Description
Model 84824 overfill warning device,
designed for double wall tanks, functions as
air supply shut-off to pump when tanks
reach near full capacity. In shut-off position,
air is diverted from pump to signal whistle to
alert full tank condition. Warning device
automatically resets when tank is emptied.
Periodical operational testing can be
performed by lifting test button about one
inch; this should shut-off air to pump and
sound signal whistle. Release button and
valve will reset itself.
Owner/Operator
responsibility
It is responsibility of owner/operator to
properly use and maintain equipment.
It is responsibility of owner/operator to
maintain legibility of all warning and
instruction labels.
Owner/Operator shall retain manual for
future reference to important warnings,
operating and mainte nance instructions.
Specifications
Fits into 2 in.NPT tank opening
Air inlet port
Air outlet port
Overall height
Maximum air pressure
Use of an air filter, regulator and lubricator is recommended to prevent damage to unit.
1)
Indicates change.
*
/
in. NPT internal
1
4
/
in. NPT internal
1
4
29
/
in. (752,5 mm)
5
8
100 psi (6,89 mm)
*
1)
3
Table 1
WARNING
This device is not intended to reduce or
replace user responsibility when transferring
liquids to holding tank.
Failure to comply may result in death or
serious injury.
