers
KP 408657
TW D112658
US D537,458
CN ZL200530007586.6
DEU, SPA, FRA, ITA, UK 1549572
Australian Patent 2007238502
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
™
311216J
TI7049
TI7047
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco Hurricane 234902
Summary of Contents for Graco Hurricane 234902
- Page 1 Instructions - Parts List ™ Hurricane 311216J Electric Dispense System For dispensing oil, gear lube, anti-freeze, and automatic transmission fluid. DO NOT use with flammable fluids or in Class 1 hazardous locations. 200 psi (1.38 MPa, 13.8 bar) Maximum Working Pressure See page 2 for model numbers and configurations.
-
Page 2: Related Manuals
Model Numbers and Configurations Model Numbers and Configurations 8 ft 25 ft Part (2.44 m) (7.62 m) Number Approvals 110 V 220 V Tapper Dispenser Dispenser Power Cord Interface ✔ ✔ 234902 North American plug ✔ ✔ 247396 North American plug ✔... - Page 3 Read fluid and solvent manufacturer’s warnings. For complete information about your material, request MSDS forms from distributor or retailer. • Check equipment daily. Repair or replace worn or damaged parts immediately with genuine Graco replacement parts only. •...
- Page 4 Warnings WARNING PRESSURIZED EQUIPMENT HAZARD Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the eyes or on skin and cause serious injury. • Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning, checking, or servicing equipment.
-
Page 5: Setup And Operation
Setup and Operation Setup and Operation Clamp (13) Inlet hose clamp(21) Black plastic barbed fitting (18) 2 screws Bung (13) adapter (6) Inlet strainer (20) Dispenser unit shown TI7035 ™ Take Hurricane Electric Dispense System out of the box. 2. Check that all unassembled parts shown are present. - Page 6 Setup and Operation TI7036 TI7038 Assemble inlet strainer (20) and black plastic barbed fitting Insert bung adapter (6) into bung hole of supply container (18) to inlet end of suction hose (2). and hand tighten. Leave clamp (13) open. TI7041 TI7042 Feed suction hose (2) through bung adapter (6) and push 10.
- Page 7 Setup and Operation TI7536 TI7537 13. On handset unit, extend the nozzle sleeve (b) by pulling it away from the dispenser. While holding sleeve in extended position, press the trigger until fluid begins to flow. TI7045 TI7046 14. On handset unit, press trigger to dispense fluid. 15.
- Page 8 5. Reprime the pump. that amount will be lost and the meter screen will display 0.00. 6. If this does not correct the problem, contact your Graco distributor. Determining Pump Usage Thermal Overload To determine the total amount of fluid dispensed, in gal- lons, follow these steps.
- Page 9 Replacing the Dispense Assemblies Replacing the Dispense Assemblies Remove the handset assembly Reference numbers on F . 1 refer to the Parts List on page 13. 1. Disconnect power before beginning this procedure. 2. Remove 4 screws (A) to detach the motor cover (8). Pull motor cover down.
-
Page 10: Troubleshooting
Troubleshooting Troubleshooting Problem Cause Solution Motor or control system is damaged. Contact your Graco distributor for return or repair Electric outlet is not providing Try a different outlet or plug in a power. device that you know is working to test the outlet. - Page 11 Extension cord is damaged. Replace extension cord. Pump electric cord is damaged. Check for broken insulation or wires. Contact your Graco distributor if dam- aged. Fluid leaks from any location on the Seals or connections need to be Contact your Graco distributor for pump or meter.
- Page 12 Parts Parts Item 21 detail 21 (not visible 21 (not visible from this from this angle, angle, see detail at left) see detail at right) 17❖ 17❖ 17❖ 17❖ 14* or 14★ 24† 22† 23† 2❖ 2❖ 18❖ 18❖ 20❖ 20❖...
-
Page 13: Parts List
Parts List Parts List Parts included in 8 ft (2.44 m) Handset Replacement Ref. Kit 253279, which may be purchased separately. Description Qty. ★ Parts included in 25 ft (7.62 m) Handset Replace- 1*★ SCREW, machine, torx pan head ment Kit 253395, which may be purchased sepa- (qty. -
Page 14: Technical Data
Technical Data Technical Data Flow range ............... 0.5 to 2.0 gpm Out-of-box flow rate* . - Page 15 Technical Data 311216J...
-
Page 16: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twenty four months from the date of sale or up to a dispense volume of 5,000 gallons, repair or replace any part of the equipment determined by Graco to be defective.
