Install Software
1. Insert the kit CD in the CD drive of your
PC.
2. Install the ISSP Programmer software.
3
In-System Programming
1. Connect the ISSP cable between the
RJ45 connector of the ISSP board and
the ISSP header on the target board.
2. Initiate programming.
CY3207-ISSP PROGRAMMER KIT
QUICK START GUIDE
2
Socket Programming
1. Connect the USB cable between the PC
and the programmer.
2. Open the ISSP Programmer and update
the kit firmware.
3. Place the silicon in the ZIF socket; initiate
programming from the ISSP Programmer.
4
Standalone Programming
1. Unplug the USB cable and plug in the
power cable.
2. Place the silicon in the ZIF socket and
press the Program button to initiate
programming.
Note: See the user guide for more
information on programming modes.
