Installation
4.3
Connecting to Ethernet/Power Over Ethernet (PoE)
Before You Begin
Shielded or unshielded Ethernet cables may be used.
Wireless Bolt IoT is designed to comply with PoE class 0 (37-57 VDC, max 0.35 A), according to IEEE
802.3.
Procedure
Fig. 3
1.
Connect the Wireless Bolt IoT Ethernet port to Ethernet/PoE.
Ethernet Connector, RJ45 PoE
Pin
1
2
3
4
5
6
7
8
Housing
2.
Connect Wireless Bolt IoT to Functional Earth (FE) via the Power connector.
Follow the instruction in
®
™
Anybus
Wireless Bolt IoT
User Manual
Data
PoE
TD+
A+
TD-
RD+
A-
B+
RD-
A-
B-
Functional Earth (FE), via 1 nF capacitor and 1 MΩ bleeder resistor
Shield
Connecting to Power, p.
Positive power from alt. A PSE
Negative power from alt. A PSE (with pin 6)
Positive power from alt. B PSE
Negative power from alt. A PSE (with pin 3)
Negative power from alt. B PSE
10.
9 (40)
SCM-1202-139 1.0 en-US
