Selectronic SP PRO Installation Notes page 5

SP PRO Three Phase
Installation Notes
Parameter to be programed
For a DC couple solar system – Set Shunt 2
Max current
(Configuration Settings > Shunts)
SoC control
(Configuration Settings > Quick Start)
Battery capacity
(Configuration Settings > Quick Start)
Max Charge current
(Configuration Settings > Charger)
Battery Charger voltage, time and temperature
compensation settings
(Configuration Settings > Charger)
DC shutdown voltages
(Configuration Settings > Inverter)
Note: L1 controls the inverter shutdown
DC Shutdown Recovery Voltage
(Configuration Settings > Inverter )
Generator lockout override
(Configuration Settings > AC Source >
Generator Auto Start)
Generator controller (Using L1 to control
generator)
(Configuration Settings > AC Source >
Generator Controller Settings)
AC source power
(Configuration Settings > Quick Start)
IN0016 Revision 12 Part # 004573 – 5 of 22
L1
1/3 solar shunt's max current (to let each unit
account for its 1/3 of the charging)
Enabled
Battery capacity
(@ C rate being used, if unknown use C10)
1/3 Max battery charge current
NOTE: This setting cannot exceed 200A in
systems with DC coupled Solar.
To suit battery bank
Lower than
To suit
L1 by 10% or
system
minimum
To suit system
Lower than
To suit
L1 by 10% or
system
minimum
Enable Disable
Solar Hybrid (Grid Connected): Maximum
required AC source power per phase.
Off Grid systems: 1/3 capacity of three
phase Generator (Example: If Generator is
20kW then set L1 = L2 = L3 to 6.7kW).
POWER
L2 L3
Lower than
L1 by 10% or
minimum
Lower than
L1 by 10% or
minimum
