SP PRO Fronius Primo Managed AC Coupling
Installation Notes
SP PRO Fronius Primo Managed AC
Coupling
Introduction
The SP PRO and Selectronic Certified (SCERT) Fronius Primo Managed AC Coupling provides a
method of linking the single phase Fronius Primo range of grid tie inverters to the SP PRO via
the AC Load supply. Regardless of whether the grid or a generator is connected, the SP PRO
can manage and control the Fronius grid tie inverters.
Each SP PRO can manage a maximum of five Fronius Primo SCERT grid tie inverters by
commanding each one to output the required amount of power to simultaneously supply the
load, export to the grid and charge the battery bank as required at any particular point in time.
This is done via a communications link between the SP PRO and the Fronius Primo SCERT.
This document only applies to Fronius Primo SCERT inverters that have been pre-programmed
by Selectronic and details the additional steps needed to install the managed system.
The SP PRO and Fronius Primo SCERTs must be installed as per their individual installation
instructions with the additional allowance of communications cables linking all of the inverters
together.
Note: This document needs to be read in conjunction with the SP PRO Instruction Manual and
the Fronius Primo Instruction Manual.
No SP PRO Installed? Important information
If the Primo inverter is not yet connected to an SP PRO, refer to Fronius SCERT Backup
Ready Connection instructions (page 3).
• Only make adjustments to the Primo configuration as indicated in this
document.
• The SP PRO and Fronius Primo SCERT Managed AC coupling cannot be used
with a Fronius Smart Meter. See Appendix III: Disable Fronius Smart Meter
(p
age 40).
• Installer must contact Fronius for the Profile Settings access code.
• SP PRO Series 2i and Series II: Single and Advanced Multiphase compatible.
• SP PRO Series I: Single Phase only.
For Fronius Primo SCERT that need to be re-programmed, see Appendix II: Fronius Step
Through Configuration
ADDITIONAL INFORMATION
Selectronic web site –
IN0049 Revision 08 (005273) – 1 of 46
(page 28).
http://www.selectronic.com.au
or contact the Selectronic Sales Team.
POWER
PERFORMANCE
PASSION
