Configuration Examples
Connecting Devices
Fig. 20
Connecting a device to internet:
1. Connect an Ethernet cable between Wireless Bolt IoT and the device.
2. Verify that the device is connected to internet.
6.2

Setting Up Wireless Bolt IoT with ULPM

You can use Wireless Bolt IoT as an internet router with Ultra Low Power Mode (ULPM) to save
electrical energy.
Devices using other power sources than grid connected power, such as devices powered by
batteries and/or solar panels, benefit from using ULPM.
Procedure
How to use Wireless Bolt IoT with ULPM commands:
1. Setup Wireless Bolt IoT as an internet router.
Refer to
2. Send the ULPM command to Wireless Bolt IoT together with the desired ULPM sleep time.
Result
→ Wireless Bolt IoT enters ULPM and wakes up after the specified time has elapsed.
A power cycle will cancel ULPM. When power is restored, the ULPM command is resent and
Wireless Bolt IoT enters ULPM.
ULPM with REST Commands
The host device can also activate or deactivate ULPM by sending REST commands, via the
Wireless Bolt IoT LAN port.
For more information, refer to
® ™
Anybus Wireless Bolt IoT User Manual
Setting Up Wireless Bolt IoT as an Internet Router, p. 23
Setting Up Wireless Bolt IoT with REST Commands, p.
25 (40)
26.
SCM-1202-139 1.0 en-US
