Operation, Parts
™
STX
Air Spray Trigger Gun
For portable spraying of water-based materials. Can be used for application of
solvent-based materials only when solvent compatible seals are installed and solvent
compatible, conductive hoses are used. For professional use only.
Not approved for use in European explosive atmosphere locations.
Model 17Y910
Requires up to 30 SCFM (0.83 m
1000 psi (7.0 MPa, 70 bar) Maximum Working Pressure
125 psi (0.9 MPa, 9 bar) Maximum Air Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual and in
the T-Max operation manual before using the equipment.
Save these instructions.
Related Manuals:
3A6748
T-Max Operation, Repair, Parts
3
/min) air
3A6746B
EN
